SDO HMI 2014-09-29 23:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 98.46 | 522.66 | 56.43 | 300.08 | 12.07 | 168.24 | -30.23 | 77.57 | 0.5056 | 0.9 | 95.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-29 23:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.17 | 0.00 | 1.75 | 9.91 | 172.44 | -26.03 | 81.28 | 0.4392 | -875.0 | -728.1 | |
| 0.00 | 0.88 | 0.00 | 0.49 | 9.49 | 172.41 | -26.06 | 82.25 | 0.4392 | -817.0 | -674.7 | |
| 0.00 | 1.06 | 0.00 | 0.59 | 10.52 | 171.88 | -26.60 | 80.03 | 0.4488 | -717.0 | -597.9 | |
| 5.99 | 194.70 | 3.34 | 109.21 | 12.34 | 171.45 | -27.02 | 76.16 | 0.4590 | -1165.5 | -351.9 | |
| 3.44 | -4.00 | 1.92 | -4.00 | 12.29 | 171.11 | -27.36 | 76.38 | 0.4640 | -1076.8 | 999999 | |
| 0.00 | 1.23 | 0.00 | 0.69 | 11.84 | 171.13 | -27.35 | 77.35 | 0.4627 | -185.0 | -383.6 | |
| 0.00 | 1.41 | 0.00 | 0.79 | 9.69 | 171.03 | -27.45 | 82.01 | 0.4607 | -671.0 | -554.9 | |
| 0.00 | 0.53 | 0.00 | 0.30 | 13.32 | 170.54 | -27.93 | 74.41 | 0.4752 | -614.0 | -501.3 | |
| 34.73 | -4.00 | 19.49 | -4.00 | 12.23 | 170.56 | -27.91 | 76.68 | 0.4720 | -1151.3 | 999999 | |
| 0.00 | 1.50 | 0.00 | 0.85 | 13.82 | 170.26 | -28.21 | 73.49 | 0.4807 | -746.0 | -520.8 | |
| 0.62 | 2.38 | 0.35 | 1.34 | 13.39 | 170.18 | -28.29 | 74.40 | 0.4807 | -740.3 | -606.7 | |
| 0.00 | 1.59 | 0.00 | 0.90 | 15.81 | 169.84 | -28.63 | 69.69 | 0.4936 | -503.0 | -445.7 | |
| 0.00 | 0.88 | 0.00 | 0.50 | 13.75 | 169.99 | -28.48 | 73.75 | 0.4844 | -395.0 | -318.2 | |
| 0.00 | 5.73 | 0.00 | 3.24 | 13.53 | 169.88 | -28.59 | 74.23 | 0.4855 | 188.0 | 52.9 | |
| 0.00 | 6.61 | 0.00 | 3.77 | 13.21 | 169.04 | -29.43 | 75.17 | 0.4969 | 450.0 | 519.5 | |
| 0.00 | 1.15 | 0.00 | 0.65 | 11.49 | 169.11 | -29.36 | 78.61 | 0.4922 | -800.0 | -645.7 | |
| 0.00 | 1.41 | 0.00 | 0.81 | 16.28 | 168.44 | -30.04 | 69.45 | 0.5152 | -591.0 | -372.6 | |
| 1.41 | 12.16 | 0.81 | 6.96 | 13.59 | 168.74 | -29.73 | 74.52 | 0.5022 | 816.3 | 695.0 | |
| 0.00 | 1.41 | 0.00 | 0.81 | 13.22 | 168.68 | -29.79 | 75.27 | 0.5021 | 887.0 | 732.4 | |
| 9.17 | 150.37 | 5.23 | 86.28 | 11.89 | 168.81 | -29.66 | 77.86 | 0.4973 | -827.7 | 223.2 | |
| 0.79 | -18.00 | 0.45 | -18.00 | 13.48 | 168.50 | -29.97 | 74.81 | 0.5054 | 733.0 | 999999 | |
| 0.35 | -20.00 | 0.20 | -20.00 | 11.11 | 168.80 | -29.67 | 79.45 | 0.4962 | 1009.5 | 999999 | |
| 3.79 | -20.00 | 2.17 | -20.00 | 11.60 | 168.35 | -30.12 | 78.56 | 0.5035 | -702.2 | 999999 | |
| 0.00 | 1.94 | 0.00 | 1.11 | 10.75 | 168.41 | -30.06 | 80.23 | 0.5014 | 907.0 | 728.0 | |
| 0.00 | 1.06 | 0.00 | 0.61 | 10.84 | 168.30 | -30.17 | 80.08 | 0.5032 | 643.0 | 604.2 | |
| 0.71 | -20.00 | 0.41 | -20.00 | 12.25 | 167.56 | -30.91 | 77.48 | 0.5163 | 976.1 | 999999 | |
| 8.46 | -20.00 | 4.91 | -20.00 | 12.40 | 167.14 | -31.33 | 77.28 | 0.5227 | 870.7 | 999999 | |
| 1.15 | 2.91 | 0.66 | 1.68 | 10.83 | 167.19 | -31.28 | 80.27 | 0.5194 | 895.2 | 732.0 | |
| 0.00 | 1.06 | 0.00 | 0.61 | 10.52 | 166.94 | -31.53 | 80.92 | 0.5227 | 732.0 | 543.0 | |
| 0.00 | 0.62 | 0.00 | 0.36 | 13.62 | 166.17 | -32.30 | 75.25 | 0.5391 | -434.0 | -331.0 | |
| 0.00 | 1.23 | 0.00 | 0.72 | 10.78 | 166.30 | -32.17 | 80.51 | 0.5324 | 916.0 | 748.9 | |
| 0.00 | 0.88 | 0.00 | 0.52 | 10.67 | 166.06 | -32.41 | 80.74 | 0.5358 | 571.0 | 546.6 | |
| 0.88 | 5.55 | 0.52 | 3.28 | 13.16 | 165.69 | -32.78 | 76.21 | 0.5450 | 992.5 | 753.6 | |
| 17.63 | 56.41 | 10.34 | 33.06 | 11.09 | 165.94 | -32.54 | 79.99 | 0.5381 | 1004.8 | 698.3 | |
| 2.29 | -34.00 | 1.35 | -34.00 | 11.42 | 165.82 | -32.65 | 79.40 | 0.5401 | 1106.8 | 999999 | |
| 0.62 | -33.00 | 0.36 | -33.00 | 13.25 | 165.57 | -32.91 | 76.09 | 0.5469 | 814.6 | 999999 | |
| 0.00 | 1.15 | 0.00 | 0.67 | 10.60 | 165.89 | -32.59 | 80.90 | 0.5382 | 566.0 | 460.7 | |
| 0.00 | 2.47 | 0.00 | 1.45 | 10.77 | 165.68 | -32.79 | 80.61 | 0.5413 | 590.0 | 483.6 | |
| 2.20 | 8.20 | 1.30 | 4.84 | 11.79 | 165.52 | -32.95 | 78.76 | 0.5450 | 855.7 | 656.9 | |
| 0.00 | 1.23 | 0.00 | 0.73 | 12.53 | 165.30 | -33.17 | 77.45 | 0.5493 | 698.0 | 629.9 | |
| 0.00 | 0.97 | 0.00 | 0.57 | 10.88 | 165.45 | -33.02 | 80.45 | 0.5448 | 451.0 | 385.1 | |
| 0.00 | 2.29 | 0.00 | 1.36 | 12.31 | 165.19 | -33.28 | 77.87 | 0.5505 | 557.0 | 531.1 | |
| 0.00 | 0.79 | 0.00 | 0.47 | 12.10 | 165.22 | -33.25 | 78.25 | 0.5498 | 679.0 | 569.2 | |
| 0.00 | 2.20 | 0.00 | 1.30 | 11.28 | 165.18 | -33.29 | 79.74 | 0.5492 | 534.0 | 455.4 | |
| 0.00 | 1.50 | 0.00 | 0.89 | 12.85 | 164.96 | -33.51 | 76.96 | 0.5547 | 389.0 | 382.0 | |
| 0.00 | 1.85 | 0.00 | 1.11 | 13.80 | 164.67 | -33.81 | 75.33 | 0.5607 | 860.0 | 676.7 | |
| 0.00 | 1.76 | 0.00 | 1.05 | 11.67 | 164.98 | -33.49 | 79.08 | 0.5525 | 503.0 | 392.4 | |
| 0.00 | 1.23 | 0.00 | 0.74 | 11.36 | 164.40 | -34.07 | 79.73 | 0.5604 | -552.0 | -477.2 | |
| 0.00 | 2.12 | 0.00 | 1.27 | 10.61 | 164.05 | -34.42 | 81.11 | 0.5645 | -490.0 | -493.6 | |
| 0.00 | 1.06 | 0.00 | 0.65 | 15.62 | 163.17 | -35.31 | 72.59 | 0.5855 | 551.0 | 448.1 | |
| 0.00 | 0.97 | 0.00 | 0.58 | 11.61 | 163.69 | -34.78 | 79.38 | 0.5707 | -812.0 | -722.5 | |
| 0.00 | 1.06 | 0.00 | 0.64 | 10.87 | 163.38 | -35.09 | 80.72 | 0.5742 | -587.0 | -482.5 | |
| 0.00 | 1.41 | 0.00 | 0.86 | 12.16 | 162.29 | -36.18 | 78.65 | 0.5908 | 783.0 | 661.4 | |
| 0.00 | 3.70 | 0.00 | 2.28 | 12.23 | 162.01 | -36.46 | 78.57 | 0.5948 | 870.0 | 709.9 | |
| 0.00 | 2.73 | 0.00 | 1.68 | 12.49 | 161.85 | -36.62 | 78.16 | 0.5973 | 870.0 | 730.1 | |
| 1.15 | 3.00 | 0.71 | 1.85 | 12.26 | 161.62 | -36.85 | 78.57 | 0.6001 | 880.9 | 761.8 | |
| 0.00 | 1.41 | 0.00 | 0.88 | 14.09 | 161.26 | -37.21 | 75.62 | 0.6078 | 512.0 | 449.9 | |
| 0.00 | 1.23 | 0.00 | 0.76 | 11.22 | 161.51 | -36.96 | 80.32 | 0.6005 | 710.0 | 514.0 | |
| 0.00 | 0.88 | 0.00 | 0.55 | 12.36 | 161.34 | -37.14 | 78.45 | 0.6042 | 593.0 | 473.7 | |
| 1.76 | 5.38 | 1.09 | 3.33 | 12.12 | 161.34 | -37.14 | 78.85 | 0.6039 | 839.0 | 614.4 | |
| 0.00 | 1.41 | 0.00 | 0.87 | 11.91 | 161.33 | -37.14 | 79.20 | 0.6037 | 626.0 | 477.5 | |
| 0.00 | 1.67 | 0.00 | 1.04 | 12.07 | 161.07 | -37.40 | 78.96 | 0.6074 | 852.0 | 661.8 | |
| 1.32 | 2.56 | 0.82 | 1.59 | 11.88 | 160.87 | -37.60 | 79.31 | 0.6099 | 792.8 | 669.6 | |
| 0.00 | 0.79 | 0.00 | 0.50 | 14.01 | 160.49 | -37.98 | 75.90 | 0.6179 | 400.0 | 390.6 | |
| 0.00 | 2.38 | 0.00 | 1.49 | 12.04 | 160.61 | -37.86 | 79.08 | 0.6136 | 638.0 | 549.1 | |
| 0.00 | 1.32 | 0.00 | 0.83 | 12.02 | 160.30 | -38.17 | 79.15 | 0.6177 | 597.0 | 493.5 | |
| 0.00 | 0.88 | 0.00 | 0.56 | 11.82 | 159.19 | -39.28 | 79.60 | 0.6323 | 593.0 | 448.2 | |
| 0.00 | 1.23 | 0.00 | 0.81 | 9.48 | 157.48 | -41.00 | 83.34 | 0.6537 | -567.0 | -410.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
