SDO HMI 2014-09-27 01:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 316.54 | 1191.67 | 174.41 | 658.67 | 14.88 | 262.25 | 25.29 | 290.29 | 0.4419 | 19.8 | -73.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-27 01:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.65 | 411.10 | 1.51 | 232.99 | 12.98 | 266.43 | 29.47 | 284.17 | 0.4964 | -933.6 | -358.5 | |
| 55.37 | -1.00 | 31.48 | -1.00 | 13.58 | 266.08 | 29.12 | 285.48 | 0.4928 | -1082.1 | 999999 | |
| 4.50 | -1.00 | 2.54 | -1.00 | 13.34 | 265.03 | 28.07 | 285.36 | 0.4767 | -962.7 | 999999 | |
| 0.00 | 1.68 | 0.00 | 0.95 | 14.67 | 265.17 | 28.21 | 288.03 | 0.4829 | -721.0 | -562.3 | |
| 17.22 | -1.00 | 9.68 | -1.00 | 13.62 | 264.82 | 27.86 | 286.03 | 0.4744 | -1156.6 | 999999 | |
| 2.47 | -1.00 | 1.39 | -1.00 | 13.49 | 264.49 | 27.53 | 285.88 | 0.4692 | -1167.5 | 999999 | |
| 5.30 | -1.00 | 2.97 | -1.00 | 13.83 | 264.32 | 27.36 | 286.67 | 0.4678 | -947.3 | 999999 | |
| 0.62 | -1.00 | 0.35 | -1.00 | 14.00 | 264.00 | 27.03 | 287.17 | 0.4635 | -833.4 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.64 | 13.81 | 263.66 | 26.70 | 286.90 | 0.4579 | -869.0 | -611.4 | |
| 2.38 | 5.48 | 1.33 | 3.05 | 14.72 | 263.64 | 26.68 | 288.86 | 0.4607 | 867.9 | 629.1 | |
| 0.00 | 1.06 | 0.00 | 0.59 | 12.13 | 263.29 | 26.33 | 283.39 | 0.4476 | -756.0 | -569.7 | |
| 0.62 | 3.00 | 0.34 | 1.67 | 13.16 | 263.37 | 26.41 | 285.61 | 0.4516 | -990.4 | -768.4 | |
| 0.00 | 0.53 | 0.00 | 0.29 | 13.85 | 262.94 | 25.98 | 287.32 | 0.4473 | -587.0 | -440.0 | |
| 22.78 | 315.45 | 12.64 | 174.19 | 15.40 | 262.86 | 25.90 | 290.73 | 0.4521 | -1088.6 | -383.0 | |
| 0.00 | 3.18 | 0.00 | 1.75 | 12.51 | 262.41 | 25.45 | 284.57 | 0.4352 | 861.0 | 635.2 | |
| 0.00 | 1.41 | 0.00 | 0.78 | 12.97 | 262.35 | 25.39 | 285.62 | 0.4357 | 590.0 | 462.6 | |
| 9.18 | -14.00 | 5.09 | -14.00 | 15.72 | 262.59 | 25.63 | 291.57 | 0.4496 | -1075.9 | 999999 | |
| 4.15 | -14.00 | 2.29 | -14.00 | 15.30 | 262.40 | 25.44 | 290.79 | 0.4450 | -1326.1 | 999999 | |
| 8.12 | -14.00 | 4.48 | -14.00 | 14.64 | 262.31 | 25.35 | 289.38 | 0.4410 | 775.4 | 999999 | |
| 5.48 | -14.00 | 3.02 | -14.00 | 14.88 | 262.34 | 25.38 | 289.89 | 0.4424 | -526.8 | 999999 | |
| 3.36 | -14.00 | 1.85 | -14.00 | 14.77 | 262.09 | 25.13 | 289.80 | 0.4382 | 982.2 | 999999 | |
| 2.30 | -14.00 | 1.27 | -14.00 | 15.41 | 262.17 | 25.21 | 291.15 | 0.4421 | -1240.3 | 999999 | |
| 3.27 | -14.00 | 1.80 | -14.00 | 15.80 | 262.19 | 25.23 | 292.00 | 0.4441 | -942.1 | 999999 | |
| 5.65 | -14.00 | 3.11 | -14.00 | 14.99 | 262.05 | 25.08 | 290.30 | 0.4385 | 476.2 | 999999 | |
| 3.97 | -14.00 | 2.19 | -14.00 | 14.62 | 262.00 | 25.04 | 289.52 | 0.4363 | 1112.2 | 999999 | |
| 1.32 | -14.00 | 0.73 | -14.00 | 15.56 | 262.09 | 25.13 | 291.54 | 0.4416 | -1210.5 | 999999 | |
| 1.50 | -14.00 | 0.83 | -14.00 | 15.41 | 262.03 | 25.07 | 291.25 | 0.4401 | -1214.9 | 999999 | |
| 7.33 | -14.00 | 4.03 | -14.00 | 14.82 | 261.82 | 24.86 | 290.05 | 0.4344 | 903.0 | 999999 | |
| 3.89 | -14.00 | 2.14 | -14.00 | 15.33 | 261.82 | 24.85 | 291.20 | 0.4366 | -1251.0 | 999999 | |
| 2.38 | -14.00 | 1.31 | -14.00 | 16.06 | 261.91 | 24.95 | 292.73 | 0.4414 | -836.7 | 999999 | |
| 6.18 | -14.00 | 3.41 | -14.00 | 15.76 | 261.84 | 24.88 | 292.13 | 0.4389 | -1160.7 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.43 | 13.22 | 261.46 | 24.50 | 286.62 | 0.4231 | 580.0 | 398.1 | |
| 1.94 | -14.00 | 1.07 | -14.00 | 15.16 | 261.62 | 24.66 | 290.94 | 0.4330 | -1030.5 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.63 | 14.76 | 261.20 | 24.23 | 290.29 | 0.4250 | -912.0 | -777.7 | |
| 2.30 | 6.98 | 1.26 | 3.83 | 16.86 | 261.16 | 24.20 | 295.01 | 0.4347 | -976.3 | -712.6 | |
| 1.41 | -35.00 | 0.78 | -35.00 | 17.02 | 261.11 | 24.15 | 295.38 | 0.4348 | -879.2 | 999999 | |
| 0.00 | 0.97 | 0.00 | 0.53 | 12.67 | 260.42 | 23.46 | 285.82 | 0.4055 | 735.0 | 603.2 | |
| 1.85 | -14.00 | 1.02 | -14.00 | 16.45 | 260.79 | 23.83 | 294.38 | 0.4273 | 461.4 | 999999 | |
| 0.00 | 2.30 | 0.00 | 1.26 | 17.58 | 260.95 | 23.99 | 296.71 | 0.4357 | -737.0 | -540.7 | |
| 0.00 | 16.16 | 0.00 | 8.80 | 14.97 | 260.57 | 23.61 | 291.18 | 0.4168 | -357.0 | -178.6 | |
| 2.56 | 68.00 | 1.39 | 36.65 | 13.90 | 260.08 | 23.12 | 288.97 | 0.4048 | 889.8 | 591.8 | |
| 0.00 | 19.34 | 0.00 | 10.50 | 15.39 | 260.01 | 23.05 | 292.55 | 0.4105 | 825.0 | 413.4 | |
| 0.00 | 0.79 | 0.00 | 0.43 | 14.73 | 259.90 | 22.94 | 291.07 | 0.4057 | 539.0 | 400.2 | |
| 5.56 | -41.00 | 3.01 | -41.00 | 14.22 | 259.71 | 22.75 | 289.98 | 0.4006 | 1002.2 | 999999 | |
| 0.44 | 259.20 | 0.24 | 139.96 | 15.77 | 259.79 | 22.83 | 293.59 | 0.4091 | 563.4 | 497.7 | |
| 0.00 | 0.35 | 0.00 | 0.19 | 16.47 | 259.84 | 22.88 | 295.16 | 0.4137 | 462.0 | 350.0 | |
| 1.06 | 2.03 | 0.57 | 1.10 | 14.47 | 259.57 | 22.61 | 290.68 | 0.3996 | 857.0 | 737.3 | |
| 0.00 | 0.97 | 0.00 | 0.55 | 23.93 | 260.90 | 23.94 | 309.16 | 0.4804 | -766.0 | -578.0 | |
| 5.03 | -41.00 | 2.71 | -41.00 | 13.81 | 259.33 | 22.37 | 289.24 | 0.3931 | 931.2 | 999999 | |
| 0.79 | -45.00 | 0.43 | -45.00 | 15.41 | 259.51 | 22.55 | 292.98 | 0.4032 | 836.0 | 999999 | |
| 0.00 | 4.86 | 0.00 | 2.64 | 17.02 | 259.71 | 22.75 | 296.53 | 0.4150 | -232.0 | -238.5 | |
| 0.00 | 1.06 | 0.00 | 0.57 | 15.06 | 259.37 | 22.41 | 292.24 | 0.3993 | 893.0 | 830.2 | |
| 0.00 | 1.59 | 0.00 | 0.87 | 17.89 | 259.65 | 22.69 | 298.49 | 0.4195 | -922.0 | -785.1 | |
| 0.00 | 2.03 | 0.00 | 1.09 | 14.57 | 259.25 | 22.28 | 291.16 | 0.3952 | 1001.0 | 834.1 | |
| 6.80 | -41.00 | 3.66 | -41.00 | 14.15 | 259.17 | 22.21 | 290.19 | 0.3921 | 1057.9 | 999999 | |
| 1.59 | -45.00 | 0.86 | -45.00 | 15.88 | 259.36 | 22.40 | 294.19 | 0.4035 | 648.9 | 999999 | |
| 3.44 | -45.00 | 1.87 | -45.00 | 16.64 | 259.42 | 22.46 | 295.90 | 0.4086 | 568.6 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.43 | 13.19 | 259.04 | 22.08 | 287.87 | 0.3861 | 830.0 | 711.9 | |
| 0.00 | 1.50 | 0.00 | 0.81 | 14.97 | 259.15 | 22.19 | 292.20 | 0.3958 | 906.0 | 825.4 | |
| 8.04 | -45.00 | 4.34 | -45.00 | 15.64 | 259.20 | 22.24 | 293.76 | 0.3999 | 1077.1 | 999999 | |
| 0.00 | 1.41 | 0.00 | 0.76 | 14.83 | 259.07 | 22.11 | 291.90 | 0.3938 | 945.0 | 763.4 | |
| 2.12 | -45.00 | 1.15 | -45.00 | 15.89 | 259.16 | 22.20 | 294.38 | 0.4006 | 917.2 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.38 | 17.96 | 259.35 | 22.39 | 298.93 | 0.4158 | -209.0 | -173.4 | |
| 2.47 | -41.00 | 1.33 | -41.00 | 14.11 | 258.86 | 21.90 | 290.28 | 0.3873 | 1122.5 | 999999 | |
| 4.86 | -45.00 | 2.62 | -45.00 | 15.77 | 259.01 | 22.05 | 294.22 | 0.3978 | 1189.1 | 999999 | |
| 2.38 | -45.00 | 1.29 | -45.00 | 16.41 | 259.09 | 22.12 | 295.66 | 0.4025 | 774.1 | 999999 | |
| 0.00 | 0.53 | 0.00 | 0.30 | 23.27 | 260.13 | 23.17 | 308.79 | 0.4657 | 636.0 | 524.3 | |
| 2.47 | -45.00 | 1.34 | -45.00 | 16.57 | 258.94 | 21.97 | 296.16 | 0.4013 | 845.9 | 999999 | |
| 8.39 | -45.00 | 4.53 | -45.00 | 16.12 | 258.85 | 21.89 | 295.17 | 0.3974 | 1071.4 | 999999 | |
| 0.00 | 2.12 | 0.00 | 1.14 | 14.15 | 258.60 | 21.64 | 290.58 | 0.3836 | 955.0 | 843.5 | |
| 8.65 | 31.88 | 4.63 | 17.06 | 13.76 | 258.46 | 21.50 | 289.69 | 0.3797 | 1159.9 | 592.6 | |
| 2.83 | -45.00 | 1.52 | -45.00 | 15.85 | 258.68 | 21.72 | 294.68 | 0.3935 | 1220.1 | 999999 | |
| 0.00 | 0.97 | 0.00 | 0.53 | 18.96 | 259.08 | 22.12 | 301.37 | 0.4188 | 710.0 | 534.2 | |
| 0.00 | 2.74 | 0.00 | 1.49 | 18.29 | 258.92 | 21.96 | 300.07 | 0.4120 | 696.0 | 576.0 | |
| 0.79 | -45.00 | 0.43 | -45.00 | 17.19 | 258.74 | 21.78 | 297.77 | 0.4023 | 652.7 | 999999 | |
| 5.30 | -45.00 | 2.86 | -45.00 | 16.95 | 258.68 | 21.72 | 297.27 | 0.3999 | 798.6 | 999999 | |
| 18.81 | -45.00 | 10.14 | -45.00 | 16.68 | 258.51 | 21.55 | 296.80 | 0.3959 | 1100.3 | 999999 | |
| 2.03 | -45.00 | 1.09 | -45.00 | 16.41 | 258.44 | 21.48 | 296.22 | 0.3933 | 1188.9 | 999999 | |
| 0.00 | 1.59 | 0.00 | 0.86 | 19.13 | 258.69 | 21.73 | 302.14 | 0.4149 | 838.0 | 589.7 | |
| 0.00 | 0.79 | 0.00 | 0.43 | 16.26 | 258.23 | 21.26 | 296.08 | 0.3893 | 796.0 | 684.6 | |
| 0.00 | 0.97 | 0.00 | 0.52 | 15.75 | 258.13 | 21.17 | 294.92 | 0.3850 | 761.0 | 661.6 | |
| 10.60 | -45.00 | 5.71 | -45.00 | 17.06 | 258.25 | 21.29 | 297.93 | 0.3946 | 1056.1 | 999999 | |
| 2.83 | -45.00 | 1.52 | -45.00 | 17.58 | 258.25 | 21.29 | 299.14 | 0.3980 | 921.4 | 999999 | |
| 0.00 | 1.32 | 0.00 | 0.72 | 18.13 | 258.32 | 21.36 | 300.32 | 0.4027 | 846.0 | 669.5 | |
| 0.00 | 0.79 | 0.00 | 0.43 | 17.95 | 258.23 | 21.27 | 300.01 | 0.4002 | 675.0 | 561.7 | |
| 6.62 | -45.00 | 3.56 | -45.00 | 16.67 | 258.04 | 21.08 | 297.23 | 0.3891 | 1157.2 | 999999 | |
| 4.50 | -45.00 | 2.43 | -45.00 | 17.53 | 258.07 | 21.11 | 299.20 | 0.3951 | 956.8 | 999999 | |
| 0.00 | 1.77 | 0.00 | 0.94 | 14.22 | 257.67 | 20.71 | 291.46 | 0.3700 | 532.0 | 469.8 | |
| 6.09 | -45.00 | 3.27 | -45.00 | 17.14 | 257.82 | 20.86 | 298.55 | 0.3891 | 1058.7 | 999999 | |
| 0.00 | 2.38 | 0.00 | 1.29 | 18.95 | 257.75 | 20.79 | 302.77 | 0.4009 | 611.0 | 564.3 | |
| 0.00 | 2.65 | 0.00 | 1.42 | 16.76 | 257.34 | 20.38 | 298.13 | 0.3798 | 770.0 | 819.4 | |
| 0.00 | 1.68 | 0.00 | 0.90 | 17.07 | 257.34 | 20.38 | 298.87 | 0.3818 | 815.0 | 700.2 | |
| 0.00 | 1.41 | 0.00 | 0.76 | 17.44 | 257.32 | 20.36 | 299.77 | 0.3840 | 792.0 | 658.7 | |
| 0.00 | 1.06 | 0.00 | 0.57 | 19.83 | 255.15 | 18.19 | 307.97 | 0.3742 | 884.0 | 728.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
