SDO HMI 2014-09-18 15:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.77 | 80.25 | 0.89 | 40.25 | 12.88 | 352.32 | 4.25 | 315.36 | 0.1487 | -225.8 | -326.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-18 15:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.06 | 0.00 | 0.54 | 11.64 | 358.93 | 10.86 | 293.63 | 0.2023 | -789.0 | -697.8 | |
| 0.00 | 1.24 | 0.00 | 0.63 | 13.24 | 357.90 | 9.83 | 303.04 | 0.1991 | -1112.0 | -818.6 | |
| 0.00 | 1.06 | 0.00 | 0.54 | 11.82 | 357.53 | 9.46 | 297.40 | 0.1820 | -795.0 | -589.5 | |
| 0.00 | 2.39 | 0.00 | 1.20 | 11.09 | 356.69 | 8.62 | 295.52 | 0.1638 | -833.0 | -710.3 | |
| 0.00 | 1.51 | 0.00 | 0.76 | 12.34 | 356.14 | 8.07 | 303.79 | 0.1658 | -847.0 | -604.8 | |
| 0.00 | 1.15 | 0.00 | 0.58 | 12.19 | 356.01 | 7.94 | 303.43 | 0.1626 | -897.0 | -773.1 | |
| 0.00 | 6.39 | 0.00 | 3.20 | 11.25 | 355.80 | 7.73 | 298.92 | 0.1514 | -850.0 | -805.7 | |
| 0.00 | 0.71 | 0.00 | 0.36 | 11.10 | 355.70 | 7.63 | 298.33 | 0.1488 | -911.0 | -748.2 | |
| 1.77 | 3.46 | 0.89 | 1.73 | 12.20 | 355.52 | 7.45 | 305.15 | 0.1556 | -1060.5 | -833.1 | |
| 0.00 | 5.06 | 0.00 | 2.53 | 11.32 | 355.49 | 7.42 | 300.28 | 0.1473 | -1136.0 | -922.2 | |
| 0.00 | 1.60 | 0.00 | 0.80 | 10.99 | 355.48 | 7.41 | 298.29 | 0.1445 | -920.0 | -793.1 | |
| 0.00 | 1.60 | 0.00 | 0.80 | 7.28 | 355.31 | 7.24 | 271.62 | 0.1256 | -904.0 | -714.7 | |
| 0.00 | 5.32 | 0.00 | 2.66 | 11.78 | 355.23 | 7.16 | 303.87 | 0.1475 | -1149.0 | -929.6 | |
| 0.00 | 4.08 | 0.00 | 2.04 | 10.96 | 355.14 | 7.07 | 299.24 | 0.1392 | -817.0 | -732.0 | |
| 0.00 | 1.24 | 0.00 | 0.63 | 15.38 | 355.18 | 7.11 | 320.41 | 0.1882 | -769.0 | -594.3 | |
| 0.00 | 2.39 | 0.00 | 1.20 | 12.17 | 355.02 | 6.95 | 306.86 | 0.1485 | -1134.0 | -943.3 | |
| 0.00 | 1.33 | 0.00 | 0.67 | 13.75 | 354.97 | 6.90 | 314.82 | 0.1653 | -965.0 | -858.2 | |
| 0.00 | 3.19 | 0.00 | 1.60 | 13.60 | 354.69 | 6.62 | 315.35 | 0.1601 | -1162.0 | -891.2 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 12.28 | 353.60 | 5.53 | 313.81 | 0.1310 | -951.0 | -734.7 | |
| 0.00 | 0.62 | 0.00 | 0.31 | 12.80 | 353.58 | 5.51 | 316.67 | 0.1370 | -894.0 | -686.6 | |
| 0.00 | 1.51 | 0.00 | 0.76 | 16.35 | 353.55 | 5.48 | 330.33 | 0.1858 | -846.0 | -629.6 | |
| 0.00 | 2.57 | 0.00 | 1.29 | 13.05 | 353.09 | 5.02 | 320.52 | 0.1346 | -913.0 | -714.3 | |
| 0.00 | 1.24 | 0.00 | 0.62 | 14.54 | 352.00 | 3.93 | 332.83 | 0.1459 | -999.0 | -828.9 | |
| 0.00 | 2.31 | 0.00 | 1.15 | 14.37 | 351.50 | 3.43 | 335.33 | 0.1394 | -733.0 | -813.3 | |
| 0.00 | 1.15 | 0.00 | 0.58 | 14.79 | 351.35 | 3.28 | 337.50 | 0.1451 | -949.0 | -875.4 | |
| 0.00 | 1.15 | 0.00 | 0.58 | 14.98 | 351.32 | 3.25 | 338.15 | 0.1478 | -951.0 | -749.2 | |
| 0.00 | 1.77 | 0.00 | 0.88 | 12.89 | 350.54 | 2.48 | 337.24 | 0.1093 | 929.0 | 625.0 | |
| 0.00 | 3.19 | 0.00 | 1.59 | 13.14 | 348.60 | 0.53 | 355.08 | 0.1054 | 1133.0 | 894.2 | |
| 0.00 | 1.06 | 0.00 | 0.54 | 19.49 | 348.11 | 0.04 | 359.80 | 0.2149 | 721.0 | 620.8 | |
| 0.00 | 0.80 | 0.00 | 0.41 | 20.51 | 347.76 | -0.31 | 1.25 | 0.2323 | 735.0 | 597.2 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 12.38 | 347.30 | -0.77 | 8.14 | 0.0928 | 871.0 | 625.0 | |
| 0.00 | 2.31 | 0.00 | 1.15 | 12.20 | 347.27 | -0.80 | 8.76 | 0.0898 | 1046.0 | 779.5 | |
| 0.00 | 1.33 | 0.00 | 0.66 | 12.44 | 347.12 | -0.95 | 9.95 | 0.0944 | 965.0 | 744.0 | |
| 0.00 | 1.24 | 0.00 | 0.63 | 18.53 | 346.81 | -1.26 | 6.02 | 0.1996 | 839.0 | 641.6 | |
| 0.00 | 0.98 | 0.00 | 0.49 | 13.50 | 345.69 | -2.38 | 20.00 | 0.1186 | 937.0 | 795.5 | |
| 0.00 | 2.39 | 0.00 | 1.20 | 13.83 | 345.66 | -2.41 | 19.31 | 0.1242 | 958.0 | 824.4 | |
| 0.00 | 1.06 | 0.00 | 0.53 | 14.38 | 344.93 | -3.13 | 22.77 | 0.1375 | 1025.0 | 790.8 | |
| 0.00 | 1.42 | 0.00 | 0.71 | 13.80 | 344.69 | -3.38 | 26.20 | 0.1301 | 928.0 | 765.6 | |
| 0.00 | 1.06 | 0.00 | 0.53 | 15.04 | 344.15 | -3.92 | 25.63 | 0.1535 | 958.0 | 790.4 | |
| 0.00 | 1.77 | 0.00 | 0.89 | 14.74 | 344.12 | -3.95 | 26.69 | 0.1490 | 989.0 | 909.5 | |
| 0.00 | 0.89 | 0.00 | 0.45 | 15.08 | 339.78 | -8.29 | 44.94 | 0.1979 | 791.0 | 652.6 | |
| 0.00 | 1.69 | 0.00 | 0.85 | 15.01 | 339.38 | -8.69 | 46.53 | 0.2021 | 888.0 | 639.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
