SDO HMI 2014-09-29 13:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 9.69 | 0.00 | 5.26 | -14.18 | 201.23 | -2.76 | 166.85 | 0.3922 | 40.0 | -94.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-29 13:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.41 | 0.00 | 0.79 | -18.32 | 214.29 | 10.30 | 201.90 | 0.4571 | 726.0 | 638.6 | |
| 0.00 | 1.06 | 0.00 | 0.62 | -24.85 | 211.21 | 7.22 | 192.29 | 0.5380 | 733.0 | 586.3 | |
| 0.00 | 0.79 | 0.00 | 0.47 | -25.23 | 211.17 | 7.18 | 192.05 | 0.5434 | 715.0 | 563.7 | |
| 0.00 | 0.88 | 0.00 | 0.47 | -14.25 | 200.21 | -3.78 | 169.89 | 0.3658 | -832.0 | -646.8 | |
| 0.00 | 1.50 | 0.00 | 0.79 | -12.42 | 196.97 | -7.02 | 160.00 | 0.3507 | 0.0 | -13.9 | |
| 0.00 | 0.79 | 0.00 | 0.42 | -10.87 | 193.73 | -10.26 | 149.86 | 0.3499 | -5.0 | -4.3 | |
| 0.00 | 3.26 | 0.00 | 1.70 | -6.92 | 192.89 | -11.10 | 140.85 | 0.3040 | -1057.0 | -770.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
