SDO HMI 2014-09-11 09:01:21 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 208.85 | 1202.41 | 105.02 | 604.32 | 15.98 | 87.68 | 3.90 | 336.74 | 0.1675 | 412.1 | 255.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-11 09:01:21 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.25 | 0.00 | 0.63 | 17.78 | 92.08 | 8.30 | 323.27 | 0.2310 | -716.0 | -563.0 | |
| 0.45 | 3.03 | 0.22 | 1.53 | 15.75 | 90.79 | 7.01 | 321.76 | 0.1906 | 1091.8 | 787.5 | |
| 0.00 | 0.98 | 0.00 | 0.50 | 17.65 | 90.67 | 6.89 | 327.82 | 0.2157 | 853.0 | 763.1 | |
| 0.00 | 2.67 | 0.00 | 1.35 | 17.17 | 90.40 | 6.62 | 327.56 | 0.2062 | 824.0 | 770.2 | |
| 0.00 | 1.25 | 0.00 | 0.63 | 15.00 | 90.32 | 6.54 | 320.99 | 0.1757 | -527.0 | -427.6 | |
| 0.00 | 1.60 | 0.00 | 0.80 | 12.69 | 90.13 | 6.35 | 311.61 | 0.1450 | -725.0 | -548.2 | |
| 0.00 | 1.51 | 0.00 | 0.77 | 17.66 | 90.00 | 6.22 | 330.38 | 0.2100 | 482.0 | 365.9 | |
| 0.00 | 3.74 | 0.00 | 1.88 | 13.49 | 89.87 | 6.09 | 316.71 | 0.1512 | -853.0 | -539.4 | |
| 0.00 | 1.87 | 0.00 | 0.94 | 12.61 | 89.82 | 6.04 | 312.57 | 0.1400 | -697.0 | -660.5 | |
| 0.00 | 1.07 | 0.00 | 0.53 | 11.49 | 89.73 | 5.95 | 306.37 | 0.1267 | -879.0 | -629.8 | |
| 3.56 | 24.86 | 1.81 | 12.61 | 18.00 | 89.82 | 6.04 | 331.90 | 0.2135 | 1190.7 | 612.8 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 16.53 | 89.77 | 5.99 | 328.32 | 0.1915 | 437.0 | 340.6 | |
| 2.14 | -11.00 | 1.08 | -11.00 | 18.16 | 89.76 | 5.99 | 332.47 | 0.2154 | 1027.0 | 999999 | |
| 0.00 | 5.97 | 0.00 | 2.98 | 12.34 | 89.59 | 5.81 | 312.14 | 0.1341 | -1076.0 | -752.4 | |
| 0.80 | 2.05 | 0.40 | 1.03 | 14.98 | 89.63 | 5.85 | 323.96 | 0.1682 | -967.2 | -757.4 | |
| 0.00 | 1.34 | 0.00 | 0.67 | 12.97 | 89.58 | 5.80 | 315.62 | 0.1414 | -923.0 | -645.1 | |
| 1.07 | -11.00 | 0.54 | -11.00 | 18.13 | 89.54 | 5.76 | 333.29 | 0.2132 | 1084.2 | 999999 | |
| 0.00 | 1.96 | 0.00 | 0.98 | 14.62 | 89.37 | 5.59 | 323.85 | 0.1605 | 935.0 | 788.0 | |
| 0.00 | 0.80 | 0.00 | 0.41 | 18.32 | 89.42 | 5.64 | 334.18 | 0.2151 | 849.0 | 732.1 | |
| 0.00 | 1.16 | 0.00 | 0.59 | 18.20 | 89.35 | 5.57 | 334.18 | 0.2128 | 1028.0 | 840.8 | |
| 0.00 | 3.47 | 0.00 | 1.76 | 17.86 | 89.24 | 5.47 | 333.88 | 0.2069 | 798.0 | 704.1 | |
| 0.00 | 1.34 | 0.00 | 0.67 | 13.59 | 89.12 | 5.35 | 320.83 | 0.1440 | -613.0 | -455.5 | |
| 0.00 | 0.53 | 0.00 | 0.27 | 13.19 | 89.05 | 5.27 | 319.37 | 0.1381 | -690.0 | -524.8 | |
| 0.00 | 1.07 | 0.00 | 0.54 | 17.46 | 89.14 | 5.36 | 333.42 | 0.2000 | -371.0 | -227.3 | |
| 4.81 | 15.95 | 2.44 | 8.10 | 18.78 | 89.05 | 5.27 | 336.57 | 0.2197 | 993.6 | 553.4 | |
| 0.00 | 1.25 | 0.00 | 0.62 | 12.89 | 88.83 | 5.05 | 319.10 | 0.1316 | -968.0 | -766.9 | |
| 0.00 | 1.51 | 0.00 | 0.77 | 18.60 | 88.85 | 5.07 | 337.01 | 0.2156 | 148.0 | 261.4 | |
| 8.46 | 32.70 | 4.23 | 16.35 | 13.35 | 88.56 | 4.78 | 322.83 | 0.1348 | -1073.0 | -460.4 | |
| 0.00 | 1.07 | 0.00 | 0.55 | 21.14 | 88.78 | 5.00 | 341.35 | 0.2552 | 845.0 | 726.8 | |
| 1.34 | 874.25 | 0.68 | 439.74 | 18.11 | 88.58 | 4.80 | 337.17 | 0.2061 | 839.4 | 472.6 | |
| 0.27 | -30.00 | 0.14 | -30.00 | 18.11 | 88.39 | 4.61 | 337.99 | 0.2049 | 934.0 | 999999 | |
| 1.25 | -30.00 | 0.63 | -30.00 | 17.90 | 88.35 | 4.58 | 337.74 | 0.2013 | 934.3 | 999999 | |
| 0.00 | 1.43 | 0.00 | 0.72 | 18.61 | 88.37 | 4.60 | 338.98 | 0.2126 | 467.0 | 321.9 | |
| 0.00 | 1.07 | 0.00 | 0.55 | 21.39 | 88.39 | 4.62 | 342.99 | 0.2573 | 751.0 | 585.7 | |
| 0.27 | -30.00 | 0.14 | -30.00 | 17.66 | 88.22 | 4.44 | 337.84 | 0.1966 | 969.7 | 999999 | |
| 75.82 | -30.00 | 38.07 | -30.00 | 15.55 | 88.11 | 4.33 | 333.35 | 0.1628 | 1639.8 | 999999 | |
| 2.67 | -30.00 | 1.35 | -30.00 | 18.12 | 88.07 | 4.29 | 339.38 | 0.2030 | 983.3 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.36 | 13.57 | 87.97 | 4.19 | 327.28 | 0.1321 | -609.0 | -406.2 | |
| 15.41 | -30.00 | 7.78 | -30.00 | 17.38 | 87.96 | 4.18 | 338.48 | 0.1906 | 1256.0 | 999999 | |
| 12.38 | -30.00 | 6.26 | -30.00 | 17.75 | 87.94 | 4.16 | 339.30 | 0.1963 | 1165.3 | 999999 | |
| 0.00 | 1.34 | 0.00 | 0.68 | 19.60 | 87.95 | 4.17 | 342.26 | 0.2261 | -797.0 | -640.3 | |
| 0.00 | 1.87 | 0.00 | 0.94 | 13.72 | 87.73 | 3.95 | 329.45 | 0.1322 | -873.0 | -516.4 | |
| 50.43 | -30.00 | 25.37 | -30.00 | 16.53 | 87.75 | 3.97 | 337.68 | 0.1756 | 1363.9 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.54 | 19.69 | 87.83 | 4.05 | 342.90 | 0.2270 | -655.0 | -447.9 | |
| 0.00 | 4.01 | 0.00 | 2.00 | 12.75 | 87.49 | 3.71 | 326.78 | 0.1158 | -1023.0 | -877.4 | |
| 0.00 | 0.98 | 0.00 | 0.50 | 20.00 | 87.64 | 3.86 | 344.03 | 0.2312 | 871.0 | 734.7 | |
| 0.00 | 1.96 | 0.00 | 0.97 | 9.52 | 87.29 | 3.51 | 303.55 | 0.0729 | -955.0 | -893.4 | |
| 1.25 | -30.00 | 0.63 | -30.00 | 16.17 | 87.21 | 3.43 | 339.72 | 0.1665 | 944.6 | 999999 | |
| 0.00 | 3.03 | 0.00 | 1.51 | 12.88 | 87.09 | 3.31 | 330.26 | 0.1140 | -786.0 | -706.3 | |
| 0.00 | 1.69 | 0.00 | 0.86 | 20.38 | 87.20 | 3.42 | 346.19 | 0.2354 | 813.0 | 589.5 | |
| 0.00 | 1.34 | 0.00 | 0.68 | 18.47 | 87.13 | 3.35 | 344.14 | 0.2036 | 168.0 | 147.1 | |
| 0.00 | 2.94 | 0.00 | 1.46 | 9.55 | 86.93 | 3.15 | 306.88 | 0.0680 | -1000.0 | -778.0 | |
| 0.00 | 1.07 | 0.00 | 0.55 | 23.66 | 87.12 | 3.34 | 349.31 | 0.2892 | 660.0 | 533.6 | |
| 0.00 | 1.60 | 0.00 | 0.81 | 19.45 | 86.83 | 3.05 | 346.68 | 0.2186 | 1016.0 | 843.6 | |
| 0.00 | 3.12 | 0.00 | 1.58 | 19.67 | 86.80 | 3.02 | 347.03 | 0.2221 | 1071.0 | 875.4 | |
| 0.00 | 1.43 | 0.00 | 0.71 | 12.43 | 86.68 | 2.90 | 331.39 | 0.1037 | -1134.0 | -883.2 | |
| 0.00 | 1.51 | 0.00 | 0.75 | 12.03 | 86.68 | 2.90 | 329.46 | 0.0978 | -988.0 | -722.5 | |
| 0.00 | 2.32 | 0.00 | 1.16 | 13.16 | 86.69 | 2.91 | 334.41 | 0.1151 | -752.0 | -620.8 | |
| 0.00 | 1.87 | 0.00 | 0.95 | 18.13 | 86.71 | 2.93 | 345.61 | 0.1962 | 956.0 | 721.7 | |
| 0.00 | 1.16 | 0.00 | 0.58 | 12.88 | 86.63 | 2.85 | 333.84 | 0.1103 | -940.0 | -747.8 | |
| 0.00 | 1.78 | 0.00 | 0.89 | 13.79 | 86.54 | 2.77 | 337.72 | 0.1242 | -684.0 | -541.3 | |
| 0.00 | 2.23 | 0.00 | 1.11 | 12.25 | 86.49 | 2.72 | 332.12 | 0.0995 | -957.0 | -923.6 | |
| 0.00 | 1.43 | 0.00 | 0.71 | 13.13 | 86.38 | 2.60 | 336.73 | 0.1124 | -940.0 | -731.6 | |
| 0.00 | 1.34 | 0.00 | 0.67 | 12.89 | 86.25 | 2.47 | 336.87 | 0.1077 | -1109.0 | -874.4 | |
| 0.00 | 1.51 | 0.00 | 0.75 | 10.25 | 86.10 | 2.33 | 322.88 | 0.0665 | -1017.0 | -763.1 | |
| 0.00 | 3.65 | 0.00 | 1.83 | 15.26 | 86.09 | 2.32 | 344.40 | 0.1457 | -118.0 | -110.7 | |
| 0.00 | 1.43 | 0.00 | 0.71 | 11.61 | 86.05 | 2.28 | 333.03 | 0.0862 | -936.0 | -713.5 | |
| 0.00 | 1.25 | 0.00 | 0.63 | 16.42 | 86.11 | 2.33 | 346.27 | 0.1651 | 678.0 | 430.4 | |
| 0.00 | 2.32 | 0.00 | 1.15 | 11.62 | 85.84 | 2.06 | 335.27 | 0.0846 | -1173.0 | -1015.0 | |
| 0.00 | 1.51 | 0.00 | 0.75 | 12.37 | 85.72 | 1.94 | 339.71 | 0.0960 | -1025.0 | -898.9 | |
| 0.00 | 16.13 | 0.00 | 8.06 | 14.53 | 85.71 | 1.93 | 345.58 | 0.1318 | -362.0 | -404.2 | |
| 0.00 | 2.85 | 0.00 | 1.42 | 11.59 | 85.53 | 1.75 | 338.47 | 0.0820 | -869.0 | -993.5 | |
| 0.00 | 1.69 | 0.00 | 0.84 | 10.53 | 85.49 | 1.71 | 332.92 | 0.0649 | -966.0 | -758.6 | |
| 0.00 | 1.16 | 0.00 | 0.58 | 14.17 | 85.49 | 1.71 | 346.51 | 0.1247 | -943.0 | -849.5 | |
| 0.00 | 1.25 | 0.00 | 0.62 | 11.01 | 85.46 | 1.69 | 336.34 | 0.0723 | -825.0 | -664.9 | |
| 0.00 | 1.78 | 0.00 | 0.88 | 10.29 | 85.46 | 1.68 | 331.55 | 0.0609 | -923.0 | -707.2 | |
| 0.00 | 6.86 | 0.00 | 3.45 | 16.51 | 85.39 | 1.61 | 350.53 | 0.1642 | 6.0 | 119.5 | |
| 0.62 | 12.12 | 0.31 | 6.04 | 13.62 | 85.33 | 1.55 | 346.69 | 0.1148 | -1248.6 | -969.2 | |
| 0.00 | 1.43 | 0.00 | 0.71 | 11.92 | 85.32 | 1.54 | 342.18 | 0.0862 | -1139.0 | -862.1 | |
| 0.00 | 1.60 | 0.00 | 0.80 | 14.44 | 85.31 | 1.53 | 348.38 | 0.1287 | -972.0 | -854.7 | |
| 3.39 | 66.47 | 1.70 | 33.28 | 15.45 | 85.19 | 1.41 | 350.57 | 0.1455 | 43.1 | -365.0 | |
| 0.71 | -78.00 | 0.36 | -78.00 | 13.71 | 85.18 | 1.40 | 348.15 | 0.1158 | -994.6 | 999999 | |
| 0.00 | 2.85 | 0.00 | 1.42 | 14.20 | 85.15 | 1.37 | 349.18 | 0.1240 | -1023.0 | -780.1 | |
| 0.00 | 4.01 | 0.00 | 2.02 | 16.85 | 85.07 | 1.30 | 352.62 | 0.1692 | -834.0 | -766.6 | |
| 2.05 | -81.00 | 1.03 | -81.00 | 15.81 | 85.00 | 1.22 | 352.15 | 0.1513 | -654.6 | 999999 | |
| 0.00 | 3.03 | 0.00 | 1.50 | 10.32 | 84.97 | 1.19 | 339.20 | 0.0578 | -943.0 | -787.8 | |
| 9.18 | 13.45 | 4.59 | 6.72 | 14.65 | 84.93 | 1.15 | 351.42 | 0.1312 | -1194.5 | -914.9 | |
| 3.12 | -81.00 | 1.56 | -81.00 | 15.14 | 84.84 | 1.06 | 352.58 | 0.1394 | -1104.2 | 999999 | |
| 6.42 | -81.00 | 3.21 | -81.00 | 15.36 | 84.84 | 1.06 | 352.77 | 0.1430 | -1251.7 | 999999 | |
| 0.98 | 5.35 | 0.49 | 2.68 | 16.24 | 84.82 | 1.04 | 353.65 | 0.1582 | -972.0 | -842.9 | |
| 0.00 | 4.45 | 0.00 | 2.21 | 11.83 | 84.73 | 0.95 | 348.53 | 0.0822 | -916.0 | -791.0 | |
| 0.00 | 1.43 | 0.00 | 0.71 | 12.26 | 84.73 | 0.95 | 349.47 | 0.0894 | -685.0 | -560.2 | |
| 0.00 | 1.96 | 0.00 | 0.97 | 11.99 | 84.48 | 0.71 | 351.72 | 0.0841 | -934.0 | -791.6 | |
| 0.00 | 1.43 | 0.00 | 0.71 | 11.29 | 84.45 | 0.67 | 350.75 | 0.0720 | -1106.0 | -831.3 | |
| 0.00 | 1.60 | 0.00 | 0.80 | 13.96 | 84.40 | 0.62 | 354.86 | 0.1181 | -1090.0 | -967.6 | |
| 0.00 | 1.51 | 0.00 | 0.75 | 13.11 | 84.06 | 0.28 | 357.37 | 0.1029 | -950.0 | -764.4 | |
| 0.00 | 0.80 | 0.00 | 0.40 | 16.64 | 83.56 | -0.22 | 1.28 | 0.1642 | -639.0 | -499.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
