SDO HMI 2014-09-27 02:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 12.88 | 0.00 | 7.33 | 7.35 | 206.71 | -29.70 | 87.32 | 0.4940 | 458.2 | 382.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-27 02:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.97 | 0.00 | 0.54 | 6.77 | 210.29 | -26.12 | 88.70 | 0.4392 | -573.0 | -521.0 | |
| 0.00 | 1.59 | 0.00 | 0.88 | 6.14 | 209.17 | -27.24 | 90.01 | 0.4570 | -866.0 | -716.2 | |
| 0.00 | 0.79 | 0.00 | 0.45 | 7.45 | 206.71 | -29.70 | 87.07 | 0.4939 | 817.0 | 775.0 | |
| 0.00 | 0.79 | 0.00 | 0.45 | 6.34 | 206.75 | -29.66 | 89.33 | 0.4939 | 740.0 | 599.9 | |
| 0.00 | 1.06 | 0.00 | 0.60 | 6.49 | 206.71 | -29.71 | 89.02 | 0.4944 | 807.0 | 690.2 | |
| 0.00 | 0.79 | 0.00 | 0.45 | 8.03 | 206.28 | -30.13 | 85.89 | 0.5004 | 808.0 | 694.6 | |
| 0.00 | 1.41 | 0.00 | 0.81 | 7.87 | 206.12 | -30.29 | 86.22 | 0.5028 | 857.0 | 691.6 | |
| 0.00 | 2.56 | 0.00 | 1.47 | 7.35 | 206.02 | -30.40 | 87.25 | 0.5044 | 659.0 | 546.0 | |
| 0.00 | 1.15 | 0.00 | 0.66 | 9.10 | 205.62 | -30.79 | 83.78 | 0.5105 | 638.0 | 584.1 | |
| 0.00 | 1.77 | 0.00 | 1.02 | 7.77 | 205.03 | -31.38 | 86.39 | 0.5191 | 695.0 | 604.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
