group	Proj. U	Proj. WS	Corr. U	Corr. WS	B	L	LCM	Pos. angle	r	MU	MP
12172	275.27	1482.44	168.71	907.55	-11.42	241.79	30.67	238.60	0.5834	-1.6	7.0

previous   or   next   observation for the same group / back to the solar disc SDO HMI 2014-09-29 00:00:33 UT See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!)

spot	Proj. U	Proj. WS	Corr. U	Corr. WS	B	L	LCM	Pos. angle	r	MU	MP
1	0.00	0.88	0.00	0.59	-9.21	249.76	38.64	247.87	0.6677	362.0	303.0
2	0.00	1.59	0.00	1.06	-10.44	249.89	38.77	246.24	0.6752	551.0	367.8
3	0.00	0.97	0.00	0.65	-12.09	249.32	38.21	243.66	0.6771	-483.0	-388.8
4	0.00	2.21	0.00	1.48	-12.64	249.03	37.91	242.75	0.6767	375.0	397.2
5	2.91	22.84	1.96	15.33	-13.29	248.83	37.71	241.75	0.6781	405.2	142.4
6	0.00	0.88	0.00	0.57	-8.26	247.95	36.83	248.23	0.6411	627.0	492.7
7	33.34	571.72	21.85	371.13	-11.08	248.04	36.92	244.27	0.6567	911.5	247.9
8	0.00	1.85	0.00	1.19	-8.97	247.42	36.30	246.90	0.6381	578.0	593.8
9	0.00	0.71	0.00	0.47	-13.97	248.06	36.94	240.36	0.6734	-321.0	-257.1
10	0.00	1.41	0.00	0.90	-8.90	247.26	36.14	246.91	0.6357	872.0	694.3
11	45.95	-7.00	29.84	-7.00	-10.94	247.45	36.33	244.09	0.6489	1291.3	999999
12	0.00	0.97	0.00	0.65	-14.11	247.85	36.73	240.03	0.6719	-525.0	-440.5
13	1.50	2.73	0.99	1.81	-14.10	247.31	36.19	239.67	0.6658	-510.8	-402.8
14	0.00	1.76	0.00	1.13	-10.87	246.49	35.37	243.57	0.6371	931.0	653.2
15	0.00	2.38	0.00	1.52	-10.17	246.29	35.17	244.45	0.6306	845.0	703.4
16	0.00	1.68	0.00	1.08	-11.21	246.42	35.31	243.05	0.6383	464.0	341.2
17	0.00	0.62	0.00	0.40	-13.18	246.46	35.34	240.33	0.6505	175.0	190.1
18	0.00	1.68	0.00	1.08	-12.05	246.25	35.13	241.74	0.6411	281.0	239.2
19	17.64	163.70	11.23	103.32	-10.83	245.92	34.81	243.26	0.6301	927.0	563.4
20	2.82	-7.00	1.85	-7.00	-14.23	246.45	35.34	238.90	0.6570	-583.2	999999
21	0.00	0.88	0.00	0.57	-12.26	246.05	34.93	241.32	0.6401	275.0	257.6
22	1.32	-7.00	0.86	-7.00	-13.25	246.17	35.05	240.03	0.6476	-360.9	999999
23	2.47	4.76	1.55	2.98	-8.68	245.52	34.40	246.16	0.6129	829.2	603.9
24	0.00	1.68	0.00	1.05	-9.08	245.53	34.41	245.56	0.6152	741.0	702.2
25	1.41	-7.00	0.91	-7.00	-13.33	245.92	34.80	239.74	0.6452	-274.0	999999
26	0.00	1.50	0.00	0.94	-8.72	245.30	34.19	245.95	0.6104	914.0	797.4
27	0.00	1.06	0.00	0.67	-11.31	245.61	34.50	242.36	0.6292	473.0	407.2
28	0.00	4.32	0.00	2.77	-12.49	245.75	34.63	240.78	0.6380	190.0	77.9
29	0.00	1.23	0.00	0.77	-9.35	245.30	34.18	245.01	0.6138	745.0	641.0
30	3.00	-7.00	1.95	-7.00	-14.03	245.85	34.73	238.74	0.6489	-626.8	999999
31	0.00	1.50	0.00	0.94	-10.00	245.19	34.07	243.98	0.6162	756.0	637.4
32	0.00	1.76	0.00	1.15	-14.22	245.81	34.69	238.46	0.6496	-626.0	-509.7
33	19.67	-19.00	12.41	-19.00	-10.84	245.22	34.10	242.76	0.6216	1100.7	999999
34	0.26	-7.00	0.17	-7.00	-13.72	245.53	34.41	238.93	0.6433	-446.0	999999
35	1.50	-7.00	0.97	-7.00	-13.84	245.48	34.36	238.73	0.6435	-778.5	999999
36	2.21	-19.00	1.38	-19.00	-10.51	244.92	33.80	243.03	0.6159	1095.1	999999
37	1.06	-19.00	0.66	-19.00	-10.79	244.88	33.76	242.60	0.6172	1180.9	999999
38	0.00	2.91	0.00	1.82	-9.96	244.70	33.59	243.69	0.6100	704.0	654.8
39	1.76	-7.00	1.13	-7.00	-13.65	245.07	33.95	238.68	0.6376	-556.3	999999
40	3.62	-7.00	2.33	-7.00	-14.01	245.09	33.97	238.21	0.6402	-760.4	999999
41	0.00	1.68	0.00	1.08	-14.33	245.11	33.99	237.79	0.6425	-709.0	-575.6
42	0.00	3.26	0.00	2.07	-12.74	244.82	33.70	239.76	0.6287	231.0	256.4
43	0.00	1.06	0.00	0.67	-12.45	244.74	33.62	240.11	0.6259	827.0	681.4
44	2.56	-7.00	1.63	-7.00	-13.54	244.83	33.71	238.66	0.6341	-586.3	999999
45	0.00	1.85	0.00	1.16	-11.54	244.35	33.23	241.13	0.6155	819.0	712.9
46	0.00	0.88	0.00	0.55	-10.11	244.10	32.98	243.05	0.6035	868.0	772.3
47	1.94	-7.00	1.23	-7.00	-13.29	244.46	33.34	238.72	0.6281	-586.9	999999
48	0.00	1.06	0.00	0.66	-10.26	244.04	32.93	242.78	0.6037	698.0	664.8
49	2.82	-7.00	1.79	-7.00	-13.44	244.29	33.18	238.39	0.6272	-757.2	999999
50	0.00	0.62	0.00	0.39	-12.35	244.13	33.01	239.80	0.6181	707.0	612.7
51	0.00	2.12	0.00	1.31	-10.28	243.86	32.75	242.62	0.6016	706.0	466.2
52	0.00	3.70	0.00	2.28	-9.68	243.72	32.61	243.43	0.5962	750.0	656.0
53	4.15	-7.00	2.61	-7.00	-12.84	243.95	32.83	238.96	0.6192	-659.3	999999
54	0.53	-7.00	0.33	-7.00	-13.39	244.03	32.91	238.25	0.6238	-873.8	999999
55	0.00	1.76	0.00	1.09	-10.29	243.61	32.49	242.42	0.5986	774.0	614.5
56	0.00	1.68	0.00	1.02	-9.51	243.09	31.98	243.22	0.5872	-614.0	-412.7
57	0.00	1.41	0.00	0.89	-14.53	242.92	31.80	235.78	0.6192	577.0	481.6
58	0.00	0.88	0.00	0.55	-14.22	242.18	31.06	235.58	0.6086	566.0	412.9
59	0.00	1.23	0.00	0.77	-13.77	242.08	30.96	236.13	0.6040	739.0	591.3
60	0.00	0.79	0.00	0.49	-14.02	242.08	30.96	235.77	0.6059	628.0	576.4
61	0.00	1.50	0.00	0.93	-13.68	241.67	30.55	235.91	0.5986	717.0	506.8
62	0.00	0.35	0.00	0.21	-11.81	241.31	30.20	238.32	0.5807	713.0	654.2
63	0.00	1.32	0.00	0.81	-13.22	241.42	30.31	236.35	0.5923	551.0	419.9
64	0.00	2.65	0.00	1.59	-11.10	240.49	29.37	238.68	0.5656	747.0	613.3
65	0.00	1.85	0.00	1.15	-15.24	240.97	29.85	233.10	0.6027	226.0	264.3
66	2.21	3.97	1.32	2.38	-11.59	240.30	29.18	237.76	0.5668	-587.4	-420.3
67	0.00	0.97	0.00	0.59	-14.03	240.61	29.49	234.47	0.5891	587.0	500.5
68	0.00	0.97	0.00	0.59	-13.50	240.36	29.24	234.99	0.5821	676.0	579.9
69	0.00	1.06	0.00	0.64	-12.73	239.84	28.72	235.63	0.5700	664.0	496.6
70	0.00	1.76	0.00	1.06	-13.91	239.28	28.17	233.38	0.5730	499.0	485.8
71	1.94	7.06	1.15	4.18	-11.41	238.88	27.76	236.73	0.5483	778.1	619.2
72	0.88	4.50	0.52	2.66	-11.69	238.81	27.69	236.23	0.5496	466.6	274.8
73	0.00	1.32	0.00	0.78	-11.49	238.61	27.50	236.35	0.5456	838.0	700.7
74	0.00	3.53	0.00	2.12	-13.82	238.75	27.63	232.99	0.5661	822.0	650.6
75	0.00	1.32	0.00	0.78	-11.63	238.32	27.20	235.84	0.5431	720.0	540.7
76	0.00	0.88	0.00	0.53	-14.06	238.50	27.38	232.39	0.5653	668.0	568.2
77	0.00	2.12	0.00	1.23	-10.33	238.08	26.97	237.68	0.5300	-565.0	-487.0
78	0.00	1.23	0.00	0.74	-14.34	238.43	27.31	231.91	0.5669	453.0	310.8
79	0.00	1.15	0.00	0.67	-11.04	237.98	26.86	236.43	0.5344	-776.0	-691.5
80	0.00	1.41	0.00	0.84	-14.17	238.23	27.11	231.96	0.5632	441.0	446.4
81	0.97	2.03	0.57	1.18	-11.29	237.35	26.24	235.40	0.5287	-732.2	-650.6
82	0.00	1.50	0.00	0.87	-11.41	237.13	26.01	234.99	0.5269	-798.0	-594.7
83	0.00	1.15	0.00	0.67	-12.26	237.11	25.99	233.64	0.5339	-745.0	-647.8
84	0.00	2.91	0.00	1.69	-11.36	236.88	25.77	234.80	0.5236	-797.0	-677.9
85	0.00	9.08	0.00	5.33	-12.89	236.97	25.86	232.54	0.5377	296.0	239.0
86	0.00	1.23	0.00	0.73	-14.26	236.93	25.81	230.46	0.5493	-686.0	-527.6
87	0.00	1.32	0.00	0.79	-16.05	237.16	26.04	228.21	0.5681	-817.0	-650.3
88	0.00	0.97	0.00	0.58	-15.88	237.14	26.02	228.40	0.5664	-685.0	-600.3
89	0.00	0.97	0.00	0.56	-11.66	236.64	25.52	234.07	0.5232	-670.0	-493.7
90	0.00	1.23	0.00	0.73	-14.52	236.92	25.81	230.09	0.5516	-643.0	-556.2
91	0.00	2.21	0.00	1.32	-15.86	236.75	25.64	228.01	0.5621	-779.0	-635.7
92	0.00	1.32	0.00	0.76	-11.55	236.26	25.14	233.83	0.5176	-739.0	-580.4
93	0.00	1.15	0.00	0.67	-12.34	236.23	25.11	232.57	0.5242	-555.0	-529.2
94	2.03	17.29	1.19	10.12	-13.42	236.31	25.20	231.01	0.5349	-838.9	-626.0
95	0.00	1.59	0.00	0.95	-16.02	236.60	25.48	227.63	0.5619	-659.0	-568.9
96	2.56	4.32	1.49	2.51	-12.59	236.12	25.00	232.06	0.5251	-654.2	-460.3
97	2.73	-94.00	1.60	-94.00	-13.52	236.22	25.10	230.77	0.5346	-936.4	999999
98	0.00	2.82	0.00	1.58	-6.25	235.64	24.52	242.41	0.4674	-608.0	-443.3
99	0.00	0.35	0.00	0.20	-11.72	236.00	24.88	233.27	0.5161	-557.0	-643.8
100	2.73	-94.00	1.60	-94.00	-13.70	236.17	25.06	230.44	0.5358	-832.0	999999
101	0.00	0.44	0.00	0.26	-14.90	236.25	25.13	228.80	0.5476	-489.0	-498.2
102	2.29	-94.00	1.34	-94.00	-13.54	236.05	24.94	230.55	0.5329	-919.5	999999
103	0.00	1.06	0.00	0.59	-6.36	235.48	24.36	242.03	0.4661	-850.0	-651.2
104	1.32	4.76	0.79	2.84	-16.00	236.32	25.20	227.34	0.5588	-868.7	-736.8
105	11.29	22.31	6.51	12.88	-11.99	235.69	24.57	232.50	0.5147	-950.3	-581.0
106	2.73	7.50	1.60	4.40	-14.39	235.84	24.73	229.06	0.5385	-796.5	-607.5
107	0.00	1.41	0.00	0.82	-14.00	235.66	24.54	229.43	0.5327	-834.0	-616.6
108	0.71	31.31	0.41	18.03	-12.74	235.49	24.38	231.11	0.5192	-797.1	-571.5
109	1.23	6.17	0.72	3.58	-13.09	235.39	24.28	230.47	0.5212	-841.3	-585.3
110	0.00	4.15	0.00	2.38	-11.84	235.17	24.05	232.15	0.5072	-896.0	-826.2
111	0.00	0.79	0.00	0.46	-13.76	235.33	24.21	229.40	0.5267	-677.0	-519.8
112	1.68	-108.00	0.96	-108.00	-12.40	235.05	23.94	231.13	0.5110	-872.0	999999
113	35.72	451.68	20.23	255.51	-10.12	234.75	23.64	234.49	0.4869	-1234.7	-471.6
114	0.00	1.76	0.00	0.98	-6.62	234.53	23.42	240.55	0.4552	-765.0	-663.5
115	2.12	-108.00	1.22	-108.00	-12.36	234.81	23.70	230.91	0.5078	-862.5	999999
116	2.47	-113.00	1.40	-113.00	-10.51	234.49	23.37	233.51	0.4870	-959.0	999999
117	1.15	-113.00	0.65	-113.00	-11.74	234.59	23.47	231.61	0.4995	-716.2	999999
118	0.00	0.88	0.00	0.51	-14.79	234.87	23.75	227.35	0.5316	-689.0	-565.0
119	0.00	3.35	0.00	1.96	-15.08	234.87	23.75	226.93	0.5344	-510.0	-430.4
120	0.00	1.06	0.00	0.61	-12.38	234.55	23.43	230.57	0.5049	-604.0	-494.4
121	7.76	-113.00	4.42	-113.00	-11.58	234.37	23.26	231.63	0.4954	-928.5	999999
122	8.56	-113.00	4.83	-113.00	-10.46	234.05	22.93	233.08	0.4812	-1318.4	999999
123	9.35	-113.00	5.29	-113.00	-10.74	234.07	22.95	232.63	0.4841	-1060.2	999999
124	0.00	1.32	0.00	0.76	-12.36	234.14	23.03	230.11	0.5000	-487.0	-492.6
125	1.94	-113.00	1.10	-113.00	-11.53	234.04	22.92	231.29	0.4909	-942.9	999999
126	0.00	1.32	0.00	0.77	-14.92	234.21	23.09	226.36	0.5257	-649.0	-564.5
127	0.00	1.15	0.00	0.64	-8.87	233.67	22.55	235.37	0.4625	-540.0	-499.7
128	8.82	-113.00	4.99	-113.00	-11.14	233.80	22.69	231.65	0.4845	-1014.0	999999
129	4.85	-113.00	2.73	-113.00	-10.87	233.48	22.37	231.69	0.4782	-1181.8	999999
130	0.79	-113.00	0.45	-113.00	-11.28	233.48	22.37	231.01	0.4821	-886.0	999999
131	0.00	0.88	0.00	0.49	-8.72	233.07	21.95	234.91	0.4535	-696.0	-550.4
132	0.00	1.41	0.00	0.81	-14.11	232.71	21.59	225.62	0.5014	-791.0	-625.9
133	0.00	2.29	0.00	1.30	-13.01	232.61	21.49	227.12	0.4890	-626.0	-643.8
134	0.00	1.85	0.00	1.02	-8.53	232.24	21.13	234.21	0.4412	-712.0	-645.5
135	0.00	1.41	0.00	0.78	-9.27	232.09	20.97	232.66	0.4462	-698.0	-556.1
136	0.00	0.71	0.00	0.40	-14.74	232.51	21.39	224.43	0.5058	-526.0	-387.2
137	0.00	1.23	0.00	0.69	-10.65	232.09	20.97	230.24	0.4594	-780.0	-649.0
138	0.00	1.15	0.00	0.64	-12.07	232.16	21.04	228.00	0.4745	-700.0	-525.2
139	0.00	0.97	0.00	0.55	-12.80	232.09	20.97	226.76	0.4811	-664.0	-559.1
140	0.00	1.76	0.00	0.97	-8.09	231.47	20.35	234.01	0.4274	-1007.0	-860.9
141	0.00	1.15	0.00	0.63	-8.07	230.95	19.84	233.34	0.4206	-809.0	-622.8
142	0.00	0.71	0.00	0.40	-13.55	231.00	19.88	224.09	0.4772	-634.0	-516.1
143	0.00	1.15	0.00	0.63	-15.28	225.87	14.75	213.40	0.4482	-729.0	-599.5
144	0.00	1.15	0.00	0.64	-15.47	225.79	14.67	213.01	0.4500	-648.0	-500.9
145	0.00	1.68	0.00	0.90	-13.19	221.31	10.19	206.84	0.3833	-39.0	-77.5

	Proj. U	-  Projected umbra area in millionths of solar disc, negative values indicate
	that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2.
	Proj. WS	-  Projected whole spot area in millionths of solar disc, negative values indicate
	that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7.
	Corr. U	-  Corrected umbra area in millionths of solar hemisphere, for negative values see above
	Corr. WS	-  Corrected whole spot area in millionths of solar hemisphere, for negative values see above
	B	-  Heliographic latitude B; positive: North, negative: South
	L	-  Heliographic longitude L
	LCM	-  Longitudinal distance from the Sun's central meridian
	Pos. angle	-  Position angle
	r	-  Distance from the centre of Sun's disc in terms of Sun's radius
	MU	-  Mean magnetic field within the umbra contour averaged the pixel values with sign.
	MP	-  Mean magnetic field within the penumbra contour averaged the pixel values with sign.
