SDO HMI 2014-09-23 11:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 230.98 | 1270.31 | 172.10 | 950.93 | -11.02 | 239.10 | -45.17 | 111.62 | 0.7490 | 26.7 | -21.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-23 11:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.50 | 16.37 | 1.01 | 10.91 | -10.71 | 245.87 | -38.40 | 114.52 | 0.6731 | 664.4 | 127.2 | |
| 0.00 | 0.97 | 0.00 | 0.66 | -12.45 | 245.42 | -38.85 | 116.60 | 0.6874 | -543.0 | -475.0 | |
| 0.00 | 0.97 | 0.00 | 0.68 | -14.16 | 244.81 | -39.46 | 118.46 | 0.7033 | 492.0 | 444.1 | |
| 0.00 | 1.95 | 0.00 | 1.31 | -10.12 | 245.33 | -38.94 | 113.41 | 0.6766 | 762.0 | 649.0 | |
| 0.00 | 0.97 | 0.00 | 0.66 | -9.53 | 244.90 | -39.37 | 112.36 | 0.6788 | 591.0 | 563.0 | |
| 19.12 | 68.15 | 12.90 | 45.92 | -9.03 | 244.45 | -39.82 | 111.44 | 0.6818 | 944.4 | 466.9 | |
| 41.95 | 428.64 | 28.85 | 296.63 | -10.89 | 243.97 | -40.30 | 113.71 | 0.6960 | 1012.2 | 370.1 | |
| 0.00 | 1.24 | 0.00 | 0.86 | -12.21 | 243.62 | -40.65 | 115.26 | 0.7064 | 58.0 | 127.1 | |
| 15.22 | -7.00 | 10.58 | -7.00 | -10.67 | 243.24 | -41.03 | 113.02 | 0.7033 | 837.0 | 999999 | |
| 0.00 | 0.53 | 0.00 | 0.37 | -12.24 | 242.96 | -41.31 | 114.93 | 0.7138 | 518.0 | 524.3 | |
| 7.61 | -7.00 | 5.31 | -7.00 | -10.99 | 243.06 | -41.21 | 113.37 | 0.7068 | 730.5 | 999999 | |
| 2.74 | -7.00 | 1.92 | -7.00 | -10.61 | 242.80 | -41.47 | 112.72 | 0.7080 | 603.6 | 999999 | |
| 21.15 | -7.00 | 14.87 | -7.00 | -11.03 | 242.65 | -41.62 | 113.20 | 0.7116 | 621.1 | 999999 | |
| 0.44 | -7.00 | 0.31 | -7.00 | -11.72 | 242.27 | -42.00 | 113.91 | 0.7190 | 510.4 | 999999 | |
| 0.00 | 1.33 | 0.00 | 0.95 | -12.24 | 242.17 | -42.10 | 114.52 | 0.7225 | 411.0 | 372.9 | |
| 7.61 | 12.48 | 5.71 | 9.36 | -16.21 | 241.10 | -43.17 | 118.89 | 0.7526 | 635.5 | 361.1 | |
| 0.53 | 2.04 | 0.38 | 1.45 | -11.69 | 241.90 | -42.37 | 113.68 | 0.7229 | 491.5 | 400.8 | |
| 0.00 | 1.86 | 0.00 | 1.33 | -11.47 | 241.90 | -42.37 | 113.39 | 0.7219 | 354.0 | 360.8 | |
| 0.00 | 2.30 | 0.00 | 1.60 | -8.18 | 242.35 | -41.92 | 109.26 | 0.7029 | 586.0 | 604.7 | |
| 0.00 | 2.57 | 0.00 | 1.85 | -11.78 | 241.55 | -42.72 | 113.62 | 0.7272 | 444.0 | 349.2 | |
| 2.66 | 103.46 | 1.90 | 74.33 | -11.09 | 241.60 | -42.67 | 112.75 | 0.7236 | 588.0 | -50.0 | |
| 2.48 | -21.00 | 1.77 | -21.00 | -10.81 | 241.52 | -42.75 | 112.35 | 0.7232 | 611.2 | 999999 | |
| 1.15 | -21.00 | 0.82 | -21.00 | -10.50 | 241.41 | -42.86 | 111.90 | 0.7232 | 440.8 | 999999 | |
| 1.33 | -21.00 | 0.95 | -21.00 | -10.86 | 241.35 | -42.92 | 112.33 | 0.7254 | 351.0 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.77 | -11.75 | 240.84 | -43.43 | 113.23 | 0.7348 | 419.0 | 436.6 | |
| 0.00 | 3.10 | 0.00 | 2.37 | -14.91 | 239.36 | -44.91 | 116.41 | 0.7640 | -666.0 | -592.8 | |
| 0.00 | 1.06 | 0.00 | 0.79 | -12.78 | 239.89 | -44.38 | 114.07 | 0.7493 | 382.0 | 344.5 | |
| 1.24 | 21.51 | 0.91 | 15.88 | -11.70 | 239.99 | -44.28 | 112.76 | 0.7437 | 424.2 | 182.1 | |
| 1.24 | -28.00 | 0.91 | -28.00 | -11.28 | 240.03 | -44.24 | 112.25 | 0.7415 | 610.9 | 999999 | |
| 0.00 | 0.89 | 0.00 | 0.65 | -10.78 | 240.05 | -44.23 | 111.62 | 0.7393 | 322.0 | 211.3 | |
| 0.00 | 1.15 | 0.00 | 0.85 | -10.73 | 239.84 | -44.43 | 111.47 | 0.7414 | 231.0 | 113.4 | |
| 0.00 | 1.06 | 0.00 | 0.77 | -9.21 | 239.76 | -44.51 | 109.48 | 0.7363 | -724.0 | -650.9 | |
| 0.00 | 2.57 | 0.00 | 1.91 | -11.16 | 239.32 | -44.95 | 111.77 | 0.7486 | 337.0 | 273.5 | |
| 0.00 | 1.59 | 0.00 | 1.17 | -9.32 | 239.53 | -44.74 | 109.52 | 0.7393 | -198.0 | -270.1 | |
| 0.00 | 0.97 | 0.00 | 0.71 | -9.10 | 239.57 | -44.70 | 109.25 | 0.7381 | -616.0 | -522.7 | |
| 0.00 | 1.15 | 0.00 | 0.87 | -12.24 | 238.88 | -45.39 | 112.92 | 0.7577 | 424.0 | 370.5 | |
| 0.00 | 1.15 | 0.00 | 0.87 | -12.04 | 238.92 | -45.35 | 112.70 | 0.7565 | 487.0 | 398.4 | |
| 0.00 | 0.71 | 0.00 | 0.53 | -11.40 | 238.71 | -45.57 | 111.80 | 0.7562 | 222.0 | 160.9 | |
| 0.00 | 1.15 | 0.00 | 0.88 | -12.60 | 238.40 | -45.88 | 113.14 | 0.7641 | 239.0 | 88.8 | |
| 0.00 | 1.59 | 0.00 | 1.21 | -11.78 | 238.36 | -45.91 | 112.11 | 0.7613 | -217.0 | -218.2 | |
| 0.00 | 1.06 | 0.00 | 0.80 | -11.20 | 238.48 | -45.79 | 111.45 | 0.7577 | -290.0 | -223.2 | |
| 1.06 | 2.21 | 0.79 | 1.64 | -8.95 | 238.81 | -45.46 | 108.74 | 0.7458 | -657.2 | -534.8 | |
| 0.00 | 5.84 | 0.00 | 4.45 | -11.39 | 238.09 | -46.18 | 111.52 | 0.7626 | -717.0 | -559.1 | |
| 0.00 | 0.97 | 0.00 | 0.76 | -13.05 | 237.66 | -46.61 | 113.36 | 0.7734 | -523.0 | -588.5 | |
| 0.00 | 1.06 | 0.00 | 0.82 | -11.92 | 237.84 | -46.43 | 112.06 | 0.7672 | -760.0 | -694.2 | |
| 0.00 | 0.80 | 0.00 | 0.60 | -9.38 | 238.21 | -46.06 | 109.04 | 0.7539 | -562.0 | -536.3 | |
| 1.95 | 13.36 | 1.47 | 10.08 | -9.73 | 238.11 | -46.17 | 109.45 | 0.7563 | -761.1 | -531.5 | |
| 3.89 | -47.00 | 2.95 | -47.00 | -9.93 | 237.98 | -46.29 | 109.64 | 0.7583 | -745.0 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.53 | -9.24 | 238.02 | -46.26 | 108.79 | 0.7555 | -597.0 | -545.6 | |
| 4.78 | 16.90 | 3.73 | 13.16 | -12.54 | 237.29 | -46.98 | 112.58 | 0.7752 | -793.3 | -497.2 | |
| 0.00 | 1.15 | 0.00 | 0.89 | -11.64 | 237.45 | -46.82 | 111.55 | 0.7702 | -728.0 | -583.2 | |
| 0.00 | 1.59 | 0.00 | 1.22 | -10.46 | 237.61 | -46.66 | 110.16 | 0.7642 | -525.0 | -576.7 | |
| 0.00 | 1.33 | 0.00 | 1.01 | -9.67 | 237.72 | -46.55 | 109.21 | 0.7602 | 372.0 | 227.6 | |
| 0.00 | 1.68 | 0.00 | 1.29 | -10.06 | 237.19 | -47.08 | 109.49 | 0.7671 | -663.0 | -543.1 | |
| 0.00 | 1.42 | 0.00 | 1.16 | -14.78 | 235.85 | -48.42 | 114.62 | 0.7979 | 221.0 | 239.8 | |
| 0.00 | 0.80 | 0.00 | 0.64 | -12.82 | 236.30 | -47.97 | 112.49 | 0.7862 | -640.0 | -568.4 | |
| 0.00 | 2.92 | 0.00 | 2.38 | -14.18 | 235.79 | -48.48 | 113.89 | 0.7962 | -338.0 | -287.3 | |
| 0.00 | 0.80 | 0.00 | 0.65 | -13.97 | 235.61 | -48.66 | 113.57 | 0.7971 | -569.0 | -579.4 | |
| 0.00 | 1.24 | 0.00 | 0.95 | -8.48 | 236.80 | -47.47 | 107.36 | 0.7659 | 363.0 | 326.1 | |
| 0.00 | 1.06 | 0.00 | 0.86 | -13.29 | 235.76 | -48.51 | 112.82 | 0.7932 | -668.0 | -522.5 | |
| 0.00 | 0.53 | 0.00 | 0.43 | -14.07 | 235.54 | -48.73 | 113.66 | 0.7982 | -579.0 | -595.3 | |
| 1.42 | 497.05 | 1.11 | 403.59 | -10.42 | 236.40 | -47.88 | 109.61 | 0.7767 | -869.2 | -308.7 | |
| 0.00 | 1.50 | 0.00 | 1.16 | -8.99 | 236.62 | -47.65 | 107.94 | 0.7695 | -20.0 | -119.6 | |
| 0.00 | 1.68 | 0.00 | 1.40 | -14.87 | 235.20 | -49.07 | 114.45 | 0.8044 | 383.0 | 292.1 | |
| 0.00 | 1.59 | 0.00 | 1.32 | -15.04 | 235.15 | -49.12 | 114.62 | 0.8055 | 229.0 | 211.2 | |
| 0.00 | 1.95 | 0.00 | 1.58 | -13.05 | 235.59 | -48.68 | 112.47 | 0.7940 | -576.0 | -434.8 | |
| 1.77 | -62.00 | 1.41 | -62.00 | -11.26 | 235.80 | -48.47 | 110.40 | 0.7857 | -728.6 | 999999 | |
| 1.50 | 12.30 | 1.23 | 10.02 | -12.66 | 235.03 | -49.24 | 111.77 | 0.7981 | -588.2 | -460.4 | |
| 0.00 | 1.15 | 0.00 | 0.89 | -7.44 | 235.87 | -48.40 | 105.74 | 0.7726 | -569.0 | -424.7 | |
| 65.94 | -62.00 | 53.14 | -62.00 | -10.76 | 235.12 | -49.16 | 109.53 | 0.7908 | -802.1 | 999999 | |
| 2.74 | -62.00 | 2.25 | -62.00 | -12.30 | 234.74 | -49.53 | 111.24 | 0.7997 | -805.8 | 999999 | |
| 10.71 | -62.00 | 8.88 | -62.00 | -12.53 | 234.35 | -49.93 | 111.35 | 0.8043 | -685.4 | 999999 | |
| 0.00 | 1.33 | 0.00 | 1.04 | -7.39 | 235.42 | -48.85 | 105.52 | 0.7773 | -614.0 | -539.8 | |
| 0.00 | 1.68 | 0.00 | 1.32 | -7.18 | 235.41 | -48.87 | 105.25 | 0.7768 | -614.0 | -505.5 | |
| 1.24 | -62.00 | 1.03 | -62.00 | -12.11 | 234.17 | -50.10 | 110.78 | 0.8045 | -545.7 | 999999 | |
| 1.15 | -62.00 | 0.96 | -62.00 | -12.27 | 234.08 | -50.19 | 110.94 | 0.8060 | -411.2 | 999999 | |
| 1.86 | -62.00 | 1.56 | -62.00 | -12.93 | 233.85 | -50.42 | 111.63 | 0.8103 | -606.7 | 999999 | |
| 1.50 | -62.00 | 1.24 | -62.00 | -10.68 | 233.99 | -50.28 | 109.02 | 0.8017 | -78.6 | 999999 | |
| 0.00 | 4.25 | 0.00 | 3.58 | -12.36 | 233.52 | -50.75 | 110.83 | 0.8116 | -184.0 | -169.1 | |
| 1.50 | -62.00 | 1.25 | -62.00 | -10.36 | 233.73 | -50.54 | 108.54 | 0.8033 | -329.3 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.60 | -10.14 | 232.40 | -51.87 | 107.82 | 0.8155 | -349.0 | -260.4 | |
| 0.00 | 1.15 | 0.00 | 1.01 | -11.92 | 231.59 | -52.68 | 109.62 | 0.8282 | -330.0 | -331.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
