SDO HMI 2014-09-28 03:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.80 | 77.25 | 24.88 | 122.78 | -0.98 | 151.21 | -71.45 | 93.31 | 0.9508 | 397.7 | 193.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-28 03:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.94 | 72.39 | 7.62 | 113.74 | -0.91 | 151.68 | -70.98 | 93.31 | 0.9483 | 702.3 | 196.9 | |
| 5.74 | -1.00 | 9.01 | -1.00 | -0.67 | 151.41 | -71.25 | 93.02 | 0.9496 | 485.3 | 999999 | |
| 3.18 | -1.00 | 5.06 | -1.00 | -1.06 | 151.20 | -71.46 | 93.40 | 0.9510 | 102.8 | 999999 | |
| 1.50 | -1.00 | 2.39 | -1.00 | -0.89 | 151.12 | -71.55 | 93.21 | 0.9513 | -32.5 | 999999 | |
| 0.00 | 1.77 | 0.00 | 3.13 | -2.10 | 149.28 | -73.38 | 94.21 | 0.9614 | 301.0 | 230.1 | |
| 0.44 | 1.77 | 0.80 | 3.20 | -2.35 | 148.92 | -73.74 | 94.42 | 0.9633 | 150.0 | 92.8 | |
| 0.00 | 1.32 | 0.00 | 2.71 | -3.34 | 147.24 | -75.43 | 95.20 | 0.9713 | 102.0 | 119.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
