SDO HMI 2014-09-29 01:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.82 | 112.64 | 15.09 | 106.00 | -9.85 | 266.11 | 55.54 | 253.54 | 0.8466 | 72.9 | 77.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-29 01:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.38 | 60.60 | 2.46 | 63.28 | -8.15 | 270.20 | 59.64 | 256.80 | 0.8792 | 862.8 | 183.6 | |
| 0.00 | 1.06 | 0.00 | 1.11 | -10.94 | 270.16 | 59.59 | 253.70 | 0.8841 | -244.0 | -268.3 | |
| 0.00 | 1.06 | 0.00 | 1.08 | -10.76 | 269.31 | 58.75 | 253.67 | 0.8771 | 408.0 | 267.1 | |
| 0.00 | 0.97 | 0.00 | 0.91 | -11.95 | 265.93 | 55.37 | 251.35 | 0.8517 | 523.0 | 428.5 | |
| 0.79 | 1.50 | 0.67 | 1.27 | -10.59 | 262.05 | 51.48 | 251.64 | 0.8125 | 307.7 | 308.0 | |
| 0.00 | 1.06 | 0.00 | 0.89 | -10.92 | 261.64 | 51.07 | 251.10 | 0.8096 | 469.0 | 362.2 | |
| 0.00 | 1.32 | 0.00 | 1.11 | -10.67 | 261.58 | 51.01 | 251.38 | 0.8082 | 551.0 | 459.3 | |
| 0.62 | 16.14 | 0.52 | 13.43 | -11.44 | 261.42 | 50.85 | 250.42 | 0.8090 | 366.9 | 497.0 | |
| 2.47 | -8.00 | 2.06 | -8.00 | -11.27 | 261.28 | 50.71 | 250.57 | 0.8072 | 661.2 | 999999 | |
| 1.06 | -8.00 | 0.88 | -8.00 | -11.44 | 261.13 | 50.56 | 250.30 | 0.8062 | 572.0 | 999999 | |
| 3.88 | -8.00 | 3.21 | -8.00 | -11.32 | 260.81 | 50.24 | 250.34 | 0.8027 | 729.7 | 999999 | |
| 0.53 | 7.41 | 0.42 | 5.91 | -11.64 | 258.95 | 48.38 | 249.23 | 0.7854 | -567.7 | -478.7 | |
| 2.29 | -12.00 | 1.83 | -12.00 | -11.86 | 258.95 | 48.39 | 248.96 | 0.7862 | -579.5 | 999999 | |
| 0.00 | 0.53 | 0.00 | 0.42 | -12.25 | 259.05 | 48.48 | 248.53 | 0.7885 | -411.0 | -388.2 | |
| 0.00 | 2.03 | 0.00 | 1.62 | -12.05 | 258.95 | 48.38 | 248.73 | 0.7868 | -611.0 | -366.8 | |
| 2.65 | 4.94 | 2.15 | 4.01 | -13.59 | 259.16 | 48.59 | 246.98 | 0.7944 | -573.2 | -432.5 | |
| 0.00 | 1.23 | 0.00 | 1.00 | -13.69 | 258.86 | 48.29 | 246.74 | 0.7918 | -600.0 | -559.9 | |
| 0.00 | 0.97 | 0.00 | 0.74 | -11.36 | 256.93 | 46.36 | 248.74 | 0.7637 | -497.0 | -333.9 | |
| 0.00 | 0.62 | 0.00 | 0.50 | -16.15 | 258.05 | 47.48 | 243.48 | 0.7935 | -353.0 | -254.7 | |
| 0.00 | 0.53 | 0.00 | 0.43 | -16.02 | 257.68 | 47.12 | 243.46 | 0.7895 | -272.0 | -343.7 | |
| 1.15 | 10.67 | 0.89 | 8.29 | -14.54 | 256.66 | 46.10 | 244.74 | 0.7735 | -692.4 | -602.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
