SDO HMI 2014-09-21 04:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 84.47 | 377.58 | 69.54 | 313.55 | -10.03 | 263.87 | -50.63 | 108.17 | 0.8013 | 129.0 | 52.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-21 04:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.80 | 0.00 | 0.56 | -8.30 | 272.23 | -42.27 | 109.35 | 0.7077 | 500.0 | 333.4 | |
| 0.00 | 1.15 | 0.00 | 0.81 | -7.29 | 271.41 | -43.09 | 107.63 | 0.7134 | 526.0 | 428.7 | |
| 15.16 | 159.01 | 11.40 | 120.06 | -8.63 | 268.12 | -46.38 | 108.05 | 0.7550 | 1063.2 | 365.6 | |
| 2.30 | -3.00 | 1.75 | -3.00 | -8.92 | 267.68 | -46.83 | 108.24 | 0.7609 | 656.8 | 999999 | |
| 14.36 | -3.00 | 10.92 | -3.00 | -8.53 | 267.52 | -46.99 | 107.69 | 0.7613 | 749.4 | 999999 | |
| 4.52 | 7.71 | 3.48 | 5.94 | -8.25 | 266.84 | -47.66 | 107.08 | 0.7676 | 687.4 | 469.7 | |
| 0.00 | 0.53 | 0.00 | 0.40 | -5.42 | 266.73 | -47.78 | 103.45 | 0.7603 | 409.0 | 382.2 | |
| 0.71 | 43.17 | 0.55 | 33.88 | -8.57 | 266.15 | -48.35 | 107.22 | 0.7759 | 669.9 | 172.9 | |
| 10.64 | -8.00 | 8.31 | -8.00 | -8.26 | 266.06 | -48.44 | 106.81 | 0.7758 | 740.3 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.56 | -8.95 | 265.71 | -48.79 | 107.53 | 0.7816 | 141.0 | 118.4 | |
| 5.23 | -8.00 | 4.09 | -8.00 | -7.72 | 265.87 | -48.63 | 106.07 | 0.7762 | 608.9 | 999999 | |
| 0.00 | 3.28 | 0.00 | 2.61 | -9.04 | 265.46 | -49.04 | 107.55 | 0.7845 | -224.0 | -233.4 | |
| 1.06 | 2.92 | 0.85 | 2.34 | -8.67 | 265.11 | -49.40 | 106.97 | 0.7870 | 349.4 | 206.0 | |
| 0.00 | 1.86 | 0.00 | 1.48 | -8.23 | 265.14 | -49.37 | 106.44 | 0.7853 | 119.0 | 27.7 | |
| 0.00 | 1.06 | 0.00 | 0.86 | -9.54 | 264.80 | -49.71 | 107.92 | 0.7928 | -607.0 | -521.3 | |
| 0.00 | 0.62 | 0.00 | 0.50 | -8.49 | 264.71 | -49.79 | 106.61 | 0.7904 | 221.0 | 161.9 | |
| 0.00 | 0.53 | 0.00 | 0.48 | -15.50 | 262.25 | -52.25 | 113.92 | 0.8357 | 384.0 | 344.0 | |
| 0.00 | 1.86 | 0.00 | 1.52 | -8.40 | 264.01 | -50.49 | 106.26 | 0.7973 | -374.0 | -285.6 | |
| 1.15 | 3.10 | 0.96 | 2.60 | -9.90 | 263.37 | -51.13 | 107.84 | 0.8080 | 277.6 | -48.3 | |
| 2.39 | 6.47 | 2.06 | 5.57 | -10.04 | 262.20 | -52.31 | 107.62 | 0.8197 | -696.6 | -572.7 | |
| 0.00 | 1.33 | 0.00 | 1.14 | -9.60 | 262.30 | -52.20 | 107.12 | 0.8175 | -680.0 | -624.6 | |
| 0.00 | 1.42 | 0.00 | 1.22 | -9.60 | 261.95 | -52.56 | 107.01 | 0.8208 | -552.0 | -402.6 | |
| 0.00 | 1.24 | 0.00 | 1.12 | -10.85 | 260.40 | -54.10 | 107.96 | 0.8385 | -567.0 | -479.7 | |
| 0.00 | 1.06 | 0.00 | 0.97 | -11.12 | 260.27 | -54.23 | 108.23 | 0.8403 | -656.0 | -623.6 | |
| 0.00 | 1.95 | 0.00 | 1.76 | -10.61 | 260.36 | -54.14 | 107.67 | 0.8382 | -509.0 | -349.3 | |
| 0.00 | 0.89 | 0.00 | 0.81 | -11.13 | 260.11 | -54.39 | 108.19 | 0.8418 | -703.0 | -636.8 | |
| 2.13 | 129.14 | 1.94 | 120.95 | -10.74 | 260.01 | -54.49 | 107.70 | 0.8417 | -63.5 | -215.9 | |
| 22.25 | -27.00 | 20.85 | -27.00 | -12.31 | 259.44 | -55.06 | 109.31 | 0.8508 | -736.3 | 999999 | |
| 2.57 | -27.00 | 2.38 | -27.00 | -11.72 | 259.62 | -54.88 | 108.70 | 0.8477 | -840.0 | 999999 | |
| 0.00 | 0.27 | 0.00 | 0.25 | -11.02 | 259.12 | -55.38 | 107.75 | 0.8502 | 175.0 | 205.7 | |
| 0.00 | 1.86 | 0.00 | 1.75 | -11.16 | 258.97 | -55.53 | 107.86 | 0.8518 | -323.0 | -145.2 | |
| 0.00 | 2.75 | 0.00 | 2.60 | -11.34 | 258.76 | -55.75 | 107.99 | 0.8542 | -373.0 | -224.4 | |
| 0.00 | 0.89 | 0.00 | 0.81 | -7.38 | 259.08 | -55.43 | 103.56 | 0.8421 | 137.0 | 166.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
