SDO HMI 2014-09-23 10:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 14.68 | 0.00 | 7.83 | -12.45 | 287.92 | 3.10 | 188.07 | 0.3629 | 746.8 | 609.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-23 10:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.50 | 0.00 | 0.81 | -9.70 | 299.97 | 15.15 | 222.27 | 0.3846 | 766.0 | 674.4 | |
| 0.00 | 1.06 | 0.00 | 0.57 | -10.17 | 299.11 | 14.29 | 219.78 | 0.3812 | 835.0 | 700.9 | |
| 0.00 | 1.06 | 0.00 | 0.57 | -11.59 | 299.08 | 14.26 | 217.42 | 0.3988 | 738.0 | 496.1 | |
| 0.00 | 1.06 | 0.00 | 0.57 | -12.08 | 298.41 | 13.59 | 215.36 | 0.3987 | 580.0 | 565.8 | |
| 0.00 | 0.97 | 0.00 | 0.49 | -4.74 | 285.81 | 0.99 | 184.82 | 0.2054 | 681.0 | 547.6 | |
| 0.00 | 1.42 | 0.00 | 0.82 | -24.08 | 285.71 | 0.89 | 181.57 | 0.5186 | 653.0 | 474.1 | |
| 0.00 | 2.39 | 0.00 | 1.25 | -11.58 | 282.28 | -2.53 | 172.26 | 0.3230 | 794.0 | 655.0 | |
| 0.00 | 1.15 | 0.00 | 0.60 | -10.34 | 282.21 | -2.61 | 171.44 | 0.3029 | 922.0 | 749.8 | |
| 0.00 | 4.07 | 0.00 | 2.15 | -12.83 | 280.88 | -3.94 | 168.83 | 0.3472 | 752.0 | 602.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
