SDO HMI 2014-09-10 21:44:05 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 248.96 | 1204.14 | 125.01 | 604.55 | 16.02 | 87.62 | -2.35 | 5.46 | 0.1605 | 425.5 | 217.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-10 21:44:05 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.42 | 0.00 | 0.72 | 17.29 | 92.17 | 2.19 | 348.19 | 0.1790 | -813.0 | -632.0 | |
| 0.00 | 1.34 | 0.00 | 0.67 | 18.34 | 91.19 | 1.22 | 354.02 | 0.1943 | -801.0 | -509.0 | |
| 0.00 | 1.16 | 0.00 | 0.58 | 16.29 | 91.02 | 1.04 | 353.65 | 0.1588 | 1026.0 | 851.2 | |
| 0.00 | 1.25 | 0.00 | 0.62 | 11.40 | 90.72 | 0.74 | 350.08 | 0.0738 | -809.0 | -619.9 | |
| 0.45 | 2.23 | 0.22 | 1.12 | 17.61 | 90.71 | 0.74 | 356.10 | 0.1810 | 1066.4 | 825.0 | |
| 1.25 | 2.76 | 0.62 | 1.38 | 15.59 | 90.61 | 0.63 | 355.81 | 0.1460 | 1009.1 | 740.4 | |
| 0.00 | 4.45 | 0.00 | 2.24 | 17.36 | 90.40 | 0.42 | 357.72 | 0.1765 | 1061.0 | 881.1 | |
| 0.00 | 1.69 | 0.00 | 0.85 | 15.26 | 90.39 | 0.41 | 357.15 | 0.1400 | -758.0 | -568.3 | |
| 0.00 | 0.80 | 0.00 | 0.40 | 15.29 | 90.08 | 0.10 | 359.31 | 0.1404 | -675.0 | -505.8 | |
| 0.00 | 1.25 | 0.00 | 0.63 | 16.97 | 89.98 | 0.01 | 359.96 | 0.1695 | -711.0 | -529.4 | |
| 0.00 | 1.60 | 0.00 | 0.80 | 14.16 | 89.92 | -0.06 | 0.47 | 0.1208 | -901.0 | -718.3 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 13.61 | 89.86 | -0.12 | 1.06 | 0.1113 | -866.0 | -773.6 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 14.31 | 89.76 | -0.21 | 1.68 | 0.1235 | -839.0 | -679.5 | |
| 10.06 | 890.47 | 5.07 | 447.30 | 17.98 | 89.70 | -0.28 | 1.41 | 0.1870 | 1119.2 | 464.8 | |
| 0.00 | 1.16 | 0.00 | 0.58 | 15.47 | 89.61 | -0.37 | 2.49 | 0.1437 | -385.0 | -304.2 | |
| 0.00 | 16.65 | 0.00 | 8.33 | 15.13 | 89.54 | -0.43 | 3.04 | 0.1379 | -103.0 | -167.2 | |
| 0.00 | 3.47 | 0.00 | 1.73 | 13.77 | 89.45 | -0.52 | 4.48 | 0.1143 | -664.0 | -738.8 | |
| 0.00 | 2.58 | 0.00 | 1.30 | 16.75 | 89.45 | -0.53 | 3.06 | 0.1660 | 461.0 | 241.9 | |
| 0.00 | 1.60 | 0.00 | 0.80 | 13.98 | 89.42 | -0.56 | 4.59 | 0.1180 | -818.0 | -747.4 | |
| 0.00 | 2.14 | 0.00 | 1.08 | 18.65 | 89.35 | -0.63 | 3.00 | 0.1988 | 176.0 | 184.6 | |
| 0.00 | 0.71 | 0.00 | 0.36 | 14.46 | 89.23 | -0.74 | 5.71 | 0.1267 | 723.0 | 522.6 | |
| 0.00 | 1.96 | 0.00 | 0.97 | 12.10 | 89.21 | -0.77 | 8.84 | 0.0859 | -994.0 | -812.3 | |
| 0.00 | 2.76 | 0.00 | 1.39 | 18.62 | 89.10 | -0.88 | 4.23 | 0.1986 | 767.0 | 688.8 | |
| 0.00 | 1.25 | 0.00 | 0.62 | 13.46 | 89.08 | -0.90 | 8.00 | 0.1097 | -1040.0 | -856.4 | |
| 0.00 | 2.49 | 0.00 | 1.24 | 13.83 | 89.05 | -0.93 | 7.82 | 0.1161 | -1015.0 | -831.0 | |
| 0.00 | 0.89 | 0.00 | 0.45 | 18.50 | 88.94 | -1.04 | 5.04 | 0.1967 | 933.0 | 762.1 | |
| 0.00 | 1.34 | 0.00 | 0.67 | 13.19 | 88.90 | -1.08 | 10.07 | 0.1055 | -1068.0 | -857.3 | |
| 2.05 | 8.90 | 1.04 | 4.51 | 18.87 | 88.62 | -1.36 | 6.37 | 0.2035 | 1033.6 | 690.3 | |
| 1.96 | -28.00 | 0.99 | -28.00 | 18.96 | 88.58 | -1.39 | 6.46 | 0.2052 | 835.7 | 999999 | |
| 0.00 | 5.34 | 0.00 | 2.67 | 14.37 | 88.61 | -1.37 | 10.55 | 0.1267 | 122.0 | 3.2 | |
| 0.00 | 1.16 | 0.00 | 0.58 | 13.61 | 88.52 | -1.46 | 12.56 | 0.1140 | -812.0 | -627.8 | |
| 1.16 | -14.00 | 0.58 | -14.00 | 16.87 | 88.44 | -1.54 | 8.73 | 0.1699 | 824.0 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.53 | 12.98 | 88.40 | -1.58 | 15.04 | 0.1038 | -1120.0 | -827.8 | |
| 0.89 | -14.00 | 0.45 | -14.00 | 18.19 | 88.33 | -1.64 | 8.16 | 0.1926 | 680.4 | 999999 | |
| 3.21 | -14.00 | 1.62 | -14.00 | 17.70 | 88.28 | -1.70 | 8.86 | 0.1844 | 1039.3 | 999999 | |
| 2.58 | -14.00 | 1.30 | -14.00 | 16.96 | 88.22 | -1.76 | 9.87 | 0.1720 | 1070.6 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.54 | 20.16 | 88.12 | -1.85 | 7.73 | 0.2266 | 791.0 | 630.2 | |
| 77.02 | -14.00 | 38.59 | -14.00 | 15.65 | 88.13 | -1.84 | 11.96 | 0.1500 | 1720.9 | 999999 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 10.92 | 88.13 | -1.84 | 26.28 | 0.0717 | -835.0 | -650.2 | |
| 19.68 | -14.00 | 9.91 | -14.00 | 17.61 | 88.02 | -1.95 | 10.25 | 0.1835 | 1122.5 | 999999 | |
| 0.00 | 9.26 | 0.00 | 4.61 | 12.67 | 88.06 | -1.91 | 19.03 | 0.1004 | -1124.0 | -939.3 | |
| 0.00 | 1.51 | 0.00 | 0.75 | 12.85 | 87.87 | -2.10 | 20.11 | 0.1045 | -1037.0 | -881.1 | |
| 4.27 | -14.00 | 2.15 | -14.00 | 17.42 | 87.77 | -2.21 | 11.74 | 0.1812 | 1070.6 | 999999 | |
| 0.00 | 1.25 | 0.00 | 0.63 | 19.02 | 87.75 | -2.22 | 10.19 | 0.2082 | 849.0 | 758.4 | |
| 78.44 | -14.00 | 39.42 | -14.00 | 16.63 | 87.75 | -2.23 | 12.88 | 0.1679 | 1382.2 | 999999 | |
| 0.00 | 1.87 | 0.00 | 0.95 | 20.69 | 87.38 | -2.60 | 10.35 | 0.2374 | 830.0 | 612.9 | |
| 0.00 | 1.07 | 0.00 | 0.54 | 19.48 | 87.23 | -2.74 | 12.01 | 0.2177 | 865.0 | 759.3 | |
| 0.00 | 2.31 | 0.00 | 1.15 | 12.76 | 87.23 | -2.75 | 25.97 | 0.1074 | -1200.0 | -950.8 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 9.16 | 87.25 | -2.72 | 54.50 | 0.0579 | -901.0 | -722.5 | |
| 0.00 | 0.80 | 0.00 | 0.40 | 12.67 | 86.92 | -3.06 | 28.85 | 0.1084 | -866.0 | -659.8 | |
| 0.00 | 1.69 | 0.00 | 0.84 | 12.88 | 86.88 | -3.09 | 28.17 | 0.1119 | -1196.0 | -1027.4 | |
| 0.00 | 0.80 | 0.00 | 0.40 | 17.94 | 86.78 | -3.19 | 15.94 | 0.1939 | 768.0 | 613.1 | |
| 0.00 | 1.25 | 0.00 | 0.63 | 18.15 | 86.71 | -3.26 | 15.94 | 0.1978 | 717.0 | 543.9 | |
| 0.00 | 1.69 | 0.00 | 0.84 | 13.88 | 86.78 | -3.20 | 25.11 | 0.1282 | -705.0 | -401.9 | |
| 0.00 | 2.49 | 0.00 | 1.24 | 12.18 | 86.71 | -3.27 | 32.93 | 0.1031 | -1025.0 | -883.3 | |
| 0.00 | 0.36 | 0.00 | 0.18 | 11.39 | 86.68 | -3.29 | 37.87 | 0.0922 | -801.0 | -683.2 | |
| 0.00 | 4.27 | 0.00 | 2.13 | 11.94 | 86.62 | -3.36 | 35.01 | 0.1004 | -917.0 | -729.4 | |
| 0.00 | 1.42 | 0.00 | 0.71 | 12.42 | 86.52 | -3.46 | 33.12 | 0.1083 | -1135.0 | -947.6 | |
| 0.00 | 1.25 | 0.00 | 0.65 | 25.13 | 86.19 | -3.78 | 11.00 | 0.3144 | 398.0 | 375.4 | |
| 0.00 | 1.07 | 0.00 | 0.54 | 15.43 | 86.38 | -3.60 | 22.99 | 0.1554 | 467.0 | 267.0 | |
| 0.00 | 1.78 | 0.00 | 0.90 | 18.09 | 86.30 | -3.67 | 17.93 | 0.1988 | 908.0 | 738.8 | |
| 0.00 | 2.76 | 0.00 | 1.38 | 12.24 | 86.30 | -3.67 | 35.69 | 0.1078 | -674.0 | -690.5 | |
| 0.80 | 1.87 | 0.40 | 0.93 | 12.87 | 86.17 | -3.81 | 33.38 | 0.1182 | -1197.1 | -961.4 | |
| 0.00 | 0.71 | 0.00 | 0.36 | 17.93 | 86.05 | -3.93 | 19.33 | 0.1976 | 508.0 | 568.4 | |
| 0.00 | 1.42 | 0.00 | 0.71 | 13.18 | 86.07 | -3.90 | 32.64 | 0.1235 | -1198.0 | -963.6 | |
| 0.00 | 2.23 | 0.00 | 1.11 | 11.33 | 86.10 | -3.88 | 42.90 | 0.0979 | -830.0 | -741.9 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 16.43 | 85.95 | -4.02 | 22.83 | 0.1742 | 771.0 | 597.5 | |
| 0.00 | 0.80 | 0.00 | 0.40 | 10.24 | 85.90 | -4.08 | 53.18 | 0.0879 | -739.0 | -595.9 | |
| 0.00 | 3.21 | 0.00 | 1.61 | 15.09 | 85.73 | -4.25 | 27.62 | 0.1550 | -175.0 | -175.3 | |
| 0.00 | 3.12 | 0.00 | 1.55 | 11.57 | 85.72 | -4.25 | 43.86 | 0.1053 | -905.0 | -854.3 | |
| 0.00 | 1.16 | 0.00 | 0.58 | 11.06 | 85.70 | -4.28 | 47.67 | 0.0994 | -1004.0 | -816.5 | |
| 2.76 | 23.33 | 1.38 | 11.66 | 13.63 | 85.57 | -4.41 | 33.84 | 0.1347 | -1217.6 | -947.4 | |
| 0.00 | 1.51 | 0.00 | 0.76 | 12.45 | 85.56 | -4.42 | 39.63 | 0.1185 | -1026.0 | -893.8 | |
| 0.00 | 1.87 | 0.00 | 0.93 | 12.78 | 85.46 | -4.52 | 38.48 | 0.1240 | -682.0 | -595.7 | |
| 0.00 | 1.51 | 0.00 | 0.75 | 12.26 | 85.44 | -4.54 | 41.41 | 0.1175 | -948.0 | -688.5 | |
| 0.00 | 11.13 | 0.00 | 5.57 | 14.23 | 85.34 | -4.64 | 32.73 | 0.1456 | -731.0 | -855.8 | |
| 1.87 | -72.00 | 0.93 | -72.00 | 13.47 | 85.32 | -4.65 | 35.96 | 0.1350 | -1071.5 | 999999 | |
| 0.00 | 1.25 | 0.00 | 0.62 | 11.81 | 85.35 | -4.63 | 44.69 | 0.1128 | -834.0 | -655.9 | |
| 0.00 | 5.79 | 0.00 | 2.92 | 16.70 | 85.19 | -4.79 | 25.89 | 0.1838 | -204.0 | -245.1 | |
| 0.00 | 1.51 | 0.00 | 0.75 | 11.54 | 85.29 | -4.68 | 46.82 | 0.1102 | -1047.0 | -874.2 | |
| 0.00 | 1.51 | 0.00 | 0.75 | 10.99 | 85.27 | -4.71 | 50.84 | 0.1044 | -859.0 | -715.9 | |
| 6.23 | 106.13 | 3.13 | 53.31 | 15.54 | 85.16 | -4.82 | 29.25 | 0.1665 | -327.0 | -492.5 | |
| 0.00 | 1.96 | 0.00 | 0.98 | 10.51 | 85.06 | -4.91 | 55.83 | 0.1023 | -849.0 | -657.3 | |
| 12.47 | -82.00 | 6.25 | -82.00 | 14.69 | 84.95 | -5.02 | 33.11 | 0.1557 | -1190.6 | 999999 | |
| 15.14 | -82.00 | 7.60 | -82.00 | 15.33 | 84.88 | -5.10 | 31.32 | 0.1657 | -1186.6 | 999999 | |
| 3.29 | -82.00 | 1.66 | -82.00 | 15.69 | 84.87 | -5.11 | 30.21 | 0.1711 | -1181.5 | 999999 | |
| 0.00 | 2.31 | 0.00 | 1.16 | 12.02 | 84.91 | -5.06 | 45.95 | 0.1207 | -1049.0 | -907.7 | |
| 2.85 | -82.00 | 1.43 | -82.00 | 15.84 | 84.80 | -5.17 | 30.07 | 0.1739 | -1061.7 | 999999 | |
| 0.00 | 1.16 | 0.00 | 0.59 | 18.05 | 84.68 | -5.30 | 25.05 | 0.2082 | 784.0 | 589.3 | |
| 0.00 | 3.83 | 0.00 | 1.92 | 13.95 | 84.44 | -5.54 | 38.62 | 0.1507 | -1051.0 | -901.2 | |
| 0.00 | 2.67 | 0.00 | 1.33 | 12.22 | 84.48 | -5.50 | 47.05 | 0.1286 | -786.0 | -780.2 | |
| 0.00 | 1.25 | 0.00 | 0.62 | 13.92 | 84.03 | -5.94 | 40.73 | 0.1547 | -834.0 | -628.6 | |
| 0.53 | 1.60 | 0.27 | 0.80 | 10.95 | 83.97 | -6.00 | 57.62 | 0.1221 | -1094.0 | -915.2 | |
| 0.00 | 1.42 | 0.00 | 0.71 | 10.95 | 83.79 | -6.19 | 58.40 | 0.1248 | -791.0 | -638.2 | |
| 0.00 | 1.42 | 0.00 | 0.72 | 15.00 | 83.10 | -6.88 | 40.47 | 0.1791 | -678.0 | -480.8 | |
| 0.00 | 1.78 | 0.00 | 0.89 | 10.69 | 82.99 | -6.99 | 62.99 | 0.1348 | -766.0 | -646.8 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 10.72 | 82.68 | -7.30 | 63.78 | 0.1397 | -692.0 | -410.5 | |
| 0.00 | 1.60 | 0.00 | 0.81 | 15.19 | 81.51 | -8.46 | 45.54 | 0.1999 | -893.0 | -649.3 | |
| 0.00 | 1.34 | 0.00 | 0.68 | 15.40 | 81.41 | -8.57 | 45.11 | 0.2037 | -753.0 | -540.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
