SDO HMI 2014-09-14 12:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 98.26 | 491.29 | 69.42 | 346.33 | 15.38 | 88.12 | 45.60 | 284.53 | 0.7141 | 460.1 | 275.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-14 12:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.07 | 0.00 | 0.79 | 12.14 | 91.33 | 48.80 | 279.87 | 0.7489 | -609.0 | -504.7 | |
| 0.00 | 0.71 | 0.00 | 0.51 | 9.69 | 89.78 | 47.25 | 276.55 | 0.7309 | -416.0 | -335.0 | |
| 0.00 | 1.78 | 0.00 | 1.28 | 12.12 | 89.61 | 47.08 | 279.89 | 0.7291 | -225.0 | -237.8 | |
| 0.53 | 1.69 | 0.39 | 1.24 | 16.58 | 90.27 | 47.74 | 285.92 | 0.7399 | 403.3 | 319.0 | |
| 0.00 | 1.16 | 0.00 | 0.81 | 9.17 | 88.17 | 45.64 | 275.79 | 0.7118 | -563.0 | -437.5 | |
| 0.00 | 1.42 | 0.00 | 1.01 | 11.63 | 88.56 | 46.03 | 279.25 | 0.7165 | -567.0 | -451.5 | |
| 0.00 | 1.87 | 0.00 | 1.33 | 12.93 | 88.81 | 46.28 | 281.04 | 0.7200 | 293.0 | 120.8 | |
| 0.00 | 1.24 | 0.00 | 0.88 | 11.53 | 88.36 | 45.83 | 279.11 | 0.7141 | -395.0 | -287.9 | |
| 0.80 | 3.91 | 0.58 | 2.85 | 16.93 | 89.77 | 47.25 | 286.46 | 0.7348 | 611.8 | 518.5 | |
| 0.00 | 0.62 | 0.00 | 0.46 | 18.32 | 89.88 | 47.35 | 288.32 | 0.7379 | -526.0 | -445.0 | |
| 0.00 | 2.49 | 0.00 | 1.80 | 16.76 | 89.30 | 46.77 | 286.29 | 0.7292 | 496.0 | 402.9 | |
| 46.95 | 283.57 | 33.32 | 200.78 | 14.82 | 88.53 | 46.01 | 283.70 | 0.7182 | 1175.1 | 417.6 | |
| 1.87 | 6.40 | 1.30 | 4.47 | 11.86 | 87.72 | 45.19 | 279.60 | 0.7065 | -794.1 | -591.4 | |
| 0.00 | 1.24 | 0.00 | 0.86 | 11.25 | 87.42 | 44.89 | 278.74 | 0.7026 | -483.0 | -377.4 | |
| 0.00 | 1.07 | 0.00 | 0.74 | 12.60 | 87.66 | 45.14 | 280.65 | 0.7062 | -447.0 | -366.5 | |
| 0.00 | 1.16 | 0.00 | 0.80 | 11.49 | 87.38 | 44.85 | 279.09 | 0.7023 | -624.0 | -469.7 | |
| 0.00 | 2.58 | 0.00 | 1.78 | 11.19 | 87.06 | 44.53 | 278.66 | 0.6982 | -769.0 | -647.2 | |
| 3.29 | 8.27 | 2.38 | 5.97 | 18.89 | 89.15 | 46.62 | 289.22 | 0.7306 | -612.7 | -307.5 | |
| 0.00 | 0.62 | 0.00 | 0.43 | 10.39 | 86.78 | 44.25 | 277.52 | 0.6946 | -558.0 | -451.0 | |
| 0.00 | 1.60 | 0.00 | 1.11 | 12.58 | 87.22 | 44.69 | 280.65 | 0.7008 | -347.0 | -379.7 | |
| 0.00 | 0.71 | 0.00 | 0.49 | 10.51 | 86.42 | 43.89 | 277.70 | 0.6901 | -593.0 | -467.9 | |
| 3.65 | 91.95 | 2.58 | 65.16 | 17.83 | 88.14 | 45.61 | 287.94 | 0.7173 | 741.0 | 190.8 | |
| 19.83 | -22.00 | 14.01 | -22.00 | 17.59 | 88.01 | 45.48 | 287.63 | 0.7155 | 890.0 | 999999 | |
| 0.00 | 1.42 | 0.00 | 0.98 | 12.69 | 86.68 | 44.15 | 280.84 | 0.6942 | -631.0 | -564.1 | |
| 1.24 | -22.00 | 0.88 | -22.00 | 18.01 | 88.11 | 45.58 | 288.20 | 0.7173 | 594.6 | 999999 | |
| 1.96 | 6.22 | 1.40 | 4.44 | 19.05 | 88.42 | 45.89 | 289.57 | 0.7227 | 603.5 | 456.8 | |
| 0.00 | 1.78 | 0.00 | 1.21 | 11.92 | 86.30 | 43.77 | 279.76 | 0.6891 | -772.0 | -546.5 | |
| 0.00 | 11.03 | 0.00 | 7.58 | 14.19 | 86.68 | 44.16 | 283.00 | 0.6955 | 425.0 | 472.6 | |
| 16.72 | 30.68 | 11.61 | 21.29 | 16.24 | 87.15 | 44.62 | 285.87 | 0.7034 | 866.9 | 521.2 | |
| 0.71 | -22.00 | 0.50 | -22.00 | 17.54 | 87.50 | 44.97 | 287.65 | 0.7095 | 669.8 | 999999 | |
| 0.00 | 1.16 | 0.00 | 0.78 | 12.00 | 85.72 | 43.19 | 279.91 | 0.6819 | -768.0 | -644.9 | |
| 0.00 | 1.69 | 0.00 | 1.14 | 12.90 | 85.61 | 43.08 | 281.23 | 0.6811 | -667.0 | -586.3 | |
| 0.00 | 1.69 | 0.00 | 1.13 | 12.64 | 85.01 | 42.48 | 280.90 | 0.6734 | -769.0 | -653.6 | |
| 0.00 | 1.24 | 0.00 | 0.84 | 14.12 | 85.29 | 42.76 | 283.06 | 0.6783 | -171.0 | -123.2 | |
| 0.00 | 2.13 | 0.00 | 1.43 | 13.85 | 85.19 | 42.66 | 282.68 | 0.6767 | -488.0 | -398.3 | |
| 0.00 | 0.89 | 0.00 | 0.59 | 12.89 | 84.98 | 42.45 | 281.28 | 0.6732 | -757.0 | -660.3 | |
| 0.00 | 1.96 | 0.00 | 1.34 | 17.60 | 86.06 | 43.53 | 288.00 | 0.6926 | 323.0 | 279.0 | |
| 0.71 | 2.67 | 0.47 | 1.77 | 12.80 | 84.58 | 42.05 | 281.18 | 0.6681 | -758.2 | -653.7 | |
| 0.00 | 1.42 | 0.00 | 0.96 | 17.72 | 85.40 | 42.87 | 288.31 | 0.6849 | 461.0 | 439.0 | |
| 0.00 | 0.71 | 0.00 | 0.46 | 12.87 | 83.35 | 40.82 | 281.40 | 0.6524 | -506.0 | -427.5 | |
| 0.00 | 1.33 | 0.00 | 0.87 | 13.15 | 83.33 | 40.80 | 281.83 | 0.6524 | -781.0 | -585.2 | |
| 0.00 | 1.96 | 0.00 | 1.29 | 16.09 | 83.79 | 41.26 | 286.22 | 0.6623 | -499.0 | -391.6 | |
| 0.00 | 0.71 | 0.00 | 0.46 | 13.95 | 83.25 | 40.72 | 283.07 | 0.6522 | -636.0 | -577.4 | |
| 0.00 | 0.98 | 0.00 | 0.64 | 14.62 | 83.27 | 40.74 | 284.09 | 0.6534 | -467.0 | -453.8 | |
| 0.00 | 1.78 | 0.00 | 1.15 | 14.11 | 82.38 | 39.85 | 283.44 | 0.6413 | -777.0 | -647.8 | |
| 0.00 | 0.71 | 0.00 | 0.43 | 11.67 | 78.06 | 35.53 | 280.03 | 0.5802 | -508.0 | -411.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
