SDO HMI 2014-09-09 11:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 50.21 | 220.06 | 38.91 | 169.24 | -16.26 | 64.68 | -44.42 | 118.52 | 0.7659 | 77.6 | 67.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-09 11:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.88 | 134.37 | 8.03 | 99.41 | -16.16 | 66.97 | -42.13 | 119.59 | 0.7433 | 916.4 | 252.9 | |
| 17.57 | -1.00 | 13.01 | -1.00 | -15.97 | 66.63 | -42.46 | 119.16 | 0.7456 | 852.0 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.55 | -17.83 | 64.92 | -44.18 | 120.43 | 0.7717 | 620.0 | 559.5 | |
| 0.00 | 2.23 | 0.00 | 1.71 | -16.63 | 65.06 | -44.04 | 119.10 | 0.7645 | 497.0 | 316.5 | |
| 0.00 | 0.89 | 0.00 | 0.69 | -16.72 | 64.77 | -44.33 | 119.05 | 0.7678 | 113.0 | 224.8 | |
| 0.00 | 1.34 | 0.00 | 1.03 | -16.37 | 64.70 | -44.40 | 118.59 | 0.7669 | 569.0 | 410.8 | |
| 0.00 | 6.33 | 0.00 | 4.85 | -15.95 | 64.64 | -44.46 | 118.07 | 0.7655 | 733.0 | 510.8 | |
| 0.00 | 1.07 | 0.00 | 0.83 | -16.20 | 64.39 | -44.71 | 118.24 | 0.7691 | 296.0 | 351.2 | |
| 0.00 | 2.05 | 0.00 | 1.59 | -16.16 | 64.14 | -44.96 | 118.05 | 0.7714 | 300.0 | 225.4 | |
| 0.00 | 0.89 | 0.00 | 0.68 | -13.83 | 64.10 | -45.00 | 115.24 | 0.7613 | 492.0 | 392.9 | |
| 0.00 | 2.32 | 0.00 | 1.85 | -16.90 | 62.87 | -46.23 | 118.28 | 0.7869 | -447.0 | -418.7 | |
| 7.94 | 12.84 | 6.27 | 10.15 | -16.13 | 63.06 | -46.04 | 117.48 | 0.7816 | -749.4 | -495.0 | |
| 0.00 | 1.78 | 0.00 | 1.43 | -16.83 | 62.57 | -46.53 | 118.05 | 0.7894 | -508.0 | -491.0 | |
| 0.00 | 1.87 | 0.00 | 1.51 | -16.42 | 62.10 | -47.00 | 117.35 | 0.7920 | -768.0 | -588.4 | |
| 0.00 | 0.54 | 0.00 | 0.43 | -16.54 | 61.88 | -47.22 | 117.38 | 0.7946 | -517.0 | -561.0 | |
| 0.00 | 0.62 | 0.00 | 0.51 | -16.74 | 61.81 | -47.29 | 117.58 | 0.7961 | -614.0 | -606.4 | |
| 0.00 | 2.68 | 0.00 | 2.19 | -16.64 | 61.52 | -47.58 | 117.32 | 0.7984 | -493.0 | -485.7 | |
| 0.00 | 1.61 | 0.00 | 1.33 | -16.87 | 61.11 | -47.99 | 117.40 | 0.8031 | -716.0 | -635.2 | |
| 1.16 | 42.00 | 0.97 | 35.15 | -16.87 | 60.77 | -48.32 | 117.25 | 0.8062 | -689.4 | -332.3 | |
| 0.00 | 0.71 | 0.00 | 0.60 | -17.76 | 60.41 | -48.69 | 118.09 | 0.8131 | -460.0 | -354.9 | |
| 0.00 | 0.80 | 0.00 | 0.68 | -18.03 | 60.31 | -48.79 | 118.35 | 0.8151 | -515.0 | -435.6 | |
| 3.12 | -19.00 | 2.59 | -19.00 | -16.51 | 60.75 | -48.35 | 116.83 | 0.8049 | -801.7 | 999999 | |
| 1.69 | -19.00 | 1.42 | -19.00 | -16.74 | 60.44 | -48.66 | 116.94 | 0.8087 | -619.5 | 999999 | |
| 7.31 | -19.00 | 6.16 | -19.00 | -16.79 | 60.23 | -48.87 | 116.91 | 0.8109 | -498.2 | 999999 | |
| 0.54 | 1.43 | 0.46 | 1.22 | -17.51 | 59.97 | -49.13 | 117.60 | 0.8160 | -423.8 | -412.4 | |
| 0.00 | 0.98 | 0.00 | 0.85 | -17.32 | 59.21 | -49.89 | 117.05 | 0.8220 | -523.0 | -401.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
