SDO HMI 2014-09-29 10:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.53 | 14.12 | 0.40 | 10.39 | -13.82 | 162.77 | -42.86 | 116.13 | 0.7385 | 261.3 | 199.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-29 10:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.06 | 0.00 | 0.73 | -23.79 | 173.58 | -32.06 | 135.39 | 0.6938 | 549.0 | 427.9 | |
| 0.00 | 0.26 | 0.00 | 0.20 | -23.58 | 166.48 | -39.15 | 129.75 | 0.7549 | 436.0 | 483.0 | |
| 0.00 | 2.65 | 0.00 | 1.80 | -13.20 | 167.17 | -38.46 | 117.62 | 0.6858 | 762.0 | 584.1 | |
| 0.00 | 0.62 | 0.00 | 0.43 | -14.42 | 166.73 | -38.90 | 118.94 | 0.6973 | 519.0 | 438.7 | |
| 0.00 | 0.62 | 0.00 | 0.41 | -7.33 | 166.12 | -39.52 | 108.99 | 0.6697 | 441.0 | 513.6 | |
| 0.00 | 1.41 | 0.00 | 1.03 | -16.35 | 163.85 | -41.78 | 119.66 | 0.7381 | 684.0 | 582.3 | |
| 0.00 | 1.06 | 0.00 | 0.74 | -11.36 | 164.01 | -41.62 | 113.43 | 0.7121 | 553.0 | 439.8 | |
| 0.00 | 1.15 | 0.00 | 0.91 | -17.44 | 159.82 | -45.82 | 118.81 | 0.7830 | 561.0 | 415.4 | |
| 0.00 | 0.97 | 0.00 | 0.72 | -10.08 | 160.18 | -45.45 | 110.00 | 0.7491 | -555.0 | -534.2 | |
| 0.53 | 2.29 | 0.40 | 1.76 | -10.54 | 158.90 | -46.74 | 110.05 | 0.7644 | -608.2 | -456.1 | |
| 0.00 | 0.62 | 0.00 | 0.49 | -10.93 | 157.68 | -47.95 | 110.04 | 0.7784 | 440.0 | 390.3 | |
| 0.00 | 1.41 | 0.00 | 1.17 | -13.91 | 156.13 | -49.51 | 112.99 | 0.8041 | -299.0 | -306.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
