SDO HMI 2014-09-17 16:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.13 | 126.44 | 35.85 | 190.11 | 7.73 | 289.43 | -71.29 | 84.29 | 0.9444 | -374.1 | -68.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-17 16:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.29 | 66.37 | 15.32 | 100.19 | 10.02 | 289.28 | -71.44 | 81.86 | 0.9445 | -527.9 | -76.4 | |
| 11.18 | 53.24 | 16.00 | 76.49 | 5.13 | 290.58 | -70.14 | 87.16 | 0.9394 | -422.8 | -70.9 | |
| 1.77 | -1.00 | 2.72 | -1.00 | 10.07 | 288.65 | -72.07 | 81.76 | 0.9479 | 52.2 | 999999 | |
| 0.00 | 1.15 | 0.00 | 1.86 | 4.81 | 288.16 | -72.56 | 87.23 | 0.9531 | 343.0 | 324.5 | |
| 0.00 | 1.42 | 0.00 | 2.90 | 6.07 | 284.14 | -76.58 | 85.50 | 0.9713 | -262.0 | -233.4 | |
| 0.00 | 0.27 | 0.00 | 0.54 | 5.95 | 284.19 | -76.53 | 85.62 | 0.9712 | -215.0 | -100.0 | |
| 0.00 | 1.42 | 0.00 | 2.90 | 5.65 | 284.19 | -76.53 | 85.94 | 0.9713 | 108.0 | 103.3 | |
| 0.89 | 2.57 | 1.81 | 5.23 | 5.17 | 284.24 | -76.48 | 86.44 | 0.9713 | -94.7 | -42.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
