SDO HMI 2014-09-23 14:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 93.34 | 477.51 | 50.85 | 261.47 | -10.54 | 265.34 | -17.28 | 136.40 | 0.4173 | 311.4 | 112.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-23 14:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.24 | 0.00 | 0.63 | -2.78 | 276.95 | -5.67 | 149.77 | 0.1970 | 780.0 | 733.9 | |
| 0.00 | 1.24 | 0.00 | 0.66 | -14.53 | 276.07 | -6.56 | 163.21 | 0.3843 | 741.0 | 554.0 | |
| 0.00 | 1.15 | 0.00 | 0.60 | -8.48 | 273.42 | -9.20 | 149.21 | 0.3104 | 774.0 | 445.3 | |
| 0.00 | 0.97 | 0.00 | 0.51 | -10.06 | 272.73 | -9.90 | 149.88 | 0.3387 | 697.0 | 539.5 | |
| 0.00 | 2.83 | 0.00 | 1.47 | -7.28 | 272.77 | -9.85 | 145.29 | 0.2993 | 793.0 | 745.6 | |
| 0.00 | 0.88 | 0.00 | 0.46 | -9.72 | 272.61 | -10.01 | 149.07 | 0.3348 | 851.0 | 637.6 | |
| 0.00 | 1.42 | 0.00 | 0.74 | -9.15 | 272.54 | -10.09 | 147.98 | 0.3275 | 752.0 | 559.0 | |
| 0.00 | 3.10 | 0.00 | 1.63 | -10.26 | 272.25 | -10.37 | 149.01 | 0.3455 | 685.0 | 579.2 | |
| 14.86 | 198.51 | 7.85 | 104.88 | -8.94 | 269.87 | -12.75 | 141.25 | 0.3499 | 1154.5 | 397.5 | |
| 13.09 | -9.00 | 6.91 | -9.00 | -8.62 | 269.88 | -12.74 | 140.71 | 0.3458 | 1351.4 | 999999 | |
| 1.15 | -9.00 | 0.61 | -9.00 | -9.25 | 269.67 | -12.95 | 141.39 | 0.3560 | 810.2 | 999999 | |
| 3.36 | -9.00 | 1.78 | -9.00 | -9.04 | 269.59 | -13.04 | 140.81 | 0.3541 | 911.4 | 999999 | |
| 4.07 | -9.00 | 2.15 | -9.00 | -8.85 | 269.53 | -13.09 | 140.36 | 0.3523 | 992.5 | 999999 | |
| 1.15 | -9.00 | 0.61 | -9.00 | -8.51 | 269.48 | -13.14 | 139.62 | 0.3485 | 656.7 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.56 | -6.71 | 269.23 | -13.39 | 135.47 | 0.3295 | -531.0 | -537.8 | |
| 0.00 | 0.97 | 0.00 | 0.52 | -9.12 | 268.96 | -13.67 | 139.62 | 0.3616 | 609.0 | 554.3 | |
| 0.00 | 1.42 | 0.00 | 0.74 | -6.67 | 268.42 | -14.20 | 133.69 | 0.3385 | 964.0 | 726.3 | |
| 0.00 | 0.88 | 0.00 | 0.47 | -6.86 | 268.41 | -14.21 | 134.08 | 0.3407 | 746.0 | 630.7 | |
| 0.80 | 58.92 | 0.42 | 31.35 | -8.45 | 268.23 | -14.39 | 136.90 | 0.3614 | 1102.7 | 486.7 | |
| 0.00 | 1.24 | 0.00 | 0.67 | -11.06 | 268.08 | -14.54 | 141.18 | 0.3948 | 646.0 | 482.1 | |
| 20.26 | -19.00 | 10.78 | -19.00 | -8.68 | 268.03 | -14.59 | 136.94 | 0.3662 | 1075.2 | 999999 | |
| 0.00 | 5.40 | 0.00 | 2.88 | -9.31 | 267.79 | -14.84 | 137.62 | 0.3765 | 620.0 | 572.1 | |
| 1.33 | -19.00 | 0.71 | -19.00 | -8.87 | 267.77 | -14.85 | 136.79 | 0.3714 | 738.7 | 999999 | |
| 2.39 | -19.00 | 1.27 | -19.00 | -8.40 | 267.76 | -14.86 | 135.89 | 0.3661 | 992.4 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.62 | -9.91 | 267.66 | -14.96 | 138.45 | 0.3850 | 719.0 | 528.4 | |
| 0.00 | 1.24 | 0.00 | 0.66 | -8.82 | 267.43 | -15.19 | 136.03 | 0.3747 | 528.0 | 439.2 | |
| 0.00 | 1.50 | 0.00 | 0.81 | -9.32 | 267.31 | -15.31 | 136.74 | 0.3819 | 633.0 | 474.4 | |
| 0.00 | 2.92 | 0.00 | 1.57 | -10.40 | 267.23 | -15.40 | 138.46 | 0.3955 | 550.0 | 578.8 | |
| 0.00 | 2.39 | 0.00 | 1.28 | -8.30 | 266.31 | -16.31 | 132.99 | 0.3815 | -709.0 | -443.2 | |
| 0.00 | 3.63 | 0.00 | 1.95 | -8.70 | 266.26 | -16.36 | 133.68 | 0.3866 | -707.0 | -631.0 | |
| 2.21 | 5.04 | 1.19 | 2.72 | -8.91 | 265.81 | -16.81 | 133.27 | 0.3941 | 967.5 | 703.3 | |
| 0.00 | 2.03 | 0.00 | 1.10 | -9.17 | 265.54 | -17.08 | 133.30 | 0.4001 | 706.0 | 602.3 | |
| 0.00 | 0.97 | 0.00 | 0.53 | -8.62 | 265.19 | -17.44 | 131.68 | 0.3984 | 723.0 | 572.8 | |
| 0.00 | 2.03 | 0.00 | 1.11 | -9.58 | 264.46 | -18.16 | 132.29 | 0.4172 | 541.0 | 345.1 | |
| 0.80 | 2.57 | 0.43 | 1.39 | -8.69 | 264.00 | -18.62 | 129.93 | 0.4134 | -833.8 | -627.0 | |
| 0.00 | 0.97 | 0.00 | 0.56 | -16.81 | 263.22 | -19.40 | 141.31 | 0.5108 | 757.0 | 560.0 | |
| 0.00 | 1.06 | 0.00 | 0.59 | -9.96 | 262.76 | -19.86 | 130.39 | 0.4412 | -762.0 | -599.8 | |
| 0.00 | 1.06 | 0.00 | 0.62 | -16.75 | 261.65 | -20.97 | 139.06 | 0.5251 | 676.0 | 532.0 | |
| 0.53 | 1.86 | 0.29 | 1.03 | -10.40 | 262.15 | -20.48 | 130.27 | 0.4529 | -925.8 | -797.8 | |
| 0.00 | 1.68 | 0.00 | 0.93 | -9.80 | 262.12 | -20.50 | 129.21 | 0.4473 | -819.0 | -604.0 | |
| 0.00 | 1.06 | 0.00 | 0.60 | -11.69 | 261.59 | -21.04 | 131.64 | 0.4723 | -723.0 | -577.8 | |
| 0.00 | 0.80 | 0.00 | 0.45 | -11.70 | 261.36 | -21.27 | 131.35 | 0.4751 | -743.0 | -613.6 | |
| 0.00 | 1.15 | 0.00 | 0.66 | -13.56 | 261.02 | -21.60 | 133.79 | 0.4977 | 405.0 | 416.1 | |
| 0.00 | 1.33 | 0.00 | 0.75 | -11.64 | 261.20 | -21.43 | 131.04 | 0.4763 | -713.0 | -592.3 | |
| 0.00 | 1.50 | 0.00 | 0.85 | -11.56 | 260.84 | -21.78 | 130.45 | 0.4797 | -772.0 | -650.1 | |
| 1.77 | 5.48 | 1.02 | 3.16 | -12.66 | 259.10 | -23.52 | 130.00 | 0.5103 | -892.2 | -717.4 | |
| 25.57 | 150.56 | 14.83 | 87.43 | -13.51 | 258.75 | -23.88 | 130.85 | 0.5224 | -1110.4 | -320.3 | |
| 0.00 | 1.15 | 0.00 | 0.66 | -12.45 | 258.38 | -24.24 | 128.81 | 0.5166 | -753.0 | -615.8 | |
| 0.00 | 1.15 | 0.00 | 0.67 | -12.55 | 258.20 | -24.42 | 128.77 | 0.5196 | -685.0 | -520.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
