SDO HMI 2014-09-23 19:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.48 | 31.02 | 1.60 | 20.10 | -15.20 | 246.16 | -33.70 | 123.82 | 0.6465 | -459.9 | -462.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-23 19:00:34 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.80 | 0.00 | 0.49 | -15.52 | 251.58 | -28.28 | 128.96 | 0.5894 | 853.0 | 783.4 | |
| 0.00 | 0.80 | 0.00 | 0.49 | -15.27 | 251.40 | -28.46 | 128.44 | 0.5892 | 802.0 | 586.3 | |
| 0.00 | 0.97 | 0.00 | 0.62 | -14.81 | 247.46 | -32.40 | 124.30 | 0.6294 | -531.0 | -524.1 | |
| 0.00 | 1.15 | 0.00 | 0.74 | -15.09 | 247.12 | -32.75 | 124.40 | 0.6352 | -644.0 | -508.3 | |
| 0.00 | 0.97 | 0.00 | 0.62 | -14.02 | 247.22 | -32.64 | 123.03 | 0.6264 | -777.0 | -573.4 | |
| 0.00 | 0.88 | 0.00 | 0.56 | -14.22 | 247.12 | -32.75 | 123.22 | 0.6291 | -709.0 | -585.8 | |
| 0.00 | 1.41 | 0.00 | 0.91 | -15.51 | 246.63 | -33.23 | 124.57 | 0.6436 | -738.0 | -548.4 | |
| 0.00 | 0.80 | 0.00 | 0.52 | -15.69 | 246.41 | -33.45 | 124.63 | 0.6473 | -617.0 | -567.8 | |
| 1.24 | 2.56 | 0.80 | 1.65 | -14.56 | 246.39 | -33.47 | 123.11 | 0.6396 | -794.4 | -667.4 | |
| 0.00 | 0.27 | 0.00 | 0.17 | -16.30 | 246.07 | -33.80 | 125.15 | 0.6553 | -450.0 | -465.3 | |
| 0.00 | 0.62 | 0.00 | 0.40 | -15.85 | 246.04 | -33.82 | 124.54 | 0.6524 | -562.0 | -566.6 | |
| 0.00 | 0.88 | 0.00 | 0.57 | -15.00 | 246.16 | -33.70 | 123.51 | 0.6451 | -745.0 | -685.2 | |
| 1.24 | 3.98 | 0.80 | 2.58 | -15.23 | 246.01 | -33.86 | 123.71 | 0.6485 | -884.1 | -648.8 | |
| 0.00 | 1.06 | 0.00 | 0.69 | -15.92 | 245.88 | -33.99 | 124.51 | 0.6547 | -477.0 | -473.2 | |
| 0.00 | 0.88 | 0.00 | 0.57 | -15.08 | 245.89 | -33.98 | 123.41 | 0.6488 | -772.0 | -607.9 | |
| 0.00 | 1.59 | 0.00 | 1.04 | -15.81 | 245.63 | -34.23 | 124.18 | 0.6566 | -451.0 | -357.8 | |
| 0.00 | 1.59 | 0.00 | 1.04 | -15.10 | 245.66 | -34.21 | 123.26 | 0.6514 | -828.0 | -715.0 | |
| 0.00 | 3.36 | 0.00 | 2.19 | -15.30 | 245.54 | -34.32 | 123.44 | 0.6540 | -613.0 | -623.6 | |
| 0.00 | 3.54 | 0.00 | 2.32 | -15.26 | 245.13 | -34.73 | 123.08 | 0.6583 | -637.0 | -596.8 | |
| 0.00 | 0.35 | 0.00 | 0.23 | -15.14 | 244.62 | -35.24 | 122.55 | 0.6631 | 33.0 | 9.8 | |
| 0.00 | 2.56 | 0.00 | 1.70 | -15.37 | 244.50 | -35.36 | 122.76 | 0.6660 | -268.0 | -46.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
