SDO HMI 2014-09-23 12:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.15 | 33.97 | 0.78 | 22.68 | -15.09 | 247.65 | -36.08 | 121.98 | 0.6717 | -433.4 | -203.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-23 12:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.42 | 0.00 | 0.89 | -13.66 | 251.89 | -31.83 | 123.18 | 0.6146 | 501.0 | 374.6 | |
| 0.00 | 8.32 | 0.00 | 5.30 | -15.39 | 251.57 | -32.15 | 125.28 | 0.6308 | 832.0 | 676.1 | |
| 0.00 | 0.88 | 0.00 | 0.57 | -15.16 | 250.16 | -33.56 | 123.84 | 0.6447 | 623.0 | 517.0 | |
| 0.00 | 0.97 | 0.00 | 0.65 | -14.09 | 247.24 | -36.48 | 120.28 | 0.6701 | -743.0 | -581.5 | |
| 0.00 | 1.86 | 0.00 | 1.26 | -15.34 | 246.80 | -36.93 | 121.62 | 0.6827 | -224.0 | -312.6 | |
| 0.00 | 0.80 | 0.00 | 0.53 | -14.10 | 247.00 | -36.72 | 120.14 | 0.6728 | -672.0 | -534.2 | |
| 0.00 | 0.97 | 0.00 | 0.66 | -15.66 | 246.53 | -37.19 | 121.84 | 0.6874 | -672.0 | -530.4 | |
| 0.00 | 0.97 | 0.00 | 0.65 | -14.10 | 246.62 | -37.11 | 119.88 | 0.6771 | -659.0 | -629.4 | |
| 1.15 | 2.30 | 0.78 | 1.55 | -14.50 | 246.46 | -37.26 | 120.30 | 0.6812 | -696.8 | -601.2 | |
| 0.00 | 1.24 | 0.00 | 0.83 | -13.82 | 246.51 | -37.21 | 119.44 | 0.6766 | -751.0 | -592.3 | |
| 0.00 | 1.42 | 0.00 | 0.96 | -15.17 | 246.17 | -37.56 | 120.97 | 0.6884 | -714.0 | -630.2 | |
| 0.00 | 1.50 | 0.00 | 1.03 | -15.76 | 246.00 | -37.73 | 121.61 | 0.6938 | -581.0 | -524.0 | |
| 0.00 | 0.53 | 0.00 | 0.36 | -15.08 | 246.03 | -37.70 | 120.76 | 0.6894 | -732.0 | -656.0 | |
| 0.00 | 2.30 | 0.00 | 1.58 | -15.77 | 245.84 | -37.89 | 121.52 | 0.6956 | -720.0 | -575.0 | |
| 0.00 | 1.50 | 0.00 | 1.04 | -15.60 | 245.60 | -38.13 | 121.14 | 0.6971 | -449.0 | -358.9 | |
| 0.00 | 2.92 | 0.00 | 2.00 | -15.08 | 245.59 | -38.13 | 120.48 | 0.6941 | -824.0 | -709.9 | |
| 0.00 | 1.77 | 0.00 | 1.22 | -15.21 | 245.20 | -38.52 | 120.39 | 0.6990 | -776.0 | -731.5 | |
| 0.00 | 2.30 | 0.00 | 1.60 | -15.30 | 244.90 | -38.82 | 120.32 | 0.7027 | -602.0 | -576.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
