SDO HMI 2014-09-27 16:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 235.05 | 1127.24 | 140.25 | 673.07 | 14.86 | 262.15 | 33.42 | 286.74 | 0.5576 | -39.8 | -28.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-27 16:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.35 | 363.10 | 3.99 | 225.67 | 13.32 | 266.76 | 38.03 | 282.87 | 0.6172 | -760.5 | -361.2 | |
| 1.94 | -1.00 | 1.22 | -1.00 | 13.05 | 266.63 | 37.90 | 282.46 | 0.6152 | -839.3 | 999999 | |
| 39.97 | -1.00 | 24.92 | -1.00 | 13.67 | 266.12 | 37.39 | 283.55 | 0.6092 | -1111.1 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.67 | 16.68 | 266.72 | 37.99 | 288.28 | 0.6232 | -561.0 | -434.5 | |
| 10.15 | -1.00 | 6.26 | -1.00 | 13.66 | 265.35 | 36.61 | 283.69 | 0.5987 | -1091.1 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.71 | 14.43 | 265.18 | 36.45 | 285.02 | 0.5979 | -643.0 | -536.7 | |
| 3.35 | -1.00 | 2.06 | -1.00 | 13.93 | 265.01 | 36.28 | 284.21 | 0.5947 | -942.5 | 999999 | |
| 0.00 | 1.32 | 0.00 | 0.83 | 17.19 | 265.61 | 36.88 | 289.42 | 0.6102 | -490.0 | -383.9 | |
| 1.41 | -1.00 | 0.87 | -1.00 | 13.73 | 264.82 | 36.09 | 283.91 | 0.5917 | -1098.4 | 999999 | |
| 0.79 | -1.00 | 0.49 | -1.00 | 13.91 | 264.85 | 36.12 | 284.21 | 0.5925 | -1025.4 | 999999 | |
| 0.26 | -1.00 | 0.16 | -1.00 | 13.84 | 264.57 | 35.84 | 284.15 | 0.5885 | -1002.7 | 999999 | |
| 7.76 | -1.00 | 4.74 | -1.00 | 13.91 | 264.39 | 35.66 | 284.31 | 0.5862 | -1123.1 | 999999 | |
| 0.00 | 3.35 | 0.00 | 2.05 | 14.67 | 264.46 | 35.73 | 285.58 | 0.5886 | -286.0 | -366.8 | |
| 0.00 | 1.15 | 0.00 | 0.70 | 14.34 | 264.39 | 35.66 | 285.03 | 0.5871 | -334.0 | -310.3 | |
| 4.68 | 292.51 | 2.83 | 175.03 | 14.85 | 263.58 | 34.84 | 286.12 | 0.5771 | 523.3 | -345.2 | |
| 0.71 | -15.00 | 0.43 | -15.00 | 15.07 | 263.43 | 34.70 | 286.54 | 0.5756 | -560.5 | 999999 | |
| 0.26 | -15.00 | 0.16 | -15.00 | 14.86 | 263.05 | 34.32 | 286.27 | 0.5698 | -945.0 | 999999 | |
| 15.35 | -15.00 | 9.24 | -15.00 | 15.47 | 262.94 | 34.20 | 287.38 | 0.5699 | -927.0 | 999999 | |
| 2.03 | -15.00 | 1.22 | -15.00 | 15.11 | 262.83 | 34.10 | 286.79 | 0.5675 | -1219.9 | 999999 | |
| 2.03 | -15.00 | 1.22 | -15.00 | 14.98 | 262.62 | 33.89 | 286.61 | 0.5642 | -1508.6 | 999999 | |
| 1.59 | -15.00 | 0.95 | -15.00 | 14.22 | 262.48 | 33.75 | 285.32 | 0.5606 | 351.8 | 999999 | |
| 22.68 | -15.00 | 13.56 | -15.00 | 15.32 | 262.46 | 33.72 | 287.27 | 0.5629 | -1449.6 | 999999 | |
| 18.71 | -15.00 | 11.12 | -15.00 | 14.87 | 261.96 | 33.23 | 286.61 | 0.5549 | 817.2 | 999999 | |
| 2.74 | -15.00 | 1.62 | -15.00 | 14.56 | 261.91 | 33.18 | 286.09 | 0.5534 | 1019.5 | 999999 | |
| 0.00 | 2.12 | 0.00 | 1.25 | 13.47 | 261.43 | 32.70 | 284.25 | 0.5442 | 604.0 | 465.0 | |
| 0.00 | 1.50 | 0.00 | 0.88 | 13.49 | 261.11 | 32.38 | 284.37 | 0.5396 | 616.0 | 441.7 | |
| 0.97 | 3.35 | 0.58 | 1.99 | 16.66 | 261.62 | 32.89 | 289.91 | 0.5555 | -881.5 | -723.0 | |
| 0.00 | 1.76 | 0.00 | 1.04 | 15.75 | 261.04 | 32.31 | 288.51 | 0.5446 | 433.0 | 271.4 | |
| 0.00 | 0.79 | 0.00 | 0.46 | 12.87 | 260.40 | 31.66 | 283.39 | 0.5281 | 726.0 | 594.2 | |
| 0.00 | 2.56 | 0.00 | 1.50 | 14.92 | 260.68 | 31.95 | 287.12 | 0.5371 | 537.0 | 417.2 | |
| 0.62 | 2.65 | 0.36 | 1.56 | 16.36 | 260.64 | 31.91 | 289.76 | 0.5410 | -994.3 | -875.0 | |
| 0.00 | 0.88 | 0.00 | 0.51 | 14.48 | 260.28 | 31.55 | 286.46 | 0.5303 | -720.0 | -572.1 | |
| 0.00 | 3.53 | 0.00 | 2.04 | 13.92 | 259.54 | 30.80 | 285.64 | 0.5183 | 593.0 | 483.2 | |
| 3.09 | 159.62 | 1.79 | 91.98 | 14.41 | 259.43 | 30.70 | 286.62 | 0.5181 | 814.5 | 450.2 | |
| 2.21 | -34.00 | 1.28 | -34.00 | 15.38 | 259.59 | 30.85 | 288.39 | 0.5232 | 706.0 | 999999 | |
| 0.00 | 0.71 | 0.00 | 0.42 | 19.18 | 260.27 | 31.54 | 294.96 | 0.5471 | 269.0 | 197.4 | |
| 2.91 | -34.00 | 1.68 | -34.00 | 14.75 | 259.41 | 30.68 | 287.26 | 0.5188 | 856.9 | 999999 | |
| 0.00 | 13.41 | 0.00 | 7.81 | 16.23 | 259.66 | 30.93 | 289.94 | 0.5270 | -151.0 | -22.1 | |
| 0.88 | -34.00 | 0.51 | -34.00 | 14.25 | 259.19 | 30.46 | 286.38 | 0.5141 | 781.5 | 999999 | |
| 6.71 | -34.00 | 3.86 | -34.00 | 13.95 | 259.11 | 30.38 | 285.83 | 0.5122 | 999.6 | 999999 | |
| 1.41 | -34.00 | 0.82 | -34.00 | 15.00 | 259.27 | 30.54 | 287.80 | 0.5175 | 966.5 | 999999 | |
| 0.71 | 1.59 | 0.41 | 0.92 | 14.59 | 259.10 | 30.37 | 287.07 | 0.5138 | 1002.1 | 917.8 | |
| 0.00 | 1.06 | 0.00 | 0.62 | 16.61 | 259.43 | 30.70 | 290.75 | 0.5253 | 516.0 | 348.8 | |
| 0.00 | 4.32 | 0.00 | 2.51 | 15.95 | 259.32 | 30.59 | 289.56 | 0.5213 | 475.0 | 427.5 | |
| 0.00 | 1.06 | 0.00 | 0.62 | 18.07 | 259.67 | 30.94 | 293.30 | 0.5343 | -797.0 | -573.3 | |
| 0.00 | 0.35 | 0.00 | 0.20 | 16.38 | 259.21 | 30.48 | 290.42 | 0.5213 | 247.0 | 172.2 | |
| 10.32 | 236.39 | 5.96 | 136.20 | 15.75 | 258.99 | 30.26 | 289.33 | 0.5161 | 849.7 | 504.7 | |
| 0.00 | 1.85 | 0.00 | 1.07 | 15.06 | 258.88 | 30.15 | 288.05 | 0.5122 | 972.0 | 829.6 | |
| 1.06 | -34.00 | 0.61 | -34.00 | 14.10 | 258.66 | 29.93 | 286.28 | 0.5062 | 1027.8 | 999999 | |
| 0.00 | 6.79 | 0.00 | 3.91 | 15.28 | 258.77 | 30.04 | 288.52 | 0.5113 | 996.0 | 839.4 | |
| 0.00 | 1.24 | 0.00 | 0.72 | 19.41 | 259.47 | 30.74 | 295.81 | 0.5375 | 715.0 | 479.3 | |
| 3.97 | -47.00 | 2.29 | -47.00 | 15.68 | 258.73 | 30.00 | 289.30 | 0.5121 | 1143.8 | 999999 | |
| 2.21 | -47.00 | 1.28 | -47.00 | 16.86 | 258.90 | 30.16 | 291.46 | 0.5188 | 621.8 | 999999 | |
| 5.12 | -34.00 | 2.93 | -34.00 | 13.99 | 258.36 | 29.63 | 286.18 | 0.5016 | 1181.0 | 999999 | |
| 4.50 | -47.00 | 2.59 | -47.00 | 15.81 | 258.61 | 29.87 | 289.60 | 0.5108 | 1208.7 | 999999 | |
| 4.32 | -47.00 | 2.49 | -47.00 | 16.26 | 258.68 | 29.95 | 290.43 | 0.5135 | 869.6 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.66 | 14.30 | 258.37 | 29.64 | 286.77 | 0.5025 | 1025.0 | 887.8 | |
| 6.44 | -47.00 | 3.71 | -47.00 | 16.08 | 258.54 | 29.81 | 290.16 | 0.5109 | 1139.1 | 999999 | |
| 0.00 | 1.59 | 0.00 | 0.91 | 15.15 | 258.32 | 29.59 | 288.46 | 0.5045 | 840.0 | 746.4 | |
| 2.38 | -47.00 | 1.37 | -47.00 | 17.01 | 258.41 | 29.68 | 291.98 | 0.5127 | 832.8 | 999999 | |
| 1.32 | -47.00 | 0.77 | -47.00 | 17.93 | 258.51 | 29.78 | 293.64 | 0.5179 | 663.9 | 999999 | |
| 1.41 | -47.00 | 0.82 | -47.00 | 17.78 | 258.44 | 29.71 | 293.40 | 0.5163 | 770.8 | 999999 | |
| 9.71 | -47.00 | 5.58 | -47.00 | 16.59 | 258.20 | 29.47 | 291.30 | 0.5080 | 1136.7 | 999999 | |
| 0.00 | 2.38 | 0.00 | 1.38 | 18.82 | 258.57 | 29.84 | 295.25 | 0.5228 | 775.0 | 627.0 | |
| 1.59 | -47.00 | 0.91 | -47.00 | 17.27 | 258.21 | 29.48 | 292.57 | 0.5109 | 915.7 | 999999 | |
| 5.38 | -47.00 | 3.09 | -47.00 | 16.88 | 258.10 | 29.37 | 291.88 | 0.5078 | 1132.0 | 999999 | |
| 5.91 | -47.00 | 3.41 | -47.00 | 17.61 | 258.23 | 29.50 | 293.19 | 0.5127 | 910.6 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.60 | 11.72 | 257.36 | 28.63 | 281.90 | 0.4814 | 723.0 | 615.4 | |
| 1.06 | -47.00 | 0.61 | -47.00 | 17.15 | 258.11 | 29.38 | 292.40 | 0.5091 | 916.6 | 999999 | |
| 2.38 | -47.00 | 1.36 | -47.00 | 16.44 | 257.78 | 29.04 | 291.20 | 0.5015 | 1203.0 | 999999 | |
| 3.35 | -47.00 | 1.92 | -47.00 | 16.83 | 257.77 | 29.04 | 291.97 | 0.5030 | 1168.5 | 999999 | |
| 0.00 | 1.24 | 0.00 | 0.71 | 17.43 | 257.55 | 28.82 | 293.23 | 0.5025 | 901.0 | 776.6 | |
| 0.00 | 1.15 | 0.00 | 0.66 | 18.14 | 257.46 | 28.73 | 294.64 | 0.5045 | 874.0 | 726.4 | |
| 0.35 | 3.88 | 0.20 | 2.21 | 16.68 | 257.17 | 28.44 | 292.00 | 0.4940 | 988.0 | 772.4 | |
| 0.00 | 1.06 | 0.00 | 0.61 | 18.36 | 257.46 | 28.73 | 295.04 | 0.5056 | 767.0 | 580.5 | |
| 0.00 | 0.97 | 0.00 | 0.55 | 16.99 | 257.19 | 28.46 | 292.59 | 0.4955 | 674.0 | 630.1 | |
| 0.00 | 1.59 | 0.00 | 0.91 | 17.97 | 257.21 | 28.48 | 294.46 | 0.5004 | 850.0 | 792.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
