SDO HMI 2014-09-10 03:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 275.24 | 1424.95 | 141.40 | 732.35 | 15.69 | 87.40 | -12.88 | 55.07 | 0.2643 | 409.5 | 63.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-10 03:00:36 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.25 | 0.00 | 0.63 | 8.94 | 91.43 | -8.84 | 78.56 | 0.1557 | -891.0 | -576.6 | |
| 1.60 | 9.27 | 0.81 | 4.71 | 16.30 | 91.12 | -9.16 | 43.90 | 0.2213 | 1043.2 | 801.6 | |
| 0.00 | 1.60 | 0.00 | 0.81 | 11.32 | 91.06 | -9.22 | 65.27 | 0.1738 | -761.0 | -500.7 | |
| 0.00 | 2.32 | 0.00 | 1.18 | 17.06 | 90.57 | -9.71 | 43.15 | 0.2368 | 720.0 | 693.0 | |
| 0.00 | 1.52 | 0.00 | 0.76 | 11.77 | 90.76 | -9.52 | 63.62 | 0.1815 | -991.0 | -800.5 | |
| 0.00 | 1.69 | 0.00 | 0.85 | 10.16 | 90.75 | -9.53 | 72.18 | 0.1719 | -870.0 | -635.9 | |
| 0.00 | 1.52 | 0.00 | 0.76 | 11.85 | 90.54 | -9.74 | 63.69 | 0.1855 | -959.0 | -806.1 | |
| 0.00 | 1.07 | 0.00 | 0.54 | 14.70 | 90.17 | -10.10 | 52.25 | 0.2156 | -1037.0 | -873.2 | |
| 0.00 | 3.30 | 0.00 | 1.66 | 12.03 | 90.25 | -10.03 | 63.46 | 0.1912 | -828.0 | -695.1 | |
| 0.00 | 1.52 | 0.00 | 0.76 | 10.36 | 90.28 | -10.00 | 71.83 | 0.1806 | -142.0 | -114.9 | |
| 0.00 | 2.76 | 0.00 | 1.40 | 14.60 | 89.92 | -10.35 | 53.26 | 0.2180 | -960.0 | -736.2 | |
| 0.00 | 1.87 | 0.00 | 0.96 | 18.12 | 89.67 | -10.60 | 42.57 | 0.2597 | 744.0 | 615.3 | |
| 0.00 | 0.98 | 0.00 | 0.50 | 16.00 | 89.79 | -10.49 | 48.63 | 0.2341 | 541.0 | 441.0 | |
| 0.00 | 0.62 | 0.00 | 0.32 | 18.82 | 89.31 | -10.97 | 41.65 | 0.2723 | 834.0 | 456.3 | |
| 5.88 | 16.13 | 3.02 | 8.29 | 18.17 | 89.32 | -10.96 | 43.34 | 0.2644 | 1189.0 | 505.7 | |
| 0.00 | 1.25 | 0.00 | 0.63 | 13.20 | 89.58 | -10.70 | 59.71 | 0.2103 | -697.0 | -494.0 | |
| 0.00 | 1.60 | 0.00 | 0.81 | 12.77 | 89.41 | -10.87 | 61.90 | 0.2095 | -1044.0 | -858.1 | |
| 0.00 | 0.98 | 0.00 | 0.50 | 12.22 | 89.43 | -10.85 | 64.25 | 0.2052 | -844.0 | -742.6 | |
| 2.32 | 1192.27 | 1.18 | 613.12 | 15.53 | 89.08 | -11.19 | 52.00 | 0.2385 | 928.3 | 132.0 | |
| 0.00 | 1.07 | 0.00 | 0.54 | 14.19 | 89.15 | -11.13 | 56.68 | 0.2249 | -725.0 | -463.2 | |
| 0.00 | 3.03 | 0.00 | 1.54 | 12.22 | 89.11 | -11.16 | 64.88 | 0.2100 | -763.0 | -608.1 | |
| 0.00 | 1.43 | 0.00 | 0.73 | 18.34 | 88.75 | -11.52 | 44.25 | 0.2730 | 767.0 | 544.5 | |
| 0.00 | 0.89 | 0.00 | 0.45 | 12.42 | 88.95 | -11.33 | 64.28 | 0.2139 | -944.0 | -769.9 | |
| 1.60 | 8.82 | 0.83 | 4.55 | 18.64 | 88.54 | -11.74 | 43.96 | 0.2790 | 995.9 | 279.1 | |
| 0.00 | 1.07 | 0.00 | 0.54 | 12.66 | 88.87 | -11.40 | 63.39 | 0.2167 | -857.0 | -767.6 | |
| 0.00 | 1.16 | 0.00 | 0.59 | 13.70 | 88.83 | -11.45 | 59.29 | 0.2254 | -659.0 | -458.0 | |
| 5.44 | -19.00 | 2.79 | -19.00 | 16.80 | 88.53 | -11.75 | 49.19 | 0.2587 | 1245.0 | 999999 | |
| 2.85 | 4.55 | 1.45 | 2.31 | 13.21 | 88.69 | -11.59 | 61.51 | 0.2235 | -1182.5 | -898.8 | |
| 0.00 | 1.07 | 0.00 | 0.55 | 18.79 | 88.36 | -11.91 | 43.97 | 0.2827 | 178.0 | 212.0 | |
| 0.00 | 1.25 | 0.00 | 0.63 | 12.93 | 88.67 | -11.61 | 62.65 | 0.2217 | -1021.0 | -958.5 | |
| 0.00 | 0.80 | 0.00 | 0.41 | 11.30 | 88.74 | -11.54 | 69.60 | 0.2102 | -722.0 | -512.1 | |
| 2.50 | -19.00 | 1.28 | -19.00 | 16.98 | 88.36 | -11.92 | 49.05 | 0.2628 | 1261.1 | 999999 | |
| 0.00 | 5.97 | 0.00 | 3.04 | 13.42 | 88.55 | -11.72 | 60.94 | 0.2271 | -418.0 | -290.1 | |
| 1.25 | 4.99 | 0.64 | 2.58 | 18.63 | 88.08 | -12.20 | 45.04 | 0.2842 | 1035.2 | 791.5 | |
| 0.00 | 1.25 | 0.00 | 0.63 | 13.05 | 88.41 | -11.86 | 62.67 | 0.2265 | -1003.0 | -792.0 | |
| 0.89 | 35.39 | 0.45 | 18.03 | 13.59 | 88.20 | -12.08 | 60.95 | 0.2338 | 765.1 | -320.7 | |
| 0.00 | 2.41 | 0.00 | 1.22 | 12.26 | 88.26 | -12.02 | 66.18 | 0.2234 | -562.0 | -574.6 | |
| 183.98 | -19.00 | 94.35 | -19.00 | 16.21 | 87.99 | -12.29 | 52.25 | 0.2597 | 1563.4 | 999999 | |
| 4.90 | 8.02 | 2.54 | 4.15 | 18.81 | 87.78 | -12.50 | 45.26 | 0.2898 | 997.0 | 709.0 | |
| 0.00 | 0.89 | 0.00 | 0.45 | 13.95 | 88.08 | -12.19 | 59.80 | 0.2383 | 601.0 | 358.4 | |
| 0.00 | 1.60 | 0.00 | 0.84 | 20.54 | 87.61 | -12.67 | 41.45 | 0.3117 | 780.0 | 657.5 | |
| 0.00 | 2.14 | 0.00 | 1.11 | 18.47 | 87.74 | -12.54 | 46.23 | 0.2865 | 1075.0 | 911.2 | |
| 2.05 | -36.00 | 1.04 | -36.00 | 13.04 | 87.97 | -12.31 | 63.50 | 0.2331 | -1118.7 | 999999 | |
| 0.00 | 1.96 | 0.00 | 0.99 | 8.17 | 88.16 | -12.12 | 84.86 | 0.2095 | -903.0 | -685.0 | |
| 0.00 | 1.07 | 0.00 | 0.55 | 19.30 | 87.57 | -12.70 | 44.45 | 0.2976 | 718.0 | 577.6 | |
| 0.00 | 1.16 | 0.00 | 0.60 | 20.78 | 87.39 | -12.89 | 41.37 | 0.3170 | 795.0 | 622.2 | |
| 0.00 | 2.41 | 0.00 | 1.25 | 18.99 | 87.40 | -12.88 | 45.61 | 0.2962 | 1043.0 | 796.3 | |
| 1.34 | 3.74 | 0.69 | 1.94 | 19.20 | 87.32 | -12.96 | 45.24 | 0.2995 | 876.8 | 720.0 | |
| 0.00 | 0.45 | 0.00 | 0.23 | 7.83 | 87.92 | -12.36 | 86.51 | 0.2133 | -374.0 | -420.4 | |
| 0.00 | 1.43 | 0.00 | 0.73 | 12.60 | 87.48 | -12.79 | 66.01 | 0.2376 | -913.0 | -767.0 | |
| 0.00 | 0.71 | 0.00 | 0.37 | 18.39 | 87.09 | -13.19 | 47.81 | 0.2935 | 826.0 | 672.5 | |
| 0.00 | 1.16 | 0.00 | 0.59 | 13.39 | 87.38 | -12.90 | 63.16 | 0.2444 | -785.0 | -608.5 | |
| 0.00 | 0.98 | 0.00 | 0.51 | 18.66 | 86.87 | -13.41 | 47.54 | 0.2991 | 804.0 | 713.2 | |
| 2.94 | -19.00 | 1.52 | -19.00 | 16.30 | 86.92 | -13.36 | 54.12 | 0.2750 | 843.8 | 999999 | |
| 0.00 | 1.25 | 0.00 | 0.64 | 13.29 | 87.10 | -13.18 | 63.99 | 0.2480 | -933.0 | -772.7 | |
| 0.00 | 2.50 | 0.00 | 1.27 | 10.11 | 87.22 | -13.06 | 76.61 | 0.2297 | -903.0 | -686.5 | |
| 0.00 | 1.25 | 0.00 | 0.64 | 10.83 | 86.93 | -13.34 | 73.86 | 0.2370 | -792.0 | -578.1 | |
| 0.00 | 3.30 | 0.00 | 1.68 | 11.43 | 86.88 | -13.40 | 71.47 | 0.2407 | -949.0 | -739.2 | |
| 0.00 | 3.57 | 0.00 | 1.82 | 11.10 | 86.76 | -13.51 | 72.94 | 0.2409 | -995.0 | -815.4 | |
| 0.00 | 1.16 | 0.00 | 0.59 | 12.21 | 86.42 | -13.85 | 68.99 | 0.2518 | -1008.0 | -725.3 | |
| 0.00 | 1.60 | 0.00 | 0.82 | 11.57 | 86.27 | -14.01 | 71.62 | 0.2511 | -1121.0 | -883.3 | |
| 0.00 | 0.80 | 0.00 | 0.41 | 14.90 | 86.04 | -14.24 | 60.08 | 0.2754 | -35.0 | -61.6 | |
| 0.00 | 2.23 | 0.00 | 1.15 | 16.70 | 85.75 | -14.53 | 55.06 | 0.2944 | 544.0 | 398.4 | |
| 0.00 | 0.89 | 0.00 | 0.46 | 11.86 | 85.90 | -14.38 | 70.91 | 0.2583 | -941.0 | -777.8 | |
| 1.34 | -19.00 | 0.69 | -19.00 | 14.76 | 85.53 | -14.74 | 61.31 | 0.2818 | -901.3 | 999999 | |
| 0.00 | 1.60 | 0.00 | 0.83 | 13.12 | 85.64 | -14.64 | 66.66 | 0.2692 | -961.0 | -797.8 | |
| 0.80 | -19.00 | 0.41 | -19.00 | 14.03 | 85.45 | -14.82 | 63.82 | 0.2778 | -1227.2 | 999999 | |
| 0.00 | 1.96 | 0.00 | 1.01 | 12.55 | 85.55 | -14.73 | 68.82 | 0.2674 | -1036.0 | -917.1 | |
| 0.98 | -19.00 | 0.50 | -19.00 | 13.39 | 85.46 | -14.81 | 65.96 | 0.2736 | -1076.7 | 999999 | |
| 0.80 | 3.03 | 0.42 | 1.58 | 17.20 | 85.12 | -15.15 | 54.70 | 0.3073 | 649.2 | 464.1 | |
| 11.59 | -19.00 | 5.97 | -19.00 | 13.63 | 85.32 | -14.96 | 65.34 | 0.2773 | -1189.8 | 999999 | |
| 0.89 | 2.05 | 0.46 | 1.05 | 12.39 | 85.39 | -14.88 | 69.55 | 0.2689 | -1048.4 | -913.8 | |
| 0.00 | 3.30 | 0.00 | 1.70 | 12.78 | 85.34 | -14.94 | 68.23 | 0.2719 | -997.0 | -840.6 | |
| 0.00 | 1.07 | 0.00 | 0.55 | 12.60 | 85.35 | -14.93 | 68.85 | 0.2708 | -900.0 | -818.5 | |
| 0.00 | 1.07 | 0.00 | 0.55 | 11.78 | 85.36 | -14.91 | 71.76 | 0.2665 | -871.0 | -794.8 | |
| 0.00 | 0.45 | 0.00 | 0.23 | 16.55 | 85.04 | -15.23 | 56.65 | 0.3028 | 351.0 | 251.4 | |
| 0.00 | 1.43 | 0.00 | 0.73 | 11.57 | 85.31 | -14.97 | 72.59 | 0.2663 | -838.0 | -662.2 | |
| 18.45 | -19.00 | 9.54 | -19.00 | 14.63 | 85.03 | -15.25 | 62.49 | 0.2882 | -1188.6 | 999999 | |
| 4.10 | -19.00 | 2.12 | -19.00 | 15.24 | 84.98 | -15.29 | 60.65 | 0.2933 | -1168.6 | 999999 | |
| 0.00 | 1.69 | 0.00 | 0.87 | 12.59 | 85.16 | -15.12 | 69.09 | 0.2737 | -974.0 | -741.6 | |
| 0.00 | 1.87 | 0.00 | 0.96 | 12.38 | 85.14 | -15.14 | 69.86 | 0.2729 | -1045.0 | -884.9 | |
| 1.96 | -19.00 | 1.02 | -19.00 | 16.12 | 84.85 | -15.43 | 58.21 | 0.3020 | -748.5 | 999999 | |
| 10.43 | -19.00 | 5.41 | -19.00 | 15.54 | 84.83 | -15.45 | 59.96 | 0.2977 | -1261.7 | 999999 | |
| 1.69 | -19.00 | 0.88 | -19.00 | 16.39 | 84.76 | -15.51 | 57.56 | 0.3054 | -900.2 | 999999 | |
| 0.00 | 5.53 | 0.00 | 2.88 | 16.94 | 84.72 | -15.56 | 56.07 | 0.3106 | -212.0 | -297.1 | |
| 0.00 | 2.05 | 0.00 | 1.06 | 13.86 | 84.89 | -15.39 | 65.14 | 0.2853 | -480.0 | -522.3 | |
| 0.98 | 4.81 | 0.51 | 2.48 | 12.41 | 84.94 | -15.33 | 69.98 | 0.2761 | -973.9 | -757.0 | |
| 0.00 | 3.30 | 0.00 | 1.70 | 11.34 | 84.94 | -15.34 | 73.73 | 0.2713 | -948.0 | -833.9 | |
| 0.00 | 0.89 | 0.00 | 0.46 | 17.06 | 84.51 | -15.77 | 56.07 | 0.3144 | -922.0 | -697.1 | |
| 1.69 | -19.00 | 0.88 | -19.00 | 16.14 | 84.52 | -15.75 | 58.65 | 0.3068 | -1163.0 | 999999 | |
| 0.00 | 1.34 | 0.00 | 0.70 | 16.41 | 84.50 | -15.78 | 57.89 | 0.3093 | -957.0 | -651.8 | |
| 0.00 | 2.32 | 0.00 | 1.20 | 12.22 | 84.73 | -15.55 | 70.85 | 0.2785 | -892.0 | -736.1 | |
| 0.00 | 1.43 | 0.00 | 0.74 | 15.34 | 84.49 | -15.79 | 61.04 | 0.3012 | -703.0 | -593.4 | |
| 0.00 | 1.34 | 0.00 | 0.70 | 16.81 | 84.34 | -15.94 | 57.04 | 0.3147 | -990.0 | -811.4 | |
| 0.00 | 2.58 | 0.00 | 1.34 | 14.49 | 84.45 | -15.82 | 63.70 | 0.2958 | -829.0 | -660.6 | |
| 0.00 | 1.43 | 0.00 | 0.74 | 14.24 | 84.31 | -15.97 | 64.66 | 0.2963 | -778.0 | -700.1 | |
| 0.00 | 3.57 | 0.00 | 1.84 | 12.57 | 84.39 | -15.89 | 70.00 | 0.2856 | -658.0 | -569.1 | |
| 0.00 | 2.23 | 0.00 | 1.15 | 12.29 | 84.28 | -16.00 | 71.04 | 0.2860 | -624.0 | -489.8 | |
| 0.00 | 1.43 | 0.00 | 0.74 | 11.89 | 84.08 | -16.20 | 72.57 | 0.2874 | -739.0 | -558.4 | |
| 0.00 | 1.25 | 0.00 | 0.64 | 11.29 | 84.08 | -16.20 | 74.64 | 0.2850 | -650.0 | -406.5 | |
| 0.00 | 0.98 | 0.00 | 0.51 | 10.55 | 83.74 | -16.54 | 77.41 | 0.2881 | -727.0 | -538.5 | |
| 0.00 | 2.05 | 0.00 | 1.07 | 14.95 | 82.72 | -17.55 | 64.43 | 0.3245 | -741.0 | -527.3 | |
| 0.00 | 1.96 | 0.00 | 1.02 | 10.97 | 82.81 | -17.47 | 76.55 | 0.3043 | -768.0 | -657.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
