SDO HMI 2014-09-21 14:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.53 | 14.80 | 0.30 | 8.44 | -14.31 | 289.54 | -19.48 | 139.44 | 0.4837 | 745.6 | 594.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-21 14:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.51 | 0.00 | 0.79 | -10.50 | 299.81 | -9.21 | 152.35 | 0.3404 | 802.0 | 613.2 | |
| 0.00 | 3.10 | 0.00 | 1.62 | -9.07 | 299.21 | -9.81 | 148.63 | 0.3247 | 947.0 | 698.2 | |
| 0.53 | 3.10 | 0.30 | 1.73 | -14.10 | 291.11 | -17.91 | 139.99 | 0.4658 | 799.5 | 700.7 | |
| 0.00 | 1.06 | 0.00 | 0.61 | -14.65 | 287.33 | -21.69 | 135.31 | 0.5106 | 689.0 | 536.2 | |
| 0.00 | 0.89 | 0.00 | 0.52 | -17.01 | 286.44 | -22.58 | 137.37 | 0.5443 | 722.0 | 523.1 | |
| 0.00 | 0.80 | 0.00 | 0.48 | -20.00 | 285.95 | -23.07 | 140.43 | 0.5804 | 648.0 | 576.0 | |
| 0.00 | 2.30 | 0.00 | 1.51 | -23.15 | 280.88 | -28.14 | 138.49 | 0.6565 | 548.0 | 404.1 | |
| 0.00 | 2.04 | 0.00 | 1.18 | -9.38 | 282.16 | -26.86 | 121.21 | 0.5233 | 793.0 | 624.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
