SDO HMI 2014-09-20 20:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 78.20 | 357.35 | 70.52 | 327.85 | -9.78 | 264.04 | -54.87 | 106.49 | 0.8406 | 199.1 | 42.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-20 20:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.71 | 0.00 | 0.54 | -8.30 | 272.04 | -46.87 | 107.44 | 0.7593 | 348.0 | 303.1 | |
| 0.00 | 0.62 | 0.00 | 0.47 | -6.45 | 271.54 | -47.37 | 104.91 | 0.7589 | 268.0 | 346.6 | |
| 22.76 | 176.07 | 18.92 | 147.09 | -8.59 | 267.69 | -51.22 | 106.25 | 0.8051 | 966.1 | 281.7 | |
| 15.32 | -3.00 | 12.86 | -3.00 | -8.39 | 267.19 | -51.72 | 105.85 | 0.8095 | 730.4 | 999999 | |
| 1.68 | -3.00 | 1.42 | -3.00 | -8.14 | 266.89 | -52.02 | 105.46 | 0.8117 | 647.9 | 999999 | |
| 4.07 | 42.95 | 3.52 | 37.52 | -8.23 | 265.92 | -52.99 | 105.27 | 0.8214 | 544.4 | 119.1 | |
| 0.00 | 3.63 | 0.00 | 3.15 | -8.61 | 265.84 | -53.07 | 105.70 | 0.8231 | 609.0 | 377.8 | |
| 0.00 | 2.48 | 0.00 | 2.17 | -8.96 | 265.51 | -53.40 | 106.00 | 0.8271 | -352.0 | -241.5 | |
| 3.28 | -6.00 | 2.84 | -6.00 | -7.85 | 265.69 | -53.22 | 104.75 | 0.8227 | 622.8 | 999999 | |
| 6.82 | -6.00 | 5.96 | -6.00 | -8.28 | 265.45 | -53.46 | 105.18 | 0.8260 | 460.9 | 999999 | |
| 0.00 | 0.80 | 0.00 | 0.70 | -8.73 | 265.30 | -53.60 | 105.67 | 0.8285 | -316.0 | -300.0 | |
| 2.48 | -6.00 | 2.19 | -6.00 | -8.23 | 265.05 | -53.86 | 105.00 | 0.8296 | -279.5 | 999999 | |
| 0.00 | 1.15 | 0.00 | 1.06 | -9.77 | 263.64 | -55.27 | 106.37 | 0.8462 | 177.0 | 151.8 | |
| 0.00 | 0.80 | 0.00 | 0.74 | -9.77 | 263.37 | -55.54 | 106.28 | 0.8486 | 205.0 | 159.9 | |
| 0.80 | 2.21 | 0.76 | 2.11 | -9.96 | 262.49 | -56.42 | 106.24 | 0.8567 | -565.0 | -503.4 | |
| 0.89 | 1.59 | 0.85 | 1.53 | -9.30 | 262.22 | -56.69 | 105.41 | 0.8575 | -348.3 | -460.3 | |
| 0.00 | 1.68 | 0.00 | 1.59 | -8.44 | 262.37 | -56.54 | 104.48 | 0.8544 | -352.0 | -327.8 | |
| 0.00 | 1.06 | 0.00 | 1.03 | -9.24 | 261.90 | -57.01 | 105.25 | 0.8602 | -246.0 | -279.8 | |
| 0.00 | 0.53 | 0.00 | 0.52 | -9.73 | 261.65 | -57.26 | 105.74 | 0.8633 | -326.0 | -408.3 | |
| 0.00 | 0.62 | 0.00 | 0.60 | -8.52 | 261.68 | -57.23 | 104.38 | 0.8605 | -301.0 | -245.3 | |
| 0.00 | 1.33 | 0.00 | 1.36 | -10.96 | 260.42 | -58.49 | 106.76 | 0.8761 | -379.0 | -409.1 | |
| 0.00 | 0.53 | 0.00 | 0.55 | -10.90 | 260.14 | -58.76 | 106.61 | 0.8782 | -606.0 | -578.0 | |
| 17.09 | 117.53 | 18.07 | 124.00 | -12.06 | 259.56 | -59.35 | 107.73 | 0.8851 | -821.9 | -210.1 | |
| 3.01 | -23.00 | 3.13 | -23.00 | -10.68 | 259.79 | -59.12 | 106.28 | 0.8805 | -141.0 | 999999 | |
| 0.00 | 1.06 | 0.00 | 1.12 | -11.07 | 259.42 | -59.48 | 106.60 | 0.8842 | -291.0 | -239.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
