group	Proj. U	Proj. WS	Corr. U	Corr. WS	B	L	LCM	Pos. angle	r	MU	MP
12158	160.10	850.58	86.17	457.06	15.89	87.66	21.48	294.19	0.3890	566.3	287.3

previous   or   next   observation for the same group / back to the solar disc SDO HMI 2014-09-12 17:00:35 UT See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!)

spot	Proj. U	Proj. WS	Corr. U	Corr. WS	B	L	LCM	Pos. angle	r	MU	MP
1	0.00	1.33	0.00	0.74	10.01	92.31	26.13	278.04	0.4398	-612.0	-458.2
2	0.00	1.07	0.00	0.58	10.39	90.34	24.16	279.31	0.4097	-834.0	-634.2
3	0.00	1.69	0.00	0.93	16.19	90.53	24.35	292.82	0.4313	922.0	736.0
4	0.00	1.87	0.00	1.01	9.34	89.62	23.45	276.84	0.3971	-914.0	-761.1
5	1.33	4.54	0.73	2.49	17.68	90.25	24.07	296.27	0.4352	780.7	726.5
6	0.00	2.85	0.00	1.56	18.03	90.13	23.95	297.11	0.4354	215.0	286.8
7	0.00	3.02	0.00	1.66	17.11	89.96	23.78	295.26	0.4279	764.0	594.7
8	0.00	1.78	0.00	0.96	12.35	89.34	23.16	284.47	0.3985	-837.0	-648.3
9	0.00	0.98	0.00	0.53	13.29	89.43	23.26	286.73	0.4030	-616.0	-429.8
10	1.33	2.85	0.73	1.56	17.88	89.97	23.79	296.93	0.4324	852.2	729.8
11	0.00	1.60	0.00	0.88	18.10	89.86	23.68	297.49	0.4322	791.0	645.3
12	0.00	2.05	0.00	1.12	17.31	89.75	23.57	295.86	0.4260	784.0	482.1
13	2.05	5.25	1.12	2.88	18.41	89.87	23.69	298.15	0.4342	796.7	611.7
14	0.53	1.60	0.29	0.88	18.02	89.61	23.43	297.54	0.4282	978.3	868.6
15	0.00	1.25	0.00	0.67	10.86	88.74	22.56	280.94	0.3855	-798.0	-636.2
16	0.00	0.80	0.00	0.44	17.81	89.47	23.29	297.19	0.4250	769.0	596.6
17	0.00	0.80	0.00	0.43	14.16	88.95	22.77	289.14	0.3990	33.0	8.4
18	0.00	1.78	0.00	0.96	13.05	88.70	22.53	286.53	0.3910	-749.0	-667.3
19	0.53	3.20	0.29	1.72	13.29	88.69	22.52	287.15	0.3917	-735.7	-606.1
20	0.00	1.07	0.00	0.57	13.67	88.50	22.32	288.20	0.3901	825.0	697.2
21	0.00	1.87	0.00	1.00	13.22	88.39	22.21	287.13	0.3867	-828.0	-666.3
22	0.00	1.25	0.00	0.68	18.96	88.70	22.52	300.38	0.4217	533.0	527.3
23	0.00	1.25	0.00	0.67	13.18	87.95	21.77	287.29	0.3798	-622.0	-485.2
24	71.25	657.60	38.32	353.89	15.15	88.12	21.94	292.12	0.3909	1547.2	470.8
25	0.00	1.42	0.00	0.76	11.79	87.79	21.61	283.74	0.3727	-602.0	-452.3
26	0.00	1.16	0.00	0.63	18.87	88.52	22.34	300.38	0.4186	758.0	575.2
27	0.00	2.49	0.00	1.33	11.31	87.65	21.47	282.52	0.3693	-823.0	-715.8
28	0.00	1.78	0.00	0.95	11.77	87.59	21.41	283.78	0.3695	-951.0	-817.7
29	0.00	0.71	0.00	0.38	11.59	87.48	21.30	283.36	0.3672	-931.0	-807.9
30	8.18	-24.00	4.43	-24.00	18.13	88.04	21.86	299.19	0.4070	970.9	999999
31	0.00	1.51	0.00	0.80	11.20	87.31	21.13	282.38	0.3636	-809.0	-772.3
32	0.00	1.69	0.00	0.93	21.27	88.50	22.32	305.38	0.4359	708.0	597.6
33	0.00	0.89	0.00	0.47	11.36	87.23	21.05	282.84	0.3627	-718.0	-615.0
34	1.78	18.50	0.97	10.07	19.61	88.07	21.89	302.40	0.4178	-944.8	-331.0
35	0.27	-24.00	0.14	-24.00	15.66	87.57	21.39	293.82	0.3855	1030.7	999999
36	22.33	-24.00	12.07	-24.00	17.86	87.76	21.58	298.85	0.4015	1186.1	999999
37	0.98	19.21	0.52	10.24	13.09	87.17	20.99	287.54	0.3676	-874.7	-446.3
38	27.22	-24.00	14.62	-24.00	16.37	87.45	21.27	295.65	0.3877	1219.9	999999
39	3.91	-24.00	2.11	-24.00	16.89	87.51	21.33	296.84	0.3917	957.2	999999
40	4.54	-24.00	2.44	-24.00	17.08	87.46	21.28	297.32	0.3922	1010.4	999999
41	0.00	1.87	0.00	0.99	10.59	86.84	20.66	280.87	0.3547	-883.0	-712.0
42	0.00	0.98	0.00	0.52	12.80	86.98	20.80	286.87	0.3635	-842.0	-649.5
43	0.80	-24.00	0.43	-24.00	17.51	87.45	21.27	298.34	0.3947	1070.7	999999
44	0.00	1.07	0.00	0.56	9.18	86.68	20.50	276.90	0.3498	-573.0	-496.2
45	2.76	-24.00	1.49	-24.00	17.78	87.45	21.27	298.99	0.3965	1142.6	999999
46	0.00	1.07	0.00	0.56	6.92	86.52	20.34	270.39	0.3467	-808.0	-584.9
47	1.25	-24.00	0.67	-24.00	15.72	86.94	20.76	294.51	0.3765	1120.6	999999
48	0.00	5.96	0.00	3.15	10.03	86.41	20.23	279.44	0.3466	-1011.0	-880.2
49	0.00	4.36	0.00	2.36	19.06	87.27	21.09	302.05	0.4030	688.0	604.5
50	0.00	0.98	0.00	0.52	11.22	86.29	20.12	282.88	0.3475	-940.0	-778.4
51	2.22	4.36	1.20	2.35	18.36	86.94	20.76	300.83	0.3935	1034.9	789.1
52	0.00	3.47	0.00	1.85	15.98	86.63	20.45	295.44	0.3735	819.0	612.8
53	0.00	2.22	0.00	1.17	11.11	86.09	19.91	282.65	0.3440	-653.0	-534.8
54	0.00	1.60	0.00	0.85	13.38	86.21	20.03	288.97	0.3538	-565.0	-560.6
55	0.00	3.38	0.00	1.82	18.71	86.78	20.60	301.80	0.3938	859.0	684.9
56	0.00	1.16	0.00	0.62	17.96	86.32	20.14	300.57	0.3820	815.0	635.6
57	0.00	5.34	0.00	2.82	13.42	85.81	19.64	289.39	0.3480	-640.0	-820.3
58	0.00	1.51	0.00	0.80	13.67	85.70	19.53	290.16	0.3475	-874.0	-735.6
59	0.00	2.13	0.00	1.12	12.46	85.57	19.39	286.85	0.3402	-710.0	-623.5
60	0.00	2.49	0.00	1.31	11.95	85.47	19.29	285.44	0.3367	-1030.0	-801.7
61	0.00	1.07	0.00	0.56	14.71	85.67	19.49	293.03	0.3521	746.0	583.2
62	0.00	1.33	0.00	0.70	14.29	85.50	19.32	292.04	0.3473	671.0	616.3
63	0.00	1.25	0.00	0.65	12.53	85.31	19.14	287.23	0.3365	-977.0	-829.3
64	0.00	0.89	0.00	0.47	10.87	85.13	18.95	282.43	0.3280	-880.0	-786.3
65	0.00	1.25	0.00	0.65	12.21	85.09	18.91	286.44	0.3318	-999.0	-838.6
66	0.00	1.07	0.00	0.56	11.79	85.00	18.82	285.25	0.3287	-937.0	-723.2
67	0.00	1.51	0.00	0.79	10.65	84.82	18.64	281.88	0.3224	-932.0	-704.8
68	0.00	1.51	0.00	0.81	20.00	85.52	19.34	306.19	0.3873	947.0	758.2
69	3.02	4.45	1.59	2.34	14.50	84.82	18.64	293.25	0.3383	-1011.0	-776.9
70	2.31	18.95	1.22	9.98	14.87	84.76	18.58	294.34	0.3394	-1073.6	-406.2
71	1.51	4.89	0.79	2.57	13.74	84.66	18.48	291.26	0.3318	-1030.4	-820.7
72	0.00	0.98	0.00	0.52	15.93	84.86	18.68	297.11	0.3475	-775.0	-635.5
73	0.00	1.16	0.00	0.61	13.87	84.47	18.29	291.80	0.3297	-941.0	-731.1
74	0.00	2.05	0.00	1.10	20.72	85.21	19.03	308.18	0.3896	739.0	572.7
75	0.00	3.91	0.00	2.04	12.46	84.14	17.96	287.89	0.3177	-857.0	-807.0
76	0.00	2.58	0.00	1.34	12.29	83.90	17.72	287.55	0.3132	-1020.0	-781.4
77	0.00	0.53	0.00	0.28	14.47	82.37	16.19	295.86	0.3014	-780.0	-526.8
78	0.00	1.25	0.00	0.65	14.84	82.21	16.03	297.21	0.3014	-860.0	-720.4
79	0.00	1.33	0.00	0.69	14.49	81.89	15.71	296.54	0.2943	-932.0	-764.3
80	0.00	1.96	0.00	1.01	14.28	81.58	15.40	296.30	0.2884	-776.0	-602.2

	Proj. U	-  Projected umbra area in millionths of solar disc, negative values indicate
	that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2.
	Proj. WS	-  Projected whole spot area in millionths of solar disc, negative values indicate
	that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7.
	Corr. U	-  Corrected umbra area in millionths of solar hemisphere, for negative values see above
	Corr. WS	-  Corrected whole spot area in millionths of solar hemisphere, for negative values see above
	B	-  Heliographic latitude B; positive: North, negative: South
	L	-  Heliographic longitude L
	LCM	-  Longitudinal distance from the Sun's central meridian
	Pos. angle	-  Position angle
	r	-  Distance from the centre of Sun's disc in terms of Sun's radius
	MU	-  Mean magnetic field within the umbra contour averaged the pixel values with sign.
	MP	-  Mean magnetic field within the penumbra contour averaged the pixel values with sign.
