SDO HMI 2014-09-23 18:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 89.92 | 473.22 | 48.53 | 256.12 | -10.60 | 265.41 | -15.01 | 140.78 | 0.3945 | 262.5 | 113.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-23 18:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.71 | 0.00 | 0.40 | -19.93 | 274.34 | -6.08 | 167.59 | 0.4652 | 720.0 | 516.9 | |
| 0.00 | 1.50 | 0.00 | 0.84 | -19.76 | 274.09 | -6.33 | 167.01 | 0.4635 | 756.0 | 629.6 | |
| 0.00 | 1.15 | 0.00 | 0.61 | -10.97 | 272.02 | -8.40 | 154.99 | 0.3407 | 645.0 | 598.8 | |
| 0.00 | 1.50 | 0.00 | 0.79 | -10.53 | 271.97 | -8.45 | 154.29 | 0.3345 | 688.0 | 468.0 | |
| 0.00 | 0.35 | 0.00 | 0.19 | -11.04 | 271.80 | -8.62 | 154.50 | 0.3433 | 572.0 | 548.2 | |
| 6.45 | 209.56 | 3.38 | 109.76 | -8.87 | 270.13 | -10.29 | 147.00 | 0.3254 | 1256.1 | 395.2 | |
| 13.00 | -6.00 | 6.80 | -6.00 | -8.59 | 269.95 | -10.46 | 146.07 | 0.3232 | 1543.9 | 999999 | |
| 15.65 | -6.00 | 8.21 | -6.00 | -8.91 | 269.76 | -10.66 | 146.13 | 0.3293 | 1197.1 | 999999 | |
| 1.77 | -6.00 | 0.93 | -6.00 | -9.22 | 269.75 | -10.67 | 146.63 | 0.3337 | 805.2 | 999999 | |
| 0.27 | -6.00 | 0.14 | -6.00 | -8.53 | 269.71 | -10.71 | 145.35 | 0.3247 | 1089.0 | 999999 | |
| 0.00 | 1.41 | 0.00 | 0.74 | -8.92 | 269.20 | -11.22 | 144.78 | 0.3347 | 392.0 | 392.6 | |
| 0.00 | 0.97 | 0.00 | 0.50 | -5.02 | 268.84 | -11.58 | 135.86 | 0.2884 | 775.0 | 610.5 | |
| 0.00 | 2.92 | 0.00 | 1.52 | -6.76 | 268.52 | -11.90 | 138.99 | 0.3134 | 706.0 | 714.5 | |
| 0.00 | 1.06 | 0.00 | 0.59 | -17.02 | 267.97 | -12.44 | 153.01 | 0.4559 | 699.0 | 502.7 | |
| 8.22 | 67.29 | 4.33 | 35.47 | -8.76 | 268.30 | -12.11 | 142.37 | 0.3412 | 1240.4 | 573.5 | |
| 0.00 | 1.95 | 0.00 | 1.04 | -10.81 | 267.94 | -12.47 | 145.01 | 0.3716 | 649.0 | 526.6 | |
| 15.30 | -15.00 | 8.06 | -15.00 | -8.64 | 267.93 | -12.48 | 141.32 | 0.3434 | 1038.0 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.61 | -9.77 | 267.89 | -12.53 | 143.21 | 0.3585 | 804.0 | 590.5 | |
| 0.00 | 1.33 | 0.00 | 0.70 | -9.30 | 267.85 | -12.57 | 142.31 | 0.3528 | 828.0 | 670.3 | |
| 0.00 | 1.24 | 0.00 | 0.66 | -9.59 | 267.62 | -12.80 | 142.30 | 0.3588 | 777.0 | 577.3 | |
| 0.00 | 0.53 | 0.00 | 0.28 | -7.06 | 267.67 | -12.74 | 137.65 | 0.3264 | 692.0 | 623.5 | |
| 0.00 | 1.68 | 0.00 | 0.90 | -10.51 | 267.36 | -13.06 | 143.29 | 0.3732 | 763.0 | 647.9 | |
| 0.00 | 1.06 | 0.00 | 0.56 | -6.76 | 267.34 | -13.08 | 136.28 | 0.3265 | 819.0 | 553.0 | |
| 0.00 | 1.50 | 0.00 | 0.80 | -8.66 | 266.21 | -14.20 | 137.68 | 0.3618 | -980.0 | -879.6 | |
| 0.44 | 2.39 | 0.24 | 1.27 | -8.79 | 265.83 | -14.59 | 137.17 | 0.3677 | 1023.4 | 750.2 | |
| 0.00 | 1.33 | 0.00 | 0.71 | -8.79 | 263.90 | -16.51 | 133.59 | 0.3895 | -694.0 | -545.5 | |
| 0.00 | 2.39 | 0.00 | 1.29 | -9.20 | 263.12 | -17.30 | 133.00 | 0.4030 | -728.0 | -697.3 | |
| 0.00 | 1.59 | 0.00 | 0.87 | -10.05 | 262.91 | -17.50 | 134.19 | 0.4148 | -850.0 | -645.9 | |
| 0.00 | 1.41 | 0.00 | 0.77 | -10.39 | 262.19 | -18.23 | 133.61 | 0.4268 | -919.0 | -815.0 | |
| 0.00 | 0.88 | 0.00 | 0.48 | -9.77 | 262.16 | -18.26 | 132.47 | 0.4203 | -757.0 | -609.6 | |
| 0.00 | 0.97 | 0.00 | 0.54 | -11.65 | 261.45 | -18.96 | 134.58 | 0.4486 | -667.0 | -536.9 | |
| 0.00 | 1.15 | 0.00 | 0.64 | -12.12 | 260.87 | -19.55 | 134.45 | 0.4602 | -675.0 | -600.4 | |
| 0.00 | 1.06 | 0.00 | 0.60 | -15.00 | 260.45 | -19.97 | 138.10 | 0.4960 | -715.0 | -582.3 | |
| 0.44 | 1.41 | 0.25 | 0.80 | -12.68 | 259.11 | -21.31 | 132.84 | 0.4855 | -967.2 | -728.8 | |
| 0.00 | 2.03 | 0.00 | 1.15 | -12.72 | 258.91 | -21.51 | 132.64 | 0.4882 | -906.0 | -761.4 | |
| 28.38 | 153.33 | 16.19 | 87.53 | -13.59 | 258.79 | -21.63 | 133.80 | 0.4983 | -1307.4 | -351.2 | |
| 0.00 | 1.33 | 0.00 | 0.75 | -12.36 | 258.34 | -22.08 | 131.34 | 0.4910 | -904.0 | -796.6 | |
| 0.00 | 3.09 | 0.00 | 1.76 | -12.35 | 257.98 | -22.44 | 130.85 | 0.4950 | -805.0 | -602.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
