SDO HMI 2014-09-29 02:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.21 | 110.17 | 19.34 | 104.90 | -9.87 | 266.16 | 56.14 | 253.69 | 0.8517 | 181.7 | 98.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-29 02:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.67 | 58.40 | 11.35 | 62.03 | -8.16 | 270.58 | 60.56 | 257.02 | 0.8866 | 594.6 | 207.1 | |
| 0.97 | -1.00 | 1.02 | -1.00 | -8.11 | 270.13 | 60.12 | 256.96 | 0.8830 | 797.5 | 999999 | |
| 0.00 | 0.44 | 0.00 | 0.47 | -10.88 | 270.21 | 60.19 | 253.93 | 0.8886 | -369.0 | -390.8 | |
| 0.00 | 0.97 | 0.00 | 1.01 | -10.78 | 269.25 | 59.24 | 253.78 | 0.8810 | 128.0 | 194.4 | |
| 0.00 | 0.79 | 0.00 | 0.77 | -8.58 | 267.47 | 57.45 | 255.78 | 0.8619 | 497.0 | 419.8 | |
| 0.71 | 1.76 | 0.60 | 1.51 | -10.55 | 262.04 | 52.02 | 251.87 | 0.8176 | 273.5 | 220.6 | |
| 0.00 | 1.06 | 0.00 | 0.90 | -10.70 | 261.63 | 51.61 | 251.56 | 0.8141 | 502.0 | 460.1 | |
| 0.00 | 1.24 | 0.00 | 1.05 | -10.92 | 261.68 | 51.66 | 251.31 | 0.8152 | 526.0 | 385.0 | |
| 3.18 | 15.26 | 2.66 | 12.86 | -11.31 | 260.84 | 50.82 | 250.56 | 0.8083 | 708.1 | 553.5 | |
| 0.00 | 1.06 | 0.00 | 0.88 | -11.17 | 260.66 | 50.64 | 250.66 | 0.8062 | 664.0 | 539.1 | |
| 1.15 | 9.09 | 0.92 | 7.33 | -11.67 | 258.97 | 48.95 | 249.43 | 0.7911 | -514.0 | -444.9 | |
| 0.00 | 0.88 | 0.00 | 0.72 | -12.24 | 259.06 | 49.04 | 248.77 | 0.7940 | -337.0 | -279.4 | |
| 0.62 | -11.00 | 0.50 | -11.00 | -11.85 | 258.87 | 48.85 | 249.17 | 0.7907 | -749.0 | 999999 | |
| 0.00 | 0.62 | 0.00 | 0.50 | -12.03 | 258.77 | 48.75 | 248.92 | 0.7904 | -228.0 | -267.0 | |
| 0.00 | 4.41 | 0.00 | 3.62 | -13.58 | 259.13 | 49.11 | 247.21 | 0.7993 | -709.0 | -538.4 | |
| 0.00 | 1.76 | 0.00 | 1.44 | -13.71 | 258.84 | 48.82 | 246.93 | 0.7969 | -580.0 | -511.4 | |
| 0.00 | 0.79 | 0.00 | 0.61 | -11.88 | 256.85 | 46.84 | 248.30 | 0.7705 | -428.0 | -356.6 | |
| 0.00 | 1.32 | 0.00 | 1.10 | -17.75 | 257.99 | 47.98 | 241.85 | 0.8046 | -156.0 | -242.7 | |
| 2.91 | 10.32 | 2.29 | 8.10 | -14.49 | 256.60 | 46.58 | 245.03 | 0.7781 | -718.5 | -555.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
