SDO HMI 2014-09-22 18:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 186.05 | 1029.86 | 170.35 | 951.25 | -11.04 | 238.82 | -54.80 | 107.99 | 0.8434 | 17.6 | -51.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-22 18:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.35 | 0.00 | 0.28 | -10.59 | 244.97 | -48.64 | 109.55 | 0.7852 | 553.0 | 612.2 | |
| 0.00 | 0.35 | 0.00 | 0.29 | -12.64 | 243.57 | -50.04 | 111.46 | 0.8059 | 558.0 | 503.5 | |
| 15.93 | 67.50 | 12.75 | 53.90 | -9.15 | 244.28 | -49.33 | 107.54 | 0.7876 | 898.5 | 498.8 | |
| 0.00 | 2.03 | 0.00 | 1.70 | -12.64 | 243.33 | -50.28 | 111.36 | 0.8081 | 631.0 | 595.5 | |
| 0.00 | 4.07 | 0.00 | 3.44 | -12.99 | 242.94 | -50.67 | 111.62 | 0.8130 | 605.0 | 427.6 | |
| 0.00 | 0.97 | 0.00 | 0.82 | -12.60 | 243.00 | -50.61 | 111.20 | 0.8112 | 388.0 | 473.5 | |
| 39.81 | 403.70 | 32.84 | 338.90 | -10.90 | 243.39 | -50.22 | 109.32 | 0.8020 | 958.0 | 230.3 | |
| 0.00 | 2.74 | 0.00 | 2.31 | -11.86 | 242.86 | -50.76 | 110.27 | 0.8102 | 689.0 | 507.6 | |
| 1.86 | -7.00 | 1.57 | -7.00 | -11.48 | 242.57 | -51.05 | 109.71 | 0.8118 | 649.5 | 999999 | |
| 4.87 | -7.00 | 4.13 | -7.00 | -11.77 | 242.44 | -51.17 | 110.01 | 0.8139 | 615.6 | 999999 | |
| 3.80 | -7.00 | 3.20 | -7.00 | -11.13 | 242.56 | -51.06 | 109.30 | 0.8108 | 558.9 | 999999 | |
| 3.01 | -7.00 | 2.52 | -7.00 | -10.62 | 242.68 | -50.94 | 108.74 | 0.8081 | 726.5 | 999999 | |
| 0.00 | 1.33 | 0.00 | 1.14 | -12.64 | 242.00 | -51.61 | 110.86 | 0.8207 | 420.0 | 376.4 | |
| 4.25 | -7.00 | 3.62 | -7.00 | -11.61 | 242.19 | -51.43 | 109.73 | 0.8158 | 529.0 | 999999 | |
| 0.27 | -7.00 | 0.23 | -7.00 | -11.14 | 242.21 | -51.41 | 109.18 | 0.8141 | 346.7 | 999999 | |
| 8.67 | -7.00 | 7.31 | -7.00 | -10.50 | 242.32 | -51.30 | 108.46 | 0.8112 | 595.2 | 999999 | |
| 0.00 | 1.50 | 0.00 | 1.24 | -8.87 | 242.67 | -50.95 | 106.64 | 0.8031 | 416.0 | 379.4 | |
| 2.74 | -7.00 | 2.34 | -7.00 | -11.31 | 242.07 | -51.55 | 109.33 | 0.8160 | 393.5 | 999999 | |
| 0.35 | 2.03 | 0.31 | 1.76 | -12.32 | 241.75 | -51.87 | 110.39 | 0.8221 | 450.8 | 336.1 | |
| 0.00 | 1.06 | 0.00 | 0.91 | -11.89 | 241.86 | -51.75 | 109.94 | 0.8197 | 205.0 | 216.5 | |
| 2.12 | -7.00 | 1.80 | -7.00 | -10.72 | 242.02 | -51.60 | 108.61 | 0.8147 | 295.7 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.91 | -11.72 | 241.76 | -51.85 | 109.70 | 0.8201 | 134.0 | 108.2 | |
| 0.97 | -7.00 | 0.83 | -7.00 | -11.30 | 241.82 | -51.79 | 109.23 | 0.8183 | 268.9 | 999999 | |
| 0.00 | 0.88 | 0.00 | 0.74 | -8.29 | 242.29 | -51.32 | 105.82 | 0.8052 | 423.0 | 336.3 | |
| 0.00 | 0.62 | 0.00 | 0.54 | -11.89 | 241.31 | -52.30 | 109.74 | 0.8248 | 356.0 | 294.1 | |
| 0.53 | 1.59 | 0.46 | 1.39 | -11.84 | 241.12 | -52.49 | 109.62 | 0.8264 | 371.5 | 303.7 | |
| 0.00 | 0.97 | 0.00 | 0.87 | -12.77 | 240.65 | -52.97 | 110.52 | 0.8335 | 262.0 | 254.8 | |
| 4.69 | -7.00 | 4.11 | -7.00 | -11.36 | 240.90 | -52.72 | 108.98 | 0.8271 | 354.1 | 999999 | |
| 0.00 | 0.88 | 0.00 | 0.78 | -11.94 | 240.74 | -52.88 | 109.60 | 0.8302 | 312.0 | 282.6 | |
| 2.39 | -7.00 | 2.09 | -7.00 | -10.98 | 240.95 | -52.67 | 108.55 | 0.8255 | 392.2 | 999999 | |
| 0.88 | -7.00 | 0.78 | -7.00 | -11.33 | 240.60 | -53.02 | 108.84 | 0.8297 | 98.4 | 999999 | |
| 0.00 | 0.97 | 0.00 | 0.88 | -12.17 | 240.10 | -53.51 | 109.64 | 0.8366 | 411.0 | 378.9 | |
| 0.00 | 1.15 | 0.00 | 1.03 | -11.97 | 240.16 | -53.45 | 109.43 | 0.8355 | 490.0 | 417.3 | |
| 0.00 | 0.88 | 0.00 | 0.77 | -9.31 | 240.43 | -53.18 | 106.44 | 0.8258 | -650.0 | -585.8 | |
| 4.25 | 49.63 | 3.85 | 45.65 | -11.74 | 239.60 | -54.02 | 108.98 | 0.8399 | 398.0 | -97.3 | |
| 0.00 | 1.68 | 0.00 | 1.49 | -10.32 | 239.98 | -53.63 | 107.47 | 0.8326 | -232.0 | -97.1 | |
| 0.00 | 1.33 | 0.00 | 1.18 | -10.46 | 239.90 | -53.72 | 107.60 | 0.8338 | -314.0 | -233.9 | |
| 0.00 | 0.88 | 0.00 | 0.78 | -9.18 | 240.15 | -53.46 | 106.20 | 0.8281 | -684.0 | -583.3 | |
| 1.68 | -35.00 | 1.54 | -35.00 | -12.00 | 239.26 | -54.36 | 109.16 | 0.8436 | 301.1 | 999999 | |
| 0.00 | 1.24 | 0.00 | 1.12 | -10.83 | 239.33 | -54.29 | 107.85 | 0.8399 | -382.0 | -322.3 | |
| 0.00 | 4.16 | 0.00 | 3.81 | -11.21 | 239.01 | -54.60 | 108.18 | 0.8437 | -684.0 | -565.7 | |
| 0.00 | 1.15 | 0.00 | 1.03 | -9.25 | 239.46 | -54.15 | 106.07 | 0.8347 | -605.0 | -592.2 | |
| 0.00 | 0.97 | 0.00 | 0.87 | -9.11 | 239.28 | -54.33 | 105.85 | 0.8360 | -646.0 | -562.5 | |
| 3.36 | 4.69 | 3.16 | 4.40 | -11.45 | 238.19 | -55.43 | 108.19 | 0.8516 | -766.3 | -613.8 | |
| 0.71 | 1.68 | 0.67 | 1.59 | -11.81 | 238.02 | -55.59 | 108.55 | 0.8539 | -48.8 | -136.3 | |
| 0.00 | 0.71 | 0.00 | 0.64 | -9.14 | 238.69 | -54.92 | 105.71 | 0.8414 | -654.0 | -685.0 | |
| 0.00 | 1.24 | 0.00 | 1.13 | -9.12 | 238.59 | -55.02 | 105.66 | 0.8423 | -559.0 | -531.0 | |
| 2.12 | 26.72 | 1.96 | 24.71 | -9.93 | 238.34 | -55.28 | 106.51 | 0.8465 | -905.5 | -609.6 | |
| 3.72 | -48.00 | 3.46 | -48.00 | -10.10 | 238.19 | -55.43 | 106.66 | 0.8483 | -840.3 | 999999 | |
| 0.00 | 0.80 | 0.00 | 0.77 | -12.15 | 237.47 | -56.14 | 108.76 | 0.8594 | -597.0 | -499.6 | |
| 0.71 | 1.86 | 0.68 | 1.78 | -11.64 | 237.58 | -56.03 | 108.21 | 0.8572 | -530.9 | -469.8 | |
| 0.00 | 1.33 | 0.00 | 1.29 | -12.75 | 237.16 | -56.46 | 109.33 | 0.8635 | -630.0 | -592.7 | |
| 0.00 | 1.33 | 0.00 | 1.25 | -10.49 | 237.75 | -55.86 | 106.97 | 0.8530 | -559.0 | -517.9 | |
| 0.00 | 1.50 | 0.00 | 1.43 | -10.71 | 237.41 | -56.20 | 107.12 | 0.8564 | -231.0 | -212.6 | |
| 0.00 | 1.15 | 0.00 | 1.13 | -11.63 | 236.74 | -56.87 | 107.95 | 0.8642 | -415.0 | -424.6 | |
| 0.00 | 1.59 | 0.00 | 1.57 | -11.54 | 236.43 | -57.18 | 107.75 | 0.8666 | -581.0 | -513.0 | |
| 1.77 | 418.83 | 1.74 | 429.44 | -10.96 | 236.27 | -57.34 | 107.06 | 0.8666 | -891.7 | -299.3 | |
| 2.03 | -57.00 | 2.04 | -57.00 | -11.27 | 235.71 | -57.90 | 107.24 | 0.8719 | -836.0 | 999999 | |
| 2.21 | -57.00 | 2.29 | -57.00 | -12.41 | 235.02 | -58.59 | 108.30 | 0.8799 | -626.3 | 999999 | |
| 0.00 | 1.50 | 0.00 | 1.60 | -13.61 | 234.50 | -59.12 | 109.46 | 0.8866 | -266.0 | -327.4 | |
| 52.46 | -57.00 | 53.31 | -57.00 | -10.85 | 235.20 | -58.41 | 106.63 | 0.8751 | -789.4 | 999999 | |
| 7.43 | -57.00 | 7.84 | -57.00 | -12.51 | 234.38 | -59.23 | 108.23 | 0.8851 | -575.1 | 999999 | |
| 0.80 | -57.00 | 0.84 | -57.00 | -11.78 | 234.41 | -59.21 | 107.44 | 0.8833 | -346.8 | 999999 | |
| 1.15 | -57.00 | 1.22 | -57.00 | -12.61 | 234.10 | -59.51 | 108.25 | 0.8874 | -239.7 | 999999 | |
| 2.83 | -57.00 | 3.06 | -57.00 | -12.77 | 233.73 | -59.88 | 108.33 | 0.8906 | -268.3 | 999999 | |
| 0.00 | 4.78 | 0.00 | 5.28 | -12.73 | 233.00 | -60.62 | 108.07 | 0.8959 | 485.0 | 303.6 | |
| 0.00 | 1.95 | 0.00 | 2.13 | -12.13 | 233.23 | -60.38 | 107.49 | 0.8930 | 226.0 | 226.8 | |
| 0.00 | 0.53 | 0.00 | 0.58 | -12.47 | 233.04 | -60.58 | 107.80 | 0.8951 | 326.0 | 283.8 | |
| 1.68 | -57.00 | 1.80 | -57.00 | -10.85 | 233.51 | -60.10 | 106.16 | 0.8884 | 399.8 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
