SDO HMI 2014-09-21 14:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 8.15 | 0.00 | 6.01 | 15.15 | 260.93 | -48.09 | 75.95 | 0.7422 | 28.8 | -207.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-21 14:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.72 | 0.00 | 2.64 | 14.39 | 263.01 | -46.01 | 76.77 | 0.7182 | -766.0 | -633.2 | |
| 0.00 | 1.42 | 0.00 | 1.02 | 14.56 | 262.24 | -46.78 | 76.60 | 0.7274 | -555.0 | -446.6 | |
| 0.00 | 1.06 | 0.00 | 0.81 | 16.28 | 259.06 | -49.96 | 74.61 | 0.7645 | 490.0 | 330.8 | |
| 0.00 | 0.71 | 0.00 | 0.56 | 15.91 | 257.70 | -51.32 | 75.22 | 0.7787 | 542.0 | 465.5 | |
| 0.00 | 1.24 | 0.00 | 0.98 | 16.43 | 257.36 | -51.66 | 74.57 | 0.7827 | 433.0 | 358.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
