SDO HMI 2014-09-27 01:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.50 | 22.78 | 1.34 | 20.32 | -14.96 | 184.63 | -52.33 | 113.16 | 0.8338 | -134.8 | -179.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-27 01:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.53 | 3.00 | 0.45 | 2.53 | -13.98 | 186.71 | -50.25 | 112.85 | 0.8118 | 667.5 | 515.9 | |
| 0.00 | 0.62 | 0.00 | 0.52 | -13.26 | 186.58 | -50.38 | 111.96 | 0.8106 | 568.0 | 513.7 | |
| 0.00 | 2.38 | 0.00 | 2.03 | -13.09 | 185.99 | -50.97 | 111.54 | 0.8156 | 480.0 | 362.6 | |
| 0.00 | 1.68 | 0.00 | 1.52 | -15.84 | 184.32 | -52.64 | 114.05 | 0.8395 | -542.0 | -453.4 | |
| 0.00 | 0.26 | 0.00 | 0.23 | -14.07 | 184.74 | -52.22 | 112.20 | 0.8302 | -570.0 | -579.7 | |
| 0.00 | 1.77 | 0.00 | 1.60 | -15.24 | 184.18 | -52.78 | 113.32 | 0.8388 | -617.0 | -535.8 | |
| 0.97 | 9.01 | 0.89 | 8.21 | -15.56 | 183.96 | -53.00 | 113.59 | 0.8417 | -552.5 | -261.7 | |
| 0.00 | 2.38 | 0.00 | 2.16 | -15.20 | 183.99 | -52.97 | 113.20 | 0.8403 | -597.0 | -564.5 | |
| 0.00 | 1.68 | 0.00 | 1.52 | -15.04 | 183.94 | -53.02 | 113.01 | 0.8402 | -457.0 | -436.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
