SDO HMI 2014-09-19 17:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 52.29 | 262.32 | 35.64 | 178.77 | 8.30 | 290.13 | -43.64 | 85.44 | 0.6879 | -622.2 | -247.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-19 17:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.42 | 0.00 | 0.89 | 8.62 | 295.69 | -38.08 | 85.10 | 0.6143 | -702.0 | -568.7 | |
| 0.00 | 1.24 | 0.00 | 0.80 | 7.35 | 294.07 | -39.70 | 87.08 | 0.6366 | -650.0 | -472.8 | |
| 0.00 | 1.06 | 0.00 | 0.69 | 12.44 | 292.92 | -40.85 | 79.16 | 0.6526 | -504.0 | -480.9 | |
| 0.00 | 1.95 | 0.00 | 1.26 | 4.49 | 293.44 | -40.33 | 91.47 | 0.6477 | 775.0 | 600.5 | |
| 0.00 | 0.71 | 0.00 | 0.46 | 10.39 | 292.70 | -41.06 | 82.33 | 0.6542 | -680.0 | -531.4 | |
| 0.00 | 1.24 | 0.00 | 0.81 | 10.83 | 292.55 | -41.22 | 81.65 | 0.6564 | -571.0 | -479.1 | |
| 0.00 | 0.71 | 0.00 | 0.47 | 11.07 | 292.43 | -41.34 | 81.30 | 0.6580 | -659.0 | -615.5 | |
| 0.00 | 2.04 | 0.00 | 1.34 | 10.55 | 292.39 | -41.37 | 82.10 | 0.6583 | -269.0 | -347.0 | |
| 0.00 | 1.60 | 0.00 | 1.05 | 11.31 | 292.02 | -41.75 | 80.96 | 0.6635 | -593.0 | -448.7 | |
| 22.24 | 96.42 | 14.97 | 64.98 | 5.25 | 290.95 | -42.81 | 89.97 | 0.6791 | -860.7 | -255.8 | |
| 13.03 | 141.18 | 8.87 | 96.57 | 10.51 | 290.06 | -43.70 | 82.21 | 0.6880 | -1109.4 | -306.5 | |
| 15.42 | -11.00 | 10.58 | -11.00 | 10.47 | 289.56 | -44.21 | 82.28 | 0.6942 | -761.1 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.73 | 6.66 | 289.30 | -44.46 | 87.76 | 0.6986 | 581.0 | 360.2 | |
| 0.00 | 1.06 | 0.00 | 0.74 | 9.97 | 288.35 | -45.42 | 83.00 | 0.7091 | -512.0 | -387.8 | |
| 0.00 | 1.15 | 0.00 | 0.83 | 5.27 | 287.24 | -46.53 | 89.51 | 0.7250 | 571.0 | 492.1 | |
| 0.00 | 0.80 | 0.00 | 0.59 | 5.98 | 285.41 | -48.36 | 88.35 | 0.7459 | 653.0 | 572.2 | |
| 0.00 | 1.15 | 0.00 | 0.86 | 5.38 | 285.11 | -48.66 | 89.12 | 0.7499 | 618.0 | 509.5 | |
| 0.00 | 4.61 | 0.00 | 3.47 | 6.15 | 284.60 | -49.16 | 88.04 | 0.7550 | 481.0 | 499.3 | |
| 1.60 | 2.92 | 1.22 | 2.23 | 5.12 | 283.97 | -49.79 | 89.33 | 0.7630 | 600.1 | 389.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
