SDO HMI 2014-09-16 11:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 16.97 | 164.87 | 9.03 | 90.06 | 12.78 | 352.55 | -24.12 | 74.73 | 0.4135 | -358.6 | -312.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-16 11:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.89 | 0.00 | 0.46 | 13.04 | 358.98 | -17.69 | 69.97 | 0.3165 | -797.0 | -637.1 | |
| 0.00 | 1.69 | 0.00 | 0.89 | 12.76 | 358.03 | -18.65 | 71.60 | 0.3301 | -818.0 | -578.1 | |
| 0.00 | 1.87 | 0.00 | 0.98 | 13.09 | 357.05 | -19.62 | 71.40 | 0.3466 | -937.0 | -775.7 | |
| 0.00 | 1.87 | 0.00 | 0.99 | 13.33 | 356.96 | -19.71 | 70.80 | 0.3490 | -743.0 | -580.1 | |
| 0.00 | 3.02 | 0.00 | 1.59 | 12.72 | 356.88 | -19.79 | 72.56 | 0.3477 | -546.0 | -614.5 | |
| 0.00 | 0.80 | 0.00 | 0.42 | 12.68 | 356.69 | -19.98 | 72.79 | 0.3506 | -979.0 | -862.2 | |
| 0.00 | 1.87 | 0.00 | 0.99 | 12.43 | 356.64 | -20.03 | 73.50 | 0.3503 | -992.0 | -781.1 | |
| 0.00 | 4.53 | 0.00 | 2.40 | 12.67 | 356.43 | -20.25 | 72.99 | 0.3546 | -895.0 | -789.1 | |
| 0.00 | 1.24 | 0.00 | 0.66 | 11.70 | 356.40 | -20.27 | 75.71 | 0.3516 | -912.0 | -781.3 | |
| 0.00 | 1.69 | 0.00 | 0.90 | 12.90 | 356.24 | -20.43 | 72.47 | 0.3584 | -1009.0 | -844.5 | |
| 0.00 | 4.44 | 0.00 | 2.35 | 12.24 | 356.26 | -20.41 | 74.28 | 0.3556 | -999.0 | -750.0 | |
| 0.00 | 3.55 | 0.00 | 1.88 | 11.18 | 356.21 | -20.46 | 77.27 | 0.3531 | -1034.0 | -918.1 | |
| 0.00 | 1.15 | 0.00 | 0.61 | 11.66 | 356.11 | -20.56 | 75.98 | 0.3561 | -962.0 | -795.5 | |
| 0.00 | 0.53 | 0.00 | 0.28 | 12.59 | 356.00 | -20.67 | 73.47 | 0.3609 | -672.0 | -592.5 | |
| 0.00 | 1.42 | 0.00 | 0.76 | 15.43 | 355.64 | -21.04 | 66.33 | 0.3794 | -658.0 | -536.5 | |
| 0.00 | 1.33 | 0.00 | 0.71 | 11.53 | 355.96 | -20.72 | 76.41 | 0.3581 | -862.0 | -633.5 | |
| 0.00 | 5.77 | 0.00 | 3.07 | 12.98 | 355.81 | -20.87 | 72.56 | 0.3654 | -678.0 | -690.6 | |
| 0.00 | 1.42 | 0.00 | 0.75 | 11.29 | 355.94 | -20.73 | 77.09 | 0.3577 | -877.0 | -793.4 | |
| 0.00 | 3.20 | 0.00 | 1.70 | 10.83 | 355.91 | -20.76 | 78.36 | 0.3570 | -961.0 | -798.8 | |
| 0.00 | 1.51 | 0.00 | 0.80 | 11.31 | 355.71 | -20.96 | 77.13 | 0.3614 | -973.0 | -892.4 | |
| 15.10 | 27.81 | 8.03 | 14.80 | 12.18 | 355.61 | -21.06 | 74.81 | 0.3656 | -1044.8 | -457.3 | |
| 0.00 | 3.38 | 0.00 | 1.79 | 10.85 | 355.71 | -20.96 | 78.38 | 0.3602 | -819.0 | -657.9 | |
| 0.00 | 1.42 | 0.00 | 0.76 | 11.33 | 355.51 | -21.16 | 77.16 | 0.3646 | -789.0 | -647.6 | |
| 0.00 | 1.33 | 0.00 | 0.71 | 11.29 | 355.28 | -21.39 | 77.37 | 0.3681 | -990.0 | -825.3 | |
| 1.07 | 4.18 | 0.57 | 2.23 | 10.88 | 354.95 | -21.72 | 78.60 | 0.3724 | -1066.2 | -846.4 | |
| 0.00 | 1.15 | 0.00 | 0.62 | 11.26 | 354.76 | -21.92 | 77.65 | 0.3764 | -939.0 | -803.4 | |
| 0.00 | 1.15 | 0.00 | 0.62 | 11.75 | 354.72 | -21.96 | 76.40 | 0.3782 | -904.0 | -788.3 | |
| 0.00 | 1.95 | 0.00 | 1.05 | 11.44 | 354.71 | -21.96 | 77.20 | 0.3776 | -864.0 | -737.0 | |
| 0.00 | 2.40 | 0.00 | 1.28 | 11.08 | 354.64 | -22.03 | 78.19 | 0.3778 | -951.0 | -804.9 | |
| 0.00 | 1.51 | 0.00 | 0.81 | 11.86 | 354.54 | -22.13 | 76.18 | 0.3813 | -764.0 | -643.4 | |
| 0.00 | 1.78 | 0.00 | 0.96 | 14.10 | 354.30 | -22.37 | 70.66 | 0.3929 | -693.0 | -541.0 | |
| 0.00 | 1.95 | 0.00 | 1.05 | 12.43 | 354.32 | -22.35 | 74.83 | 0.3864 | -694.0 | -443.8 | |
| 0.80 | 7.46 | 0.43 | 4.00 | 10.95 | 354.42 | -22.26 | 78.61 | 0.3810 | -848.7 | -621.8 | |
| 0.00 | 3.91 | 0.00 | 2.09 | 10.52 | 354.38 | -22.29 | 79.74 | 0.3806 | -639.0 | -565.1 | |
| 0.00 | 4.18 | 0.00 | 2.24 | 12.21 | 354.14 | -22.53 | 75.48 | 0.3885 | -738.0 | -651.0 | |
| 0.00 | 1.42 | 0.00 | 0.77 | 12.19 | 353.81 | -22.86 | 75.67 | 0.3936 | -557.0 | -398.9 | |
| 0.00 | 0.89 | 0.00 | 0.48 | 11.55 | 353.70 | -22.97 | 77.33 | 0.3936 | -489.0 | -464.3 | |
| 0.00 | 1.15 | 0.00 | 0.62 | 12.48 | 353.58 | -23.09 | 75.05 | 0.3980 | -558.0 | -356.9 | |
| 0.00 | 1.24 | 0.00 | 0.67 | 12.94 | 353.00 | -23.67 | 74.20 | 0.4084 | 629.0 | 486.6 | |
| 0.00 | 5.15 | 0.00 | 2.83 | 15.95 | 352.32 | -24.36 | 67.61 | 0.4306 | -429.0 | -327.8 | |
| 0.00 | 2.04 | 0.00 | 1.11 | 12.58 | 352.49 | -24.18 | 75.29 | 0.4150 | 891.0 | 644.0 | |
| 0.00 | 1.60 | 0.00 | 0.88 | 14.48 | 352.05 | -24.62 | 71.10 | 0.4282 | -680.0 | -491.7 | |
| 0.00 | 1.33 | 0.00 | 0.74 | 15.75 | 351.24 | -25.44 | 68.75 | 0.4454 | -735.0 | -568.3 | |
| 0.00 | 1.07 | 0.00 | 0.59 | 15.56 | 350.50 | -26.18 | 69.59 | 0.4553 | -626.0 | -530.2 | |
| 0.00 | 1.78 | 0.00 | 0.99 | 16.55 | 350.15 | -26.53 | 67.71 | 0.4646 | -564.0 | -460.8 | |
| 0.00 | 1.60 | 0.00 | 0.89 | 16.27 | 350.15 | -26.52 | 68.28 | 0.4633 | -662.0 | -562.1 | |
| 0.00 | 1.07 | 0.00 | 0.59 | 15.39 | 350.24 | -26.43 | 70.09 | 0.4584 | -599.0 | -484.5 | |
| 0.00 | 1.78 | 0.00 | 0.99 | 13.68 | 350.15 | -26.53 | 73.81 | 0.4537 | 1013.0 | 857.2 | |
| 0.00 | 1.15 | 0.00 | 0.64 | 12.38 | 349.74 | -26.93 | 76.78 | 0.4563 | 841.0 | 753.4 | |
| 0.00 | 3.02 | 0.00 | 1.68 | 12.55 | 349.48 | -27.19 | 76.50 | 0.4606 | 783.0 | 700.1 | |
| 0.00 | 4.53 | 0.00 | 2.62 | 14.42 | 346.01 | -30.67 | 73.86 | 0.5163 | 934.0 | 804.7 | |
| 0.00 | 0.98 | 0.00 | 0.56 | 14.14 | 346.01 | -30.66 | 74.38 | 0.5155 | 834.0 | 723.9 | |
| 0.00 | 1.07 | 0.00 | 0.61 | 12.36 | 346.18 | -30.49 | 77.80 | 0.5091 | 710.0 | 587.2 | |
| 0.00 | 0.62 | 0.00 | 0.36 | 14.61 | 345.21 | -31.46 | 73.75 | 0.5281 | 756.0 | 613.3 | |
| 0.00 | 0.80 | 0.00 | 0.47 | 14.17 | 345.06 | -31.61 | 74.62 | 0.5292 | 530.0 | 555.6 | |
| 0.00 | 1.15 | 0.00 | 0.67 | 12.75 | 345.16 | -31.51 | 77.28 | 0.5247 | 674.0 | 563.5 | |
| 0.00 | 2.49 | 0.00 | 1.44 | 11.72 | 345.19 | -31.49 | 79.24 | 0.5226 | 637.0 | 539.2 | |
| 0.00 | 0.80 | 0.00 | 0.47 | 13.84 | 344.60 | -32.07 | 75.37 | 0.5350 | 852.0 | 710.0 | |
| 0.00 | 2.40 | 0.00 | 1.40 | 12.90 | 344.63 | -32.04 | 77.12 | 0.5326 | 679.0 | 591.4 | |
| 0.00 | 1.07 | 0.00 | 0.64 | 17.48 | 343.54 | -33.13 | 69.18 | 0.5599 | 631.0 | 513.8 | |
| 0.00 | 0.98 | 0.00 | 0.57 | 13.12 | 344.27 | -32.41 | 76.79 | 0.5382 | 517.0 | 460.3 | |
| 0.00 | 1.15 | 0.00 | 0.68 | 13.45 | 344.18 | -32.49 | 76.21 | 0.5401 | 725.0 | 612.8 | |
| 0.00 | 0.80 | 0.00 | 0.48 | 14.85 | 343.17 | -33.50 | 73.94 | 0.5573 | 519.0 | 394.2 | |
| 0.00 | 1.07 | 0.00 | 0.64 | 13.68 | 342.62 | -34.05 | 76.16 | 0.5625 | 627.0 | 505.2 | |
| 0.00 | 0.89 | 0.00 | 0.55 | 18.57 | 340.00 | -36.67 | 68.68 | 0.6100 | 503.0 | 427.2 | |
| 0.00 | 1.33 | 0.00 | 0.81 | 10.26 | 341.47 | -35.21 | 82.35 | 0.5746 | -704.0 | -536.7 | |
| 0.00 | 1.07 | 0.00 | 0.64 | 10.10 | 341.37 | -35.30 | 82.63 | 0.5758 | -658.0 | -551.6 | |
| 0.00 | 2.04 | 0.00 | 1.28 | 18.43 | 339.83 | -36.84 | 68.95 | 0.6117 | 577.0 | 354.3 | |
| 0.00 | 2.04 | 0.00 | 1.28 | 17.55 | 339.21 | -37.46 | 70.56 | 0.6172 | 509.0 | 474.0 | |
| 0.00 | 0.80 | 0.00 | 0.50 | 14.74 | 339.48 | -37.20 | 75.04 | 0.6074 | 608.0 | 501.9 | |
| 0.00 | 1.15 | 0.00 | 0.72 | 14.11 | 339.25 | -37.43 | 76.11 | 0.6094 | 602.0 | 492.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
