SDO HMI 2014-09-16 23:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 26.19 | 0.00 | 15.25 | 8.76 | 338.49 | -31.56 | 84.76 | 0.5194 | -261.6 | -215.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-16 23:00:35 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.80 | 0.00 | 0.44 | 9.62 | 345.20 | -24.85 | 82.61 | 0.4196 | 625.0 | 518.8 | |
| 0.00 | 0.98 | 0.00 | 0.53 | 9.58 | 345.00 | -25.05 | 82.74 | 0.4227 | 720.0 | 573.7 | |
| 0.00 | 0.89 | 0.00 | 0.49 | 7.84 | 343.02 | -27.03 | 86.84 | 0.4528 | -696.0 | -637.8 | |
| 0.00 | 1.51 | 0.00 | 0.84 | 8.89 | 342.88 | -27.18 | 84.52 | 0.4552 | -861.0 | -635.7 | |
| 0.00 | 1.24 | 0.00 | 0.69 | 7.46 | 342.71 | -27.35 | 87.67 | 0.4578 | -664.0 | -520.6 | |
| 0.00 | 0.98 | 0.00 | 0.55 | 8.04 | 342.25 | -27.80 | 86.40 | 0.4646 | -562.0 | -473.8 | |
| 0.00 | 3.02 | 0.00 | 1.69 | 8.84 | 342.05 | -28.00 | 84.67 | 0.4678 | -372.0 | -335.5 | |
| 0.00 | 4.26 | 0.00 | 2.39 | 10.28 | 341.75 | -28.30 | 81.64 | 0.4735 | -338.0 | -401.3 | |
| 0.00 | 1.15 | 0.00 | 0.66 | 6.81 | 339.94 | -30.11 | 88.83 | 0.5003 | -666.0 | -565.4 | |
| 0.00 | 1.95 | 0.00 | 1.12 | 9.34 | 339.27 | -30.78 | 83.79 | 0.5100 | -754.0 | -527.5 | |
| 0.00 | 1.15 | 0.00 | 0.67 | 10.74 | 338.84 | -31.21 | 81.11 | 0.5174 | -654.0 | -500.5 | |
| 0.00 | 0.80 | 0.00 | 0.46 | 7.29 | 338.92 | -31.14 | 87.80 | 0.5153 | -571.0 | -511.2 | |
| 0.00 | 1.42 | 0.00 | 0.84 | 8.17 | 337.01 | -33.04 | 86.07 | 0.5431 | -600.0 | -448.7 | |
| 0.00 | 0.98 | 0.00 | 0.59 | 9.18 | 335.47 | -34.58 | 84.23 | 0.5653 | -435.0 | -460.6 | |
| 0.00 | 1.51 | 0.00 | 0.96 | 8.78 | 330.82 | -39.24 | 84.92 | 0.6299 | 148.0 | 241.1 | |
| 0.00 | 2.04 | 0.00 | 1.32 | 7.82 | 329.74 | -40.32 | 86.40 | 0.6445 | 608.0 | 514.6 | |
| 0.00 | 1.51 | 0.00 | 1.01 | 7.31 | 327.23 | -42.82 | 87.01 | 0.6775 | 625.0 | 446.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
