SDO HMI 2014-09-20 02:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 51.34 | 287.83 | 32.41 | 181.73 | 8.35 | 290.27 | -38.53 | 85.55 | 0.6213 | -605.0 | -299.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-20 02:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.42 | 0.00 | 0.80 | 10.96 | 299.86 | -28.94 | 80.20 | 0.4840 | -851.0 | -671.1 | |
| 0.00 | 0.53 | 0.00 | 0.32 | 10.73 | 293.47 | -35.33 | 81.46 | 0.5768 | -783.0 | -735.2 | |
| 0.00 | 0.98 | 0.00 | 0.59 | 10.63 | 293.33 | -35.47 | 81.64 | 0.5786 | -657.0 | -561.9 | |
| 0.00 | 2.48 | 0.00 | 1.52 | 11.01 | 292.63 | -36.17 | 81.06 | 0.5886 | -791.0 | -675.2 | |
| 0.00 | 1.15 | 0.00 | 0.70 | 4.46 | 293.19 | -35.61 | 92.31 | 0.5831 | 687.0 | 577.8 | |
| 0.00 | 1.15 | 0.00 | 0.71 | 10.88 | 292.50 | -36.30 | 81.29 | 0.5904 | -669.0 | -588.0 | |
| 0.00 | 1.06 | 0.00 | 0.65 | 10.33 | 292.50 | -36.30 | 82.22 | 0.5901 | -708.0 | -564.4 | |
| 0.00 | 2.57 | 0.00 | 1.58 | 11.16 | 292.15 | -36.65 | 80.85 | 0.5954 | -778.0 | -589.3 | |
| 0.00 | 0.98 | 0.00 | 0.61 | 8.68 | 291.40 | -37.40 | 85.02 | 0.6049 | -570.0 | -399.5 | |
| 15.61 | 108.44 | 9.75 | 67.87 | 5.21 | 291.07 | -37.73 | 90.72 | 0.6117 | -1024.7 | -331.8 | |
| 16.49 | 155.17 | 10.42 | 98.46 | 10.61 | 290.10 | -38.70 | 81.89 | 0.6230 | -1158.7 | -323.1 | |
| 4.52 | -10.00 | 2.84 | -10.00 | 5.30 | 290.68 | -38.12 | 90.52 | 0.6170 | -689.1 | 999999 | |
| 13.92 | -11.00 | 8.86 | -11.00 | 10.57 | 289.59 | -39.21 | 81.98 | 0.6298 | -851.9 | 999999 | |
| 0.27 | -11.00 | 0.17 | -11.00 | 10.90 | 289.50 | -39.30 | 81.46 | 0.6312 | -654.3 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.67 | 5.61 | 290.00 | -38.80 | 89.93 | 0.6259 | -447.0 | -344.8 | |
| 0.00 | 1.24 | 0.00 | 0.80 | 3.74 | 289.30 | -39.50 | 92.77 | 0.6378 | -628.0 | -465.5 | |
| 0.00 | 1.60 | 0.00 | 1.04 | 5.98 | 288.15 | -40.65 | 89.14 | 0.6502 | 824.0 | 632.3 | |
| 0.00 | 1.24 | 0.00 | 0.81 | 5.62 | 288.14 | -40.66 | 89.69 | 0.6507 | 739.0 | 597.5 | |
| 0.00 | 0.98 | 0.00 | 0.64 | 5.44 | 287.47 | -41.33 | 89.88 | 0.6597 | 663.0 | 537.4 | |
| 0.00 | 0.89 | 0.00 | 0.60 | 5.94 | 285.42 | -43.38 | 88.91 | 0.6856 | 792.0 | 687.4 | |
| 0.00 | 0.71 | 0.00 | 0.48 | 6.11 | 285.27 | -43.53 | 88.65 | 0.6873 | 693.0 | 621.9 | |
| 0.00 | 1.60 | 0.00 | 1.09 | 5.11 | 284.95 | -43.86 | 90.06 | 0.6924 | 727.0 | 613.5 | |
| 0.00 | 0.27 | 0.00 | 0.18 | 5.01 | 284.79 | -44.01 | 90.19 | 0.6945 | 640.0 | 655.7 | |
| 0.53 | 1.60 | 0.37 | 1.11 | 4.80 | 284.12 | -44.68 | 90.40 | 0.7030 | 473.7 | 421.3 | |
| 0.00 | 0.71 | 0.00 | 0.50 | 7.55 | 283.40 | -45.40 | 86.43 | 0.7096 | 492.0 | 309.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
