SDO HMI 2014-09-12 10:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.71 | 30.99 | 0.53 | 21.55 | -20.00 | 105.82 | 35.78 | 231.57 | 0.7029 | 216.9 | 297.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-12 10:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.71 | 2.05 | 0.53 | 1.51 | -20.04 | 110.10 | 40.06 | 234.56 | 0.7445 | 632.5 | 492.7 | |
| 0.00 | 1.07 | 0.00 | 0.79 | -20.23 | 109.94 | 39.91 | 234.24 | 0.7442 | 527.0 | 451.5 | |
| 0.00 | 0.89 | 0.00 | 0.61 | -16.15 | 107.56 | 37.53 | 237.57 | 0.6955 | 548.0 | 425.8 | |
| 0.00 | 4.18 | 0.00 | 2.96 | -20.22 | 106.97 | 36.94 | 232.22 | 0.7159 | 765.0 | 634.0 | |
| 0.00 | 1.51 | 0.00 | 1.08 | -20.83 | 107.11 | 37.08 | 231.60 | 0.7213 | 546.0 | 419.6 | |
| 0.00 | 1.42 | 0.00 | 1.01 | -20.83 | 106.66 | 36.63 | 231.28 | 0.7171 | 445.0 | 415.9 | |
| 0.00 | 1.16 | 0.00 | 0.86 | -23.76 | 107.53 | 37.50 | 228.61 | 0.7449 | 604.0 | 436.1 | |
| 0.00 | 4.01 | 0.00 | 2.79 | -19.72 | 106.24 | 36.21 | 232.27 | 0.7054 | 697.0 | 562.7 | |
| 0.00 | 0.62 | 0.00 | 0.46 | -23.96 | 107.52 | 37.48 | 228.38 | 0.7462 | 392.0 | 372.3 | |
| 0.00 | 0.36 | 0.00 | 0.25 | -19.23 | 106.03 | 36.00 | 232.70 | 0.7001 | 548.0 | 465.8 | |
| 0.00 | 0.62 | 0.00 | 0.46 | -23.74 | 106.94 | 36.91 | 228.20 | 0.7397 | 338.0 | 353.4 | |
| 0.00 | 1.07 | 0.00 | 0.73 | -18.98 | 105.34 | 35.31 | 232.48 | 0.6914 | 499.0 | 443.3 | |
| 0.00 | 1.25 | 0.00 | 0.85 | -18.73 | 105.20 | 35.17 | 232.67 | 0.6883 | 494.0 | 636.4 | |
| 0.00 | 1.96 | 0.00 | 1.36 | -20.47 | 105.48 | 35.45 | 230.82 | 0.7033 | 633.0 | 556.0 | |
| 0.00 | 1.34 | 0.00 | 0.91 | -18.82 | 105.07 | 35.03 | 232.46 | 0.6876 | 677.0 | 606.7 | |
| 0.00 | 0.80 | 0.00 | 0.55 | -20.28 | 104.80 | 34.77 | 230.51 | 0.6954 | 551.0 | 512.1 | |
| 0.00 | 1.16 | 0.00 | 0.76 | -18.86 | 102.50 | 32.47 | 230.34 | 0.6622 | -786.0 | -576.1 | |
| 0.00 | 0.98 | 0.00 | 0.65 | -19.06 | 102.51 | 32.47 | 230.10 | 0.6638 | -702.0 | -560.0 | |
| 0.00 | 0.71 | 0.00 | 0.46 | -18.27 | 101.66 | 31.63 | 230.35 | 0.6490 | -506.0 | -581.2 | |
| 0.00 | 0.98 | 0.00 | 0.66 | -21.96 | 102.28 | 32.24 | 226.49 | 0.6845 | -581.0 | -486.9 | |
| 0.00 | 1.60 | 0.00 | 1.04 | -18.37 | 101.27 | 31.24 | 229.88 | 0.6459 | -707.0 | -617.2 | |
| 0.00 | 1.25 | 0.00 | 0.80 | -18.25 | 100.51 | 30.47 | 229.34 | 0.6372 | -647.0 | -511.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
