SDO HMI 2014-09-21 15:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 7.52 | 0.00 | 4.23 | -21.10 | 310.75 | 2.28 | 184.58 | 0.4757 | -461.2 | -369.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-21 15:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.33 | 0.00 | 0.73 | -19.01 | 312.26 | 3.79 | 188.10 | 0.4456 | 700.0 | 518.8 | |
| 0.00 | 1.86 | 0.00 | 1.05 | -21.31 | 311.64 | 3.17 | 186.18 | 0.4797 | -687.0 | -568.8 | |
| 0.00 | 0.97 | 0.00 | 0.55 | -20.93 | 311.56 | 3.09 | 186.13 | 0.4739 | -715.0 | -521.5 | |
| 0.00 | 1.06 | 0.00 | 0.60 | -22.02 | 309.64 | 1.17 | 182.23 | 0.4884 | -602.0 | -514.4 | |
| 0.00 | 1.33 | 0.00 | 0.75 | -21.70 | 309.47 | 1.00 | 181.94 | 0.4835 | -762.0 | -615.9 | |
| 0.00 | 0.97 | 0.00 | 0.55 | -21.81 | 309.21 | 0.74 | 181.43 | 0.4850 | -701.0 | -529.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
