SDO HMI 2014-09-12 02:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 155.71 | 719.48 | 90.34 | 415.77 | -14.21 | 96.54 | 22.13 | 225.24 | 0.5149 | -18.7 | -53.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-12 02:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.07 | 0.00 | 0.65 | -10.72 | 105.58 | 31.16 | 240.24 | 0.5879 | 639.0 | 522.8 | |
| 3.56 | 20.39 | 2.20 | 12.57 | -12.35 | 105.64 | 31.22 | 237.90 | 0.5999 | 727.9 | 566.0 | |
| 0.00 | 1.87 | 0.00 | 1.14 | -10.90 | 105.46 | 31.04 | 239.87 | 0.5876 | 785.0 | 649.7 | |
| 0.00 | 0.62 | 0.00 | 0.38 | -10.01 | 105.36 | 30.94 | 241.14 | 0.5803 | 643.0 | 412.4 | |
| 0.00 | 1.16 | 0.00 | 0.70 | -10.26 | 105.31 | 30.90 | 240.72 | 0.5815 | 751.0 | 560.6 | |
| 1.69 | -2.00 | 1.04 | -2.00 | -12.17 | 105.40 | 30.98 | 237.96 | 0.5958 | 920.6 | 999999 | |
| 22.79 | 55.29 | 13.90 | 33.67 | -11.87 | 104.71 | 30.29 | 237.82 | 0.5855 | 951.3 | 603.2 | |
| 0.00 | 2.05 | 0.00 | 1.25 | -12.42 | 104.28 | 29.86 | 236.64 | 0.5844 | 775.0 | 644.4 | |
| 0.00 | 0.71 | 0.00 | 0.43 | -12.01 | 103.52 | 29.10 | 236.54 | 0.5724 | 811.0 | 683.1 | |
| 0.00 | 0.62 | 0.00 | 0.38 | -12.67 | 103.35 | 28.93 | 235.42 | 0.5755 | 476.0 | 391.6 | |
| 0.00 | 2.85 | 0.00 | 1.72 | -12.09 | 103.28 | 28.86 | 236.21 | 0.5702 | 882.0 | 742.4 | |
| 0.00 | 0.89 | 0.00 | 0.54 | -12.57 | 103.23 | 28.82 | 235.46 | 0.5733 | 614.0 | 550.2 | |
| 0.45 | 13.53 | 0.27 | 8.13 | -12.40 | 103.14 | 28.73 | 235.62 | 0.5709 | 881.2 | 797.2 | |
| 0.00 | 0.62 | 0.00 | 0.38 | -12.99 | 103.21 | 28.80 | 234.84 | 0.5763 | 444.0 | 352.6 | |
| 0.00 | 1.34 | 0.00 | 0.79 | -10.73 | 102.89 | 28.47 | 237.90 | 0.5550 | 848.0 | 734.2 | |
| 0.00 | 0.62 | 0.00 | 0.38 | -14.84 | 103.40 | 28.98 | 232.40 | 0.5933 | 648.0 | 493.9 | |
| 4.10 | -13.00 | 2.46 | -13.00 | -12.11 | 102.97 | 28.55 | 235.90 | 0.5665 | 1072.7 | 999999 | |
| 1.25 | -13.00 | 0.75 | -13.00 | -12.33 | 102.99 | 28.58 | 235.59 | 0.5686 | 917.7 | 999999 | |
| 1.42 | 5.25 | 0.86 | 3.17 | -13.16 | 102.99 | 28.57 | 234.37 | 0.5752 | 736.8 | 673.1 | |
| 0.00 | 0.89 | 0.00 | 0.54 | -12.55 | 102.84 | 28.42 | 235.13 | 0.5685 | 698.0 | 649.4 | |
| 0.00 | 1.25 | 0.00 | 0.74 | -11.42 | 102.68 | 28.26 | 236.66 | 0.5577 | 691.0 | 591.1 | |
| 0.00 | 2.67 | 0.00 | 1.60 | -12.31 | 102.71 | 28.29 | 235.34 | 0.5651 | 909.0 | 825.9 | |
| 0.00 | 1.34 | 0.00 | 0.81 | -13.50 | 102.71 | 28.30 | 233.62 | 0.5747 | 649.0 | 548.3 | |
| 0.00 | 0.62 | 0.00 | 0.38 | -15.26 | 102.92 | 28.50 | 231.36 | 0.5917 | 622.0 | 526.4 | |
| 0.00 | 1.69 | 0.00 | 1.02 | -13.72 | 102.60 | 28.18 | 233.20 | 0.5752 | 745.0 | 615.9 | |
| 0.00 | 2.14 | 0.00 | 1.28 | -12.33 | 102.43 | 28.01 | 235.05 | 0.5619 | 694.0 | 555.7 | |
| 0.00 | 0.98 | 0.00 | 0.58 | -11.97 | 102.32 | 27.90 | 235.48 | 0.5577 | 800.0 | 625.4 | |
| 0.00 | 0.98 | 0.00 | 0.59 | -13.36 | 102.48 | 28.07 | 233.60 | 0.5709 | 876.0 | 698.7 | |
| 0.00 | 2.40 | 0.00 | 1.44 | -13.09 | 102.31 | 27.89 | 233.82 | 0.5667 | 889.0 | 728.8 | |
| 0.00 | 1.87 | 0.00 | 1.12 | -13.47 | 102.25 | 27.84 | 233.21 | 0.5692 | 642.0 | 548.9 | |
| 0.00 | 0.80 | 0.00 | 0.48 | -12.43 | 102.06 | 27.64 | 234.54 | 0.5584 | 718.0 | 591.2 | |
| 0.00 | 1.51 | 0.00 | 0.90 | -12.86 | 101.79 | 27.38 | 233.63 | 0.5589 | 759.0 | 562.6 | |
| 0.00 | 0.98 | 0.00 | 0.59 | -13.93 | 101.85 | 27.44 | 232.15 | 0.5685 | 296.0 | 260.9 | |
| 0.00 | 0.53 | 0.00 | 0.31 | -12.27 | 100.96 | 26.54 | 233.67 | 0.5442 | 791.0 | 664.3 | |
| 0.00 | 1.51 | 0.00 | 0.89 | -12.36 | 100.42 | 26.00 | 232.96 | 0.5386 | 886.0 | 798.2 | |
| 0.00 | 0.89 | 0.00 | 0.51 | -10.20 | 99.29 | 24.88 | 235.14 | 0.5066 | 805.0 | 703.2 | |
| 0.00 | 0.45 | 0.00 | 0.26 | -14.28 | 99.02 | 24.60 | 228.59 | 0.5401 | 765.0 | 676.4 | |
| 0.00 | 1.51 | 0.00 | 0.89 | -14.46 | 98.90 | 24.49 | 228.19 | 0.5406 | 734.0 | 688.5 | |
| 0.00 | 2.40 | 0.00 | 1.45 | -17.10 | 99.21 | 24.79 | 224.97 | 0.5692 | 584.0 | 388.7 | |
| 0.00 | 2.58 | 0.00 | 1.52 | -14.72 | 98.87 | 24.45 | 227.78 | 0.5426 | 823.0 | 644.6 | |
| 0.00 | 1.42 | 0.00 | 0.85 | -16.99 | 98.99 | 24.57 | 224.86 | 0.5659 | 417.0 | 383.9 | |
| 1.42 | 3.12 | 0.84 | 1.83 | -14.45 | 98.63 | 24.21 | 227.89 | 0.5374 | 904.4 | 697.8 | |
| 0.00 | 1.07 | 0.00 | 0.62 | -12.50 | 98.32 | 23.90 | 230.39 | 0.5155 | -680.0 | -596.0 | |
| 0.00 | 1.16 | 0.00 | 0.66 | -11.66 | 98.17 | 23.75 | 231.51 | 0.5060 | -583.0 | -415.5 | |
| 0.00 | 1.60 | 0.00 | 0.95 | -15.62 | 98.53 | 24.11 | 226.15 | 0.5477 | 154.0 | 147.1 | |
| 5.88 | 38.02 | 3.48 | 22.49 | -16.04 | 98.55 | 24.13 | 225.60 | 0.5521 | 741.7 | 583.2 | |
| 0.00 | 2.40 | 0.00 | 1.41 | -14.50 | 98.36 | 23.94 | 227.50 | 0.5350 | 847.0 | 694.1 | |
| 0.00 | 0.89 | 0.00 | 0.51 | -12.29 | 97.99 | 23.58 | 230.32 | 0.5098 | -703.0 | -580.9 | |
| 0.00 | 1.51 | 0.00 | 0.87 | -12.58 | 97.95 | 23.54 | 229.84 | 0.5120 | -696.0 | -638.9 | |
| 4.90 | -46.00 | 2.89 | -46.00 | -15.83 | 98.28 | 23.86 | 225.56 | 0.5472 | 952.1 | 999999 | |
| 0.00 | 1.78 | 0.00 | 1.04 | -14.71 | 98.15 | 23.73 | 226.94 | 0.5348 | 799.0 | 714.1 | |
| 0.00 | 2.31 | 0.00 | 1.33 | -12.77 | 97.90 | 23.49 | 229.49 | 0.5133 | -691.0 | -588.3 | |
| 0.00 | 0.80 | 0.00 | 0.46 | -12.50 | 97.74 | 23.33 | 229.70 | 0.5089 | -629.0 | -527.8 | |
| 0.00 | 0.80 | 0.00 | 0.47 | -14.87 | 97.96 | 23.54 | 226.50 | 0.5343 | 486.0 | 482.1 | |
| 3.29 | -46.00 | 1.94 | -46.00 | -15.95 | 98.02 | 23.60 | 225.09 | 0.5457 | 952.6 | 999999 | |
| 0.62 | -46.00 | 0.37 | -46.00 | -15.81 | 97.97 | 23.55 | 225.21 | 0.5438 | 1011.6 | 999999 | |
| 0.53 | 4.18 | 0.31 | 2.41 | -12.85 | 97.61 | 23.19 | 229.01 | 0.5107 | -906.7 | -754.4 | |
| 0.00 | 1.96 | 0.00 | 1.14 | -14.56 | 97.75 | 23.34 | 226.68 | 0.5291 | 835.0 | 668.0 | |
| 0.00 | 0.98 | 0.00 | 0.56 | -12.29 | 97.42 | 23.00 | 229.62 | 0.5032 | -502.0 | -468.5 | |
| 0.00 | 0.98 | 0.00 | 0.57 | -14.68 | 97.53 | 23.11 | 226.23 | 0.5279 | 706.0 | 574.9 | |
| 0.00 | 1.69 | 0.00 | 0.97 | -12.73 | 97.30 | 22.88 | 228.79 | 0.5061 | -835.0 | -748.8 | |
| 5.08 | 21.46 | 2.92 | 12.38 | -13.38 | 97.29 | 22.87 | 227.82 | 0.5123 | -847.1 | -133.9 | |
| 0.00 | 1.78 | 0.00 | 1.02 | -12.34 | 97.12 | 22.71 | 229.18 | 0.5003 | -710.0 | -675.6 | |
| 0.00 | 1.07 | 0.00 | 0.61 | -12.66 | 97.15 | 22.74 | 228.72 | 0.5038 | -858.0 | -741.1 | |
| 0.00 | 5.97 | 0.00 | 3.48 | -15.13 | 97.38 | 22.96 | 225.42 | 0.5307 | 549.0 | 610.2 | |
| 0.00 | 1.78 | 0.00 | 1.01 | -11.76 | 97.04 | 22.62 | 229.98 | 0.4937 | -747.0 | -520.8 | |
| 0.00 | 0.80 | 0.00 | 0.46 | -12.05 | 97.06 | 22.65 | 229.56 | 0.4968 | -656.0 | -530.9 | |
| 1.34 | 2.58 | 0.76 | 1.48 | -12.81 | 96.97 | 22.55 | 228.26 | 0.5032 | -777.6 | -589.1 | |
| 0.00 | 1.69 | 0.00 | 0.97 | -12.52 | 96.87 | 22.46 | 228.59 | 0.4992 | -866.0 | -748.8 | |
| 0.00 | 1.25 | 0.00 | 0.71 | -11.88 | 96.82 | 22.40 | 229.51 | 0.4923 | -732.0 | -612.6 | |
| 0.00 | 1.51 | 0.00 | 0.88 | -15.51 | 97.11 | 22.70 | 224.57 | 0.5319 | 577.0 | 522.1 | |
| 0.00 | 0.80 | 0.00 | 0.46 | -12.73 | 96.69 | 22.27 | 228.03 | 0.4993 | -806.0 | -662.9 | |
| 0.00 | 1.69 | 0.00 | 0.97 | -12.99 | 96.65 | 22.23 | 227.59 | 0.5013 | -822.0 | -717.3 | |
| 0.00 | 0.98 | 0.00 | 0.56 | -11.99 | 96.56 | 22.14 | 229.00 | 0.4905 | -784.0 | -611.0 | |
| 0.00 | 1.25 | 0.00 | 0.73 | -15.46 | 96.80 | 22.39 | 224.25 | 0.5281 | 799.0 | 656.5 | |
| 0.00 | 0.80 | 0.00 | 0.46 | -14.70 | 96.62 | 22.20 | 225.06 | 0.5184 | 755.0 | 630.6 | |
| 0.00 | 1.34 | 0.00 | 0.77 | -13.52 | 96.40 | 21.98 | 226.47 | 0.5040 | -710.0 | -558.7 | |
| 0.00 | 1.69 | 0.00 | 0.98 | -14.92 | 96.44 | 22.02 | 224.52 | 0.5188 | 699.0 | 579.2 | |
| 1.51 | 6.77 | 0.88 | 3.93 | -15.34 | 96.42 | 22.00 | 223.91 | 0.5230 | 1029.5 | 820.6 | |
| 0.00 | 2.23 | 0.00 | 1.29 | -15.60 | 96.45 | 22.03 | 223.59 | 0.5260 | 798.0 | 622.8 | |
| 0.00 | 1.60 | 0.00 | 0.92 | -13.97 | 96.27 | 21.86 | 225.65 | 0.5072 | 596.0 | 348.1 | |
| 0.00 | 1.25 | 0.00 | 0.73 | -16.55 | 96.42 | 22.00 | 222.30 | 0.5358 | 512.0 | 571.9 | |
| 0.62 | 5.43 | 0.36 | 3.16 | -16.02 | 96.32 | 21.91 | 222.87 | 0.5292 | 751.4 | 642.8 | |
| 0.00 | 1.16 | 0.00 | 0.64 | -8.34 | 95.61 | 21.19 | 233.95 | 0.4442 | -154.0 | -149.6 | |
| 8.81 | 27.96 | 5.12 | 16.21 | -15.81 | 96.00 | 21.58 | 222.73 | 0.5236 | 953.1 | 428.8 | |
| 0.00 | 0.80 | 0.00 | 0.45 | -12.71 | 95.59 | 21.17 | 226.61 | 0.4868 | -763.0 | -626.7 | |
| 1.51 | 344.83 | 0.87 | 195.13 | -14.64 | 95.40 | 20.99 | 223.54 | 0.5051 | 561.9 | -425.0 | |
| 3.65 | -87.00 | 2.08 | -87.00 | -14.28 | 94.67 | 20.25 | 223.03 | 0.4936 | -858.2 | 999999 | |
| 0.00 | 2.49 | 0.00 | 1.44 | -15.85 | 94.76 | 20.34 | 221.00 | 0.5117 | -57.0 | -24.3 | |
| 0.00 | 1.25 | 0.00 | 0.71 | -14.79 | 94.62 | 20.20 | 222.23 | 0.4987 | -612.0 | -478.7 | |
| 0.00 | 1.69 | 0.00 | 0.97 | -15.32 | 94.64 | 20.22 | 221.54 | 0.5047 | -784.0 | -677.4 | |
| 0.00 | 0.71 | 0.00 | 0.42 | -17.90 | 94.89 | 20.47 | 218.57 | 0.5359 | -602.0 | -545.0 | |
| 2.31 | -87.00 | 1.31 | -87.00 | -13.94 | 94.44 | 20.02 | 223.18 | 0.4876 | -938.8 | 999999 | |
| 0.00 | 1.96 | 0.00 | 1.15 | -18.10 | 94.88 | 20.46 | 218.31 | 0.5381 | -582.0 | -489.0 | |
| 0.00 | 1.25 | 0.00 | 0.73 | -18.48 | 94.58 | 20.17 | 217.45 | 0.5398 | -653.0 | -557.4 | |
| 0.00 | 1.34 | 0.00 | 0.75 | -12.99 | 93.96 | 19.54 | 223.89 | 0.4721 | -680.0 | -511.4 | |
| 29.92 | -87.00 | 16.94 | -87.00 | -14.25 | 94.00 | 19.59 | 222.12 | 0.4864 | -1088.8 | 999999 | |
| 1.16 | 4.72 | 0.68 | 2.75 | -17.84 | 94.34 | 19.92 | 217.89 | 0.5302 | -923.2 | -705.1 | |
| 0.00 | 1.07 | 0.00 | 0.62 | -16.34 | 94.17 | 19.76 | 219.53 | 0.5117 | -772.0 | -620.1 | |
| 2.67 | -87.00 | 1.52 | -87.00 | -14.73 | 93.88 | 19.46 | 221.26 | 0.4906 | -661.5 | 999999 | |
| 8.99 | 40.51 | 5.14 | 23.13 | -15.73 | 93.78 | 19.36 | 219.75 | 0.5010 | 840.9 | 145.4 | |
| 0.00 | 0.98 | 0.00 | 0.57 | -17.52 | 93.97 | 19.55 | 217.75 | 0.5232 | -481.0 | -405.8 | |
| 2.49 | -87.00 | 1.41 | -87.00 | -14.26 | 93.51 | 19.09 | 221.37 | 0.4815 | -1171.9 | 999999 | |
| 0.27 | -87.00 | 0.15 | -87.00 | -14.75 | 93.55 | 19.13 | 220.76 | 0.4875 | -637.7 | 999999 | |
| 1.16 | -87.00 | 0.65 | -87.00 | -14.00 | 93.45 | 19.04 | 221.66 | 0.4780 | -1018.5 | 999999 | |
| 0.00 | 0.80 | 0.00 | 0.45 | -13.12 | 93.38 | 18.96 | 222.83 | 0.4675 | -637.0 | -507.6 | |
| 0.00 | 1.25 | 0.00 | 0.70 | -13.41 | 93.31 | 18.89 | 222.29 | 0.4699 | -345.0 | -271.5 | |
| 0.00 | 1.16 | 0.00 | 0.65 | -12.86 | 93.23 | 18.81 | 222.99 | 0.4629 | -716.0 | -655.2 | |
| 0.00 | 1.34 | 0.00 | 0.78 | -18.84 | 93.68 | 19.26 | 215.78 | 0.5360 | -559.0 | -533.1 | |
| 30.45 | -87.00 | 17.18 | -87.00 | -14.44 | 93.16 | 18.74 | 220.60 | 0.4801 | -1152.9 | 999999 | |
| 1.87 | -87.00 | 1.06 | -87.00 | -14.82 | 92.96 | 18.55 | 219.78 | 0.4826 | -661.8 | 999999 | |
| 0.00 | 1.07 | 0.00 | 0.61 | -17.55 | 92.40 | 17.98 | 215.43 | 0.5097 | -653.0 | -491.2 | |
| 0.00 | 0.98 | 0.00 | 0.56 | -16.49 | 92.26 | 17.84 | 216.52 | 0.4957 | 552.0 | 436.5 | |
| 0.00 | 0.62 | 0.00 | 0.36 | -17.35 | 92.21 | 17.79 | 215.40 | 0.5055 | -799.0 | -706.9 | |
| 0.00 | 0.71 | 0.00 | 0.41 | -16.75 | 92.12 | 17.70 | 215.98 | 0.4975 | -809.0 | -738.5 | |
| 0.00 | 0.98 | 0.00 | 0.55 | -16.07 | 91.76 | 17.34 | 216.26 | 0.4862 | -680.0 | -624.9 | |
| 0.00 | 0.98 | 0.00 | 0.55 | -15.73 | 91.50 | 17.08 | 216.28 | 0.4797 | -839.0 | -757.9 | |
| 0.00 | 1.16 | 0.00 | 0.65 | -15.30 | 91.33 | 16.91 | 216.57 | 0.4729 | -745.0 | -605.7 | |
| 0.00 | 0.98 | 0.00 | 0.57 | -19.87 | 91.78 | 17.36 | 211.92 | 0.5328 | -653.0 | -471.3 | |
| 0.00 | 1.78 | 0.00 | 1.03 | -19.32 | 91.55 | 17.13 | 212.16 | 0.5242 | -878.0 | -720.3 | |
| 0.00 | 1.69 | 0.00 | 0.95 | -16.09 | 89.53 | 15.12 | 212.59 | 0.4671 | -705.0 | -536.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
