SDO HMI 2014-09-21 07:22:19 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 56.74 | 286.24 | 30.39 | 153.79 | 8.74 | 290.01 | -22.65 | 84.28 | 0.3867 | -690.6 | -310.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-21 07:22:19 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.98 | 0.00 | 0.51 | 12.11 | 293.63 | -19.03 | 73.53 | 0.3339 | -681.0 | -562.6 | |
| 0.00 | 3.28 | 0.00 | 1.73 | 12.74 | 293.45 | -19.21 | 71.83 | 0.3392 | -852.0 | -708.1 | |
| 0.00 | 0.89 | 0.00 | 0.47 | 12.22 | 293.49 | -19.17 | 73.29 | 0.3365 | -716.0 | -626.5 | |
| 0.00 | 3.99 | 0.00 | 2.11 | 9.86 | 291.89 | -20.77 | 80.82 | 0.3554 | -788.0 | -587.1 | |
| 3.55 | 81.02 | 1.88 | 43.15 | 5.44 | 291.40 | -21.26 | 93.21 | 0.3631 | -1078.2 | -419.7 | |
| 0.00 | 2.84 | 0.00 | 1.51 | 9.05 | 291.23 | -21.44 | 83.23 | 0.3650 | -756.0 | -641.8 | |
| 18.26 | -5.00 | 9.71 | -5.00 | 5.13 | 291.28 | -21.38 | 94.01 | 0.3656 | -1150.3 | 999999 | |
| 0.00 | 4.79 | 0.00 | 2.55 | 5.86 | 291.22 | -21.44 | 92.03 | 0.3654 | -338.0 | -252.5 | |
| 33.51 | 162.48 | 18.01 | 87.34 | 10.86 | 289.88 | -22.79 | 78.78 | 0.3894 | -1169.2 | -401.7 | |
| 0.00 | 2.13 | 0.00 | 1.15 | 9.12 | 289.37 | -23.29 | 83.35 | 0.3947 | 755.0 | 604.2 | |
| 0.00 | 1.15 | 0.00 | 0.62 | 2.95 | 289.02 | -23.64 | 98.76 | 0.4069 | -600.0 | -415.8 | |
| 0.00 | 4.52 | 0.00 | 2.48 | 5.48 | 287.08 | -25.58 | 92.12 | 0.4320 | 651.0 | 630.9 | |
| 0.00 | 2.48 | 0.00 | 1.37 | 5.67 | 286.16 | -26.50 | 91.51 | 0.4461 | 688.0 | 585.5 | |
| 1.42 | 6.47 | 0.79 | 3.60 | 5.21 | 285.40 | -27.26 | 92.39 | 0.4585 | 1012.2 | 792.8 | |
| 0.00 | 1.42 | 0.00 | 0.79 | 4.90 | 285.38 | -27.28 | 93.05 | 0.4593 | 617.0 | 535.9 | |
| 0.00 | 2.39 | 0.00 | 1.33 | 5.50 | 285.32 | -27.34 | 91.73 | 0.4593 | 861.0 | 694.9 | |
| 0.00 | 0.89 | 0.00 | 0.50 | 6.01 | 283.71 | -28.95 | 90.39 | 0.4834 | 539.0 | 423.2 | |
| 0.00 | 1.24 | 0.00 | 0.70 | 8.14 | 283.39 | -29.27 | 85.98 | 0.4872 | 560.0 | 484.4 | |
| 0.00 | 1.33 | 0.00 | 0.75 | 6.41 | 283.30 | -29.36 | 89.52 | 0.4892 | 566.0 | 421.5 | |
| 0.00 | 1.06 | 0.00 | 0.61 | 4.33 | 282.85 | -29.81 | 93.65 | 0.4987 | 732.0 | 644.2 | |
| 0.00 | 0.89 | 0.00 | 0.52 | 18.52 | 280.75 | -31.91 | 66.69 | 0.5479 | -511.0 | -361.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
