SDO HMI 2014-09-16 03:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.71 | 24.86 | 3.57 | 18.64 | -15.97 | 64.22 | 43.16 | 241.20 | 0.7525 | 27.6 | 63.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-16 03:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.33 | 0.00 | 1.02 | -15.22 | 65.97 | 44.91 | 243.06 | 0.7664 | 602.0 | 490.5 | |
| 0.80 | 3.38 | 0.61 | 2.58 | -15.82 | 65.38 | 44.32 | 242.05 | 0.7633 | 516.8 | 400.1 | |
| 0.44 | 1.95 | 0.34 | 1.48 | -15.67 | 65.16 | 44.11 | 242.11 | 0.7605 | 688.0 | 629.9 | |
| 0.53 | 5.15 | 0.40 | 3.89 | -15.16 | 64.89 | 43.84 | 242.59 | 0.7554 | 719.3 | 628.4 | |
| 1.78 | -4.00 | 1.34 | -4.00 | -15.32 | 64.89 | 43.84 | 242.39 | 0.7561 | 729.3 | 999999 | |
| 1.16 | 2.49 | 0.88 | 1.89 | -16.05 | 65.05 | 43.99 | 241.60 | 0.7611 | 645.5 | 549.5 | |
| 0.00 | 0.53 | 0.00 | 0.40 | -15.92 | 64.71 | 43.65 | 241.57 | 0.7571 | 448.0 | 411.0 | |
| 0.00 | 1.33 | 0.00 | 1.00 | -16.67 | 64.00 | 42.95 | 240.29 | 0.7538 | -194.0 | -340.8 | |
| 0.00 | 0.98 | 0.00 | 0.73 | -16.37 | 63.92 | 42.86 | 240.60 | 0.7515 | -382.0 | -303.3 | |
| 0.00 | 0.80 | 0.00 | 0.60 | -16.87 | 64.06 | 43.00 | 240.08 | 0.7554 | -503.0 | -376.8 | |
| 0.00 | 1.33 | 0.00 | 1.00 | -16.88 | 63.85 | 42.79 | 239.94 | 0.7533 | -429.0 | -362.0 | |
| 0.00 | 1.24 | 0.00 | 0.93 | -16.34 | 63.65 | 42.60 | 240.48 | 0.7487 | -644.0 | -498.9 | |
| 0.00 | 1.42 | 0.00 | 1.04 | -15.81 | 63.13 | 42.08 | 240.84 | 0.7407 | -576.0 | -468.0 | |
| 0.00 | 1.33 | 0.00 | 0.98 | -16.33 | 63.10 | 42.04 | 240.19 | 0.7430 | -663.0 | -545.2 | |
| 0.00 | 0.71 | 0.00 | 0.50 | -16.83 | 60.27 | 39.22 | 237.86 | 0.7170 | -474.0 | -457.8 | |
| 0.00 | 0.89 | 0.00 | 0.60 | -17.44 | 55.93 | 34.88 | 234.07 | 0.6761 | -518.0 | -438.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
