SDO HMI 2014-09-23 08:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.88 | 33.73 | 21.24 | 98.48 | 15.50 | 7.60 | 81.69 | 284.60 | 0.9857 | 33.1 | -12.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-23 08:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.59 | 0.00 | 7.01 | 15.34 | 10.99 | 85.08 | 284.72 | 0.9939 | -76.0 | -16.3 | |
| 0.00 | 1.95 | 0.00 | 8.34 | 15.74 | 10.82 | 84.90 | 285.10 | 0.9935 | -80.0 | 11.2 | |
| 7.88 | 27.18 | 21.24 | 74.32 | 15.42 | 6.90 | 80.99 | 284.46 | 0.9840 | 61.0 | 9.8 | |
| 0.00 | 1.68 | 0.00 | 4.97 | 16.03 | 7.86 | 81.95 | 285.15 | 0.9866 | -238.0 | -230.3 | |
| 0.00 | 1.33 | 0.00 | 3.84 | 16.25 | 7.63 | 81.72 | 285.35 | 0.9860 | -66.0 | -86.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
