SDO HMI 2014-09-27 00:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 361.73 | 1759.29 | 189.31 | 920.18 | -11.07 | 239.15 | 1.63 | 184.65 | 0.3223 | -4.6 | -95.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-27 00:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.79 | 0.00 | 0.42 | -11.88 | 247.56 | 10.05 | 208.07 | 0.3645 | 746.0 | 534.9 | |
| 0.00 | 2.21 | 0.00 | 1.18 | -12.31 | 247.11 | 9.60 | 206.44 | 0.3674 | -774.0 | -641.1 | |
| 0.00 | 0.71 | 0.00 | 0.37 | -9.97 | 246.88 | 9.37 | 209.03 | 0.3317 | 318.0 | 245.0 | |
| 0.00 | 2.21 | 0.00 | 1.18 | -12.84 | 246.66 | 9.15 | 204.73 | 0.3721 | 871.0 | 652.8 | |
| 0.00 | 0.44 | 0.00 | 0.24 | -13.08 | 245.73 | 8.22 | 202.23 | 0.3696 | -714.0 | -565.4 | |
| 110.64 | 516.92 | 58.22 | 271.89 | -11.07 | 245.64 | 8.13 | 204.28 | 0.3389 | 1459.7 | 441.2 | |
| 0.00 | 1.06 | 0.00 | 0.56 | -12.79 | 245.69 | 8.18 | 202.44 | 0.3650 | -651.0 | -463.8 | |
| 0.00 | 1.68 | 0.00 | 0.90 | -13.62 | 245.62 | 8.11 | 201.42 | 0.3771 | -758.0 | -560.3 | |
| 0.00 | 0.97 | 0.00 | 0.52 | -12.92 | 245.60 | 8.09 | 202.09 | 0.3664 | -829.0 | -672.5 | |
| 2.21 | -6.00 | 1.16 | -6.00 | -10.59 | 245.10 | 7.59 | 203.43 | 0.3281 | 1423.6 | 999999 | |
| 6.71 | 39.29 | 3.49 | 20.40 | -9.02 | 244.95 | 7.43 | 205.04 | 0.3032 | 1158.8 | 564.7 | |
| 0.00 | 1.85 | 0.00 | 0.98 | -12.30 | 244.90 | 7.39 | 200.96 | 0.3528 | 283.0 | 224.3 | |
| 2.03 | -6.00 | 1.06 | -6.00 | -10.74 | 244.77 | 7.26 | 202.31 | 0.3282 | 1176.7 | 999999 | |
| 6.89 | -11.00 | 3.58 | -11.00 | -9.05 | 244.67 | 7.16 | 204.19 | 0.3017 | 1166.9 | 999999 | |
| 0.79 | -6.00 | 0.42 | -6.00 | -11.34 | 244.53 | 7.02 | 201.00 | 0.3360 | 833.8 | 999999 | |
| 2.38 | -6.00 | 1.25 | -6.00 | -11.53 | 244.35 | 6.84 | 200.31 | 0.3378 | 826.0 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.55 | -9.76 | 244.19 | 6.68 | 201.84 | 0.3095 | 653.0 | 516.2 | |
| 3.27 | -6.00 | 1.72 | -6.00 | -11.36 | 244.13 | 6.62 | 199.87 | 0.3341 | 974.2 | 999999 | |
| 0.00 | 0.97 | 0.00 | 0.52 | -13.30 | 244.03 | 6.51 | 197.75 | 0.3636 | -705.0 | -535.9 | |
| 0.00 | 1.24 | 0.00 | 0.65 | -11.65 | 243.95 | 6.44 | 199.09 | 0.3375 | 615.0 | 426.7 | |
| 0.00 | 1.32 | 0.00 | 0.69 | -9.34 | 243.45 | 5.94 | 200.08 | 0.2986 | 901.0 | 775.4 | |
| 16.78 | 84.95 | 8.79 | 44.50 | -11.26 | 243.33 | 5.82 | 197.72 | 0.3281 | 1160.0 | 522.4 | |
| 0.00 | 1.32 | 0.00 | 0.69 | -9.37 | 243.17 | 5.66 | 199.19 | 0.2975 | 1001.0 | 836.1 | |
| 0.00 | 2.21 | 0.00 | 1.15 | -9.77 | 243.15 | 5.64 | 198.67 | 0.3038 | 902.0 | 664.2 | |
| 0.00 | 1.24 | 0.00 | 0.65 | -12.62 | 243.14 | 5.63 | 196.00 | 0.3487 | 986.0 | 817.1 | |
| 9.36 | -22.00 | 4.91 | -22.00 | -11.48 | 243.06 | 5.55 | 196.74 | 0.3303 | 1049.6 | 999999 | |
| 1.15 | -22.00 | 0.60 | -22.00 | -11.79 | 243.03 | 5.52 | 196.39 | 0.3352 | 751.2 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.41 | -9.27 | 242.96 | 5.45 | 198.62 | 0.2948 | 278.0 | 303.1 | |
| 0.88 | 2.03 | 0.47 | 1.07 | -12.91 | 242.99 | 5.48 | 195.38 | 0.3526 | 931.0 | 733.9 | |
| 3.53 | -22.00 | 1.85 | -22.00 | -11.00 | 242.80 | 5.29 | 196.43 | 0.3215 | 1188.9 | 999999 | |
| 0.00 | 7.59 | 0.00 | 4.01 | -12.68 | 242.83 | 5.32 | 195.12 | 0.3483 | 812.0 | 742.9 | |
| 0.00 | 0.88 | 0.00 | 0.46 | -11.88 | 242.73 | 5.21 | 195.45 | 0.3352 | 580.0 | 513.1 | |
| 0.00 | 0.79 | 0.00 | 0.41 | -8.89 | 242.65 | 5.14 | 198.02 | 0.2872 | -568.0 | -522.4 | |
| 0.00 | 4.94 | 0.00 | 2.57 | -9.74 | 242.54 | 5.03 | 196.80 | 0.3001 | 982.0 | 742.2 | |
| 0.00 | 1.15 | 0.00 | 0.61 | -12.93 | 242.28 | 4.77 | 193.44 | 0.3501 | 714.0 | 556.7 | |
| 0.00 | 2.03 | 0.00 | 1.05 | -9.73 | 242.20 | 4.69 | 195.73 | 0.2985 | 950.0 | 635.8 | |
| 0.00 | 1.41 | 0.00 | 0.73 | -9.85 | 242.02 | 4.51 | 195.04 | 0.2997 | 861.0 | 658.9 | |
| 0.00 | 1.24 | 0.00 | 0.65 | -10.99 | 241.73 | 4.22 | 193.23 | 0.3167 | 759.0 | 544.5 | |
| 0.00 | 2.03 | 0.00 | 1.08 | -14.30 | 241.78 | 4.27 | 191.28 | 0.3703 | 689.0 | 522.9 | |
| 0.00 | 0.97 | 0.00 | 0.51 | -12.06 | 241.34 | 3.83 | 191.37 | 0.3328 | 868.0 | 675.7 | |
| 0.00 | 1.50 | 0.00 | 0.79 | -12.25 | 241.31 | 3.80 | 191.18 | 0.3358 | 759.0 | 668.2 | |
| 0.00 | 2.03 | 0.00 | 1.06 | -11.74 | 240.85 | 3.33 | 190.10 | 0.3260 | 19.0 | 22.3 | |
| 0.79 | 5.47 | 0.42 | 2.90 | -13.62 | 240.71 | 3.20 | 188.80 | 0.3562 | 920.0 | 718.0 | |
| 0.00 | 1.06 | 0.00 | 0.56 | -13.23 | 240.58 | 3.07 | 188.62 | 0.3497 | 746.0 | 650.1 | |
| 0.00 | 0.97 | 0.00 | 0.51 | -13.74 | 240.47 | 2.96 | 188.08 | 0.3577 | 483.0 | 451.2 | |
| 0.00 | 1.06 | 0.00 | 0.56 | -13.33 | 240.43 | 2.92 | 188.16 | 0.3508 | 817.0 | 652.0 | |
| 0.00 | 1.06 | 0.00 | 0.55 | -9.24 | 240.36 | 2.85 | 190.02 | 0.2837 | -713.0 | -578.4 | |
| 7.24 | 26.31 | 3.78 | 13.76 | -11.45 | 240.32 | 2.81 | 188.67 | 0.3199 | -1098.4 | -542.1 | |
| 2.65 | -48.00 | 1.39 | -48.00 | -11.73 | 240.29 | 2.78 | 188.46 | 0.3245 | -862.6 | 999999 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -11.13 | 240.19 | 2.68 | 188.44 | 0.3143 | -884.0 | -728.6 | |
| 0.00 | 0.88 | 0.00 | 0.46 | -9.37 | 240.15 | 2.64 | 189.21 | 0.2851 | -822.0 | -668.9 | |
| 0.00 | 1.77 | 0.00 | 0.92 | -10.59 | 239.95 | 2.43 | 187.91 | 0.3049 | 734.0 | 580.0 | |
| 0.00 | 1.50 | 0.00 | 0.77 | -9.33 | 239.54 | 2.03 | 187.13 | 0.2831 | -849.0 | -663.9 | |
| 0.00 | 1.59 | 0.00 | 0.83 | -11.85 | 239.09 | 1.58 | 184.81 | 0.3242 | 696.0 | 592.6 | |
| 0.53 | 1.41 | 0.28 | 0.75 | -13.54 | 238.92 | 1.41 | 183.91 | 0.3518 | 991.5 | 853.9 | |
| 0.00 | 1.77 | 0.00 | 0.94 | -14.02 | 238.89 | 1.38 | 183.74 | 0.3596 | 665.0 | 552.7 | |
| 0.00 | 1.06 | 0.00 | 0.55 | -11.44 | 238.76 | 1.24 | 183.87 | 0.3169 | 903.0 | 807.4 | |
| 0.00 | 1.94 | 0.00 | 1.03 | -13.83 | 238.73 | 1.22 | 183.35 | 0.3563 | 989.0 | 754.4 | |
| 0.00 | 1.59 | 0.00 | 0.84 | -13.99 | 238.73 | 1.22 | 183.32 | 0.3589 | 620.0 | 497.6 | |
| 0.00 | 1.15 | 0.00 | 0.61 | -14.25 | 238.70 | 1.19 | 183.20 | 0.3631 | 654.0 | 512.8 | |
| 0.00 | 2.38 | 0.00 | 1.26 | -13.48 | 238.58 | 1.07 | 182.97 | 0.3504 | 840.0 | 685.2 | |
| 2.74 | 23.49 | 1.44 | 12.34 | -12.36 | 238.45 | 0.94 | 182.78 | 0.3318 | 1107.0 | 629.2 | |
| 0.35 | 26.58 | 0.18 | 13.90 | -11.47 | 238.42 | 0.91 | 182.82 | 0.3171 | 750.5 | 198.6 | |
| 0.00 | 2.38 | 0.00 | 1.24 | -10.52 | 238.42 | 0.91 | 182.97 | 0.3013 | -723.0 | -650.3 | |
| 3.53 | -62.00 | 1.86 | -62.00 | -12.58 | 238.27 | 0.76 | 182.21 | 0.3354 | 784.2 | 999999 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -10.96 | 238.20 | 0.69 | 182.21 | 0.3085 | -876.0 | -731.7 | |
| 0.00 | 0.97 | 0.00 | 0.50 | -9.73 | 238.20 | 0.69 | 182.38 | 0.2880 | 710.0 | 650.1 | |
| 0.71 | -62.00 | 0.37 | -62.00 | -12.64 | 238.05 | 0.54 | 181.57 | 0.3363 | 681.0 | 999999 | |
| 2.91 | 8.48 | 1.51 | 4.38 | -9.77 | 238.02 | 0.51 | 181.74 | 0.2884 | 1118.6 | 818.2 | |
| 0.79 | -69.00 | 0.41 | -69.00 | -9.92 | 237.93 | 0.42 | 181.42 | 0.2910 | 996.2 | 999999 | |
| 0.88 | -63.00 | 0.46 | -63.00 | -12.01 | 237.90 | 0.39 | 181.17 | 0.3257 | -826.0 | 999999 | |
| 0.00 | 1.68 | 0.00 | 0.87 | -9.36 | 237.81 | 0.29 | 181.04 | 0.2814 | 857.0 | 797.0 | |
| 0.00 | 2.21 | 0.00 | 1.16 | -12.83 | 237.71 | 0.20 | 180.58 | 0.3393 | 665.0 | 442.4 | |
| 0.00 | 5.21 | 0.00 | 2.69 | -9.64 | 237.68 | 0.17 | 180.60 | 0.2861 | 563.0 | 878.4 | |
| 1.15 | 15.63 | 0.60 | 8.21 | -12.48 | 237.65 | 0.14 | 180.41 | 0.3335 | 733.4 | -109.2 | |
| 0.00 | 1.24 | 0.00 | 0.64 | -9.89 | 237.56 | 0.05 | 180.17 | 0.2903 | 798.0 | 693.7 | |
| 0.00 | 2.30 | 0.00 | 1.18 | -9.26 | 237.44 | -0.07 | 179.75 | 0.2798 | 960.0 | 722.9 | |
| 0.00 | 2.83 | 0.00 | 1.47 | -10.93 | 237.19 | -0.32 | 178.98 | 0.3078 | 539.0 | 456.4 | |
| 0.00 | 0.97 | 0.00 | 0.51 | -12.99 | 237.16 | -0.35 | 178.99 | 0.3420 | -223.0 | -192.4 | |
| 0.62 | -75.00 | 0.32 | -75.00 | -12.67 | 237.13 | -0.38 | 178.88 | 0.3367 | -937.1 | 999999 | |
| 0.00 | 1.41 | 0.00 | 0.74 | -11.40 | 236.98 | -0.53 | 178.34 | 0.3157 | -929.0 | -844.3 | |
| 0.00 | 1.77 | 0.00 | 0.91 | -9.20 | 236.98 | -0.53 | 178.13 | 0.2789 | -568.0 | -468.5 | |
| 0.88 | 2.12 | 0.47 | 1.14 | -15.54 | 236.90 | -0.61 | 178.46 | 0.3837 | -870.2 | -749.6 | |
| 0.00 | 1.50 | 0.00 | 0.81 | -16.03 | 236.90 | -0.61 | 178.49 | 0.3916 | 839.0 | 613.4 | |
| 5.47 | 23.75 | 2.89 | 12.54 | -13.38 | 236.85 | -0.66 | 178.14 | 0.3484 | -1177.4 | -731.4 | |
| 0.00 | 1.06 | 0.00 | 0.55 | -10.61 | 236.77 | -0.75 | 177.57 | 0.3027 | 770.0 | 663.7 | |
| 0.00 | 1.15 | 0.00 | 0.62 | -15.93 | 236.71 | -0.80 | 178.02 | 0.3901 | 876.0 | 708.6 | |
| 4.33 | 20.75 | 2.26 | 10.86 | -11.85 | 236.52 | -1.00 | 176.97 | 0.3234 | -1133.2 | -513.7 | |
| 0.00 | 3.09 | 0.00 | 1.62 | -12.29 | 236.39 | -1.12 | 176.68 | 0.3309 | -894.0 | -749.4 | |
| 2.56 | -88.00 | 1.34 | -88.00 | -12.04 | 236.33 | -1.18 | 176.45 | 0.3268 | -1138.1 | 999999 | |
| 0.00 | 2.91 | 0.00 | 1.51 | -9.83 | 236.34 | -1.17 | 176.01 | 0.2900 | 419.0 | 277.2 | |
| 0.00 | 1.32 | 0.00 | 0.71 | -15.12 | 236.25 | -1.26 | 176.76 | 0.3773 | -267.0 | -266.3 | |
| 0.00 | 1.94 | 0.00 | 1.02 | -11.75 | 236.18 | -1.33 | 175.93 | 0.3222 | -1147.0 | -896.0 | |
| 0.00 | 1.85 | 0.00 | 0.96 | -9.14 | 236.19 | -1.32 | 175.30 | 0.2786 | -824.0 | -558.2 | |
| 0.00 | 2.74 | 0.00 | 1.40 | -8.05 | 236.20 | -1.31 | 174.98 | 0.2602 | -724.0 | -657.4 | |
| 6.27 | 20.22 | 3.30 | 10.63 | -12.67 | 236.14 | -1.37 | 176.02 | 0.3375 | -962.3 | -790.8 | |
| 2.38 | 22.25 | 1.27 | 11.87 | -14.96 | 236.09 | -1.42 | 176.33 | 0.3748 | -1083.5 | -626.3 | |
| 0.00 | 1.15 | 0.00 | 0.61 | -14.31 | 236.04 | -1.47 | 176.06 | 0.3644 | -700.0 | -547.4 | |
| 2.74 | -96.00 | 1.44 | -96.00 | -12.39 | 236.02 | -1.49 | 175.60 | 0.3329 | -1184.1 | 999999 | |
| 2.65 | -97.00 | 1.41 | -97.00 | -14.83 | 235.97 | -1.54 | 175.99 | 0.3729 | -1117.5 | 999999 | |
| 0.00 | 1.77 | 0.00 | 0.95 | -15.28 | 235.91 | -1.61 | 175.91 | 0.3803 | -814.0 | -716.7 | |
| 1.50 | -96.00 | 0.79 | -96.00 | -12.68 | 235.90 | -1.62 | 175.31 | 0.3378 | -921.6 | 999999 | |
| 0.00 | 6.00 | 0.00 | 3.08 | -8.14 | 235.83 | -1.68 | 173.63 | 0.2624 | -881.0 | -671.7 | |
| 4.15 | 22.25 | 2.20 | 11.83 | -14.18 | 235.67 | -1.84 | 175.04 | 0.3628 | -1147.0 | -816.1 | |
| 2.91 | 702.44 | 1.53 | 365.07 | -11.94 | 235.41 | -2.10 | 173.66 | 0.3265 | -907.9 | -506.6 | |
| 0.00 | 1.50 | 0.00 | 0.79 | -13.19 | 235.34 | -2.18 | 173.86 | 0.3471 | -622.0 | -485.7 | |
| 0.00 | 1.15 | 0.00 | 0.59 | -8.61 | 235.37 | -2.14 | 172.15 | 0.2712 | -309.0 | -348.5 | |
| 0.00 | 0.88 | 0.00 | 0.47 | -14.70 | 235.32 | -2.19 | 174.26 | 0.3717 | -570.0 | -485.7 | |
| 1.24 | 7.95 | 0.63 | 4.08 | -8.11 | 235.35 | -2.16 | 171.79 | 0.2630 | -1111.1 | -867.5 | |
| 0.00 | 0.97 | 0.00 | 0.51 | -13.00 | 235.25 | -2.27 | 173.54 | 0.3441 | -758.0 | -625.4 | |
| 0.00 | 5.03 | 0.00 | 2.65 | -12.65 | 235.19 | -2.32 | 173.26 | 0.3385 | -690.0 | -617.4 | |
| 0.00 | 1.32 | 0.00 | 0.70 | -12.26 | 235.19 | -2.32 | 173.13 | 0.3322 | -706.0 | -522.9 | |
| 0.00 | 3.53 | 0.00 | 1.88 | -14.54 | 235.14 | -2.38 | 173.74 | 0.3694 | -690.0 | -661.8 | |
| 0.79 | -105.00 | 0.42 | -105.00 | -11.91 | 235.13 | -2.38 | 172.83 | 0.3266 | -1070.7 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.41 | -8.33 | 235.10 | -2.41 | 171.01 | 0.2672 | -450.0 | -393.0 | |
| 1.50 | -109.00 | 0.77 | -109.00 | -8.05 | 235.08 | -2.44 | 170.74 | 0.2626 | -1184.4 | 999999 | |
| 0.00 | 3.71 | 0.00 | 1.96 | -13.25 | 235.00 | -2.52 | 172.93 | 0.3488 | -840.0 | -712.3 | |
| 34.26 | -105.00 | 17.75 | -105.00 | -9.89 | 234.97 | -2.54 | 171.40 | 0.2936 | -1647.8 | 999999 | |
| 0.79 | -105.00 | 0.42 | -105.00 | -11.53 | 234.89 | -2.62 | 171.94 | 0.3208 | -1077.1 | 999999 | |
| 3.44 | 8.65 | 1.82 | 4.57 | -13.06 | 234.75 | -2.76 | 172.18 | 0.3462 | -929.4 | -726.2 | |
| 1.15 | -105.00 | 0.60 | -105.00 | -11.82 | 234.77 | -2.75 | 171.69 | 0.3258 | -1100.1 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.56 | -12.42 | 234.76 | -2.75 | 171.93 | 0.3357 | -730.0 | -606.2 | |
| 1.68 | -105.00 | 0.88 | -105.00 | -12.58 | 234.54 | -2.97 | 171.38 | 0.3389 | -948.9 | 999999 | |
| 35.76 | -105.00 | 18.55 | -105.00 | -10.05 | 234.51 | -3.00 | 169.97 | 0.2975 | -1474.1 | 999999 | |
| 4.59 | -105.00 | 2.41 | -105.00 | -12.01 | 234.49 | -3.02 | 170.95 | 0.3297 | -1096.3 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.60 | -11.66 | 234.46 | -3.05 | 170.70 | 0.3240 | -836.0 | -733.1 | |
| 2.38 | 7.95 | 1.22 | 4.08 | -7.93 | 234.41 | -3.10 | 168.17 | 0.2627 | -1196.4 | -932.0 | |
| 0.00 | 1.15 | 0.00 | 0.61 | -13.35 | 234.31 | -3.20 | 171.09 | 0.3519 | -484.0 | -294.0 | |
| 1.50 | -105.00 | 0.79 | -105.00 | -12.17 | 234.27 | -3.24 | 170.40 | 0.3329 | -915.9 | 999999 | |
| 0.97 | -105.00 | 0.51 | -105.00 | -12.05 | 234.18 | -3.33 | 170.07 | 0.3311 | -1078.8 | 999999 | |
| 15.72 | -105.00 | 8.17 | -105.00 | -10.40 | 234.17 | -3.34 | 169.08 | 0.3042 | -1210.4 | 999999 | |
| 1.41 | -105.00 | 0.74 | -105.00 | -11.76 | 234.15 | -3.36 | 169.83 | 0.3265 | -990.7 | 999999 | |
| 22.96 | -105.00 | 11.97 | -105.00 | -10.87 | 234.07 | -3.44 | 169.07 | 0.3123 | -1080.4 | 999999 | |
| 1.41 | -105.00 | 0.74 | -105.00 | -11.32 | 234.07 | -3.45 | 169.32 | 0.3195 | -863.9 | 999999 | |
| 0.71 | -105.00 | 0.37 | -105.00 | -11.54 | 234.06 | -3.45 | 169.44 | 0.3231 | -518.2 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.61 | -13.00 | 233.92 | -3.59 | 169.83 | 0.3473 | -664.0 | -496.6 | |
| 1.59 | -105.00 | 0.83 | -105.00 | -12.02 | 233.90 | -3.61 | 169.24 | 0.3314 | -891.2 | 999999 | |
| 0.00 | 2.83 | 0.00 | 1.52 | -15.36 | 232.81 | -4.70 | 168.22 | 0.3885 | -707.0 | -566.0 | |
| 0.00 | 1.41 | 0.00 | 0.75 | -13.75 | 232.66 | -4.85 | 166.89 | 0.3634 | -718.0 | -587.2 | |
| 0.53 | 3.27 | 0.28 | 1.72 | -11.99 | 232.67 | -4.84 | 165.69 | 0.3354 | -923.7 | -770.5 | |
| 0.00 | 2.03 | 0.00 | 1.07 | -11.65 | 232.62 | -4.90 | 165.26 | 0.3301 | -1061.0 | -835.4 | |
| 0.00 | 1.24 | 0.00 | 0.66 | -13.63 | 232.29 | -5.22 | 165.84 | 0.3629 | -619.0 | -501.8 | |
| 0.00 | 0.71 | 0.00 | 0.37 | -9.60 | 232.38 | -5.14 | 162.72 | 0.2984 | -884.0 | -566.9 | |
| 0.00 | 1.41 | 0.00 | 0.75 | -13.40 | 232.27 | -5.24 | 165.62 | 0.3594 | -941.0 | -748.8 | |
| 0.00 | 1.24 | 0.00 | 0.65 | -12.96 | 232.03 | -5.48 | 164.66 | 0.3534 | -849.0 | -698.1 | |
| 0.00 | 1.15 | 0.00 | 0.61 | -12.38 | 231.98 | -5.53 | 164.08 | 0.3445 | -944.0 | -756.8 | |
| 0.00 | 3.97 | 0.00 | 2.04 | -7.27 | 231.80 | -5.71 | 158.00 | 0.2647 | -920.0 | -746.3 | |
| 0.00 | 1.41 | 0.00 | 0.75 | -13.09 | 231.59 | -5.92 | 163.61 | 0.3574 | -624.0 | -498.1 | |
| 0.00 | 2.65 | 0.00 | 1.40 | -12.83 | 231.48 | -6.03 | 163.09 | 0.3540 | -773.0 | -627.2 | |
| 0.00 | 1.68 | 0.00 | 0.87 | -8.39 | 231.42 | -6.09 | 158.25 | 0.2847 | -1093.0 | -966.6 | |
| 0.00 | 0.79 | 0.00 | 0.44 | -18.91 | 231.03 | -6.48 | 166.20 | 0.4496 | -579.0 | -457.9 | |
| 0.00 | 0.88 | 0.00 | 0.46 | -9.18 | 230.45 | -7.06 | 156.30 | 0.3031 | -827.0 | -618.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
