SDO HMI 2014-09-30 06:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 80.08 | 328.23 | 54.86 | 223.02 | -1.38 | 151.98 | -42.65 | 99.28 | 0.6884 | 338.6 | 259.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-30 06:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29.54 | 253.81 | 19.74 | 170.41 | -1.32 | 153.19 | -41.44 | 99.54 | 0.6732 | 1197.2 | 397.3 | |
| 4.59 | -1.00 | 3.09 | -1.00 | -1.75 | 152.81 | -41.81 | 100.04 | 0.6791 | 880.1 | 999999 | |
| 3.44 | -1.00 | 2.31 | -1.00 | -1.18 | 152.67 | -41.96 | 99.18 | 0.6795 | 700.0 | 999999 | |
| 0.26 | -1.00 | 0.18 | -1.00 | -1.86 | 152.53 | -42.10 | 100.11 | 0.6830 | 665.0 | 999999 | |
| 7.41 | -1.00 | 5.05 | -1.00 | -1.57 | 151.92 | -42.71 | 99.53 | 0.6898 | 756.3 | 999999 | |
| 2.12 | -1.00 | 1.45 | -1.00 | -1.91 | 151.87 | -42.76 | 99.99 | 0.6913 | 542.0 | 999999 | |
| 1.15 | -1.00 | 0.79 | -1.00 | -1.68 | 151.67 | -42.95 | 99.61 | 0.6931 | 615.6 | 999999 | |
| 1.32 | 4.14 | 0.90 | 2.83 | -0.74 | 151.69 | -42.93 | 98.28 | 0.6906 | 532.8 | 380.9 | |
| 2.56 | -1.00 | 1.75 | -1.00 | -1.51 | 151.64 | -42.99 | 99.35 | 0.6931 | 411.5 | 999999 | |
| 0.88 | 2.20 | 0.60 | 1.51 | -0.39 | 151.62 | -43.01 | 97.74 | 0.6907 | 751.3 | 537.3 | |
| 1.32 | -1.00 | 0.91 | -1.00 | -1.82 | 151.46 | -43.17 | 99.75 | 0.6961 | 247.4 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.73 | -0.82 | 151.49 | -43.14 | 98.33 | 0.6933 | -399.0 | -247.5 | |
| 1.41 | -1.00 | 0.97 | -1.00 | -1.65 | 151.34 | -43.28 | 99.47 | 0.6971 | 531.2 | 999999 | |
| 0.00 | 1.06 | 0.00 | 0.73 | -1.92 | 151.33 | -43.29 | 99.85 | 0.6979 | -103.0 | -142.0 | |
| 0.00 | 2.47 | 0.00 | 1.71 | -1.45 | 150.85 | -43.78 | 99.04 | 0.7027 | 616.0 | 429.8 | |
| 0.00 | 0.79 | 0.00 | 0.55 | -1.66 | 150.80 | -43.83 | 99.33 | 0.7038 | 514.0 | 383.0 | |
| 2.47 | 6.09 | 1.73 | 4.27 | -1.91 | 150.37 | -44.25 | 99.56 | 0.7096 | 618.1 | 331.7 | |
| 0.00 | 1.68 | 0.00 | 1.18 | -0.76 | 150.02 | -44.60 | 97.86 | 0.7111 | -238.0 | -123.1 | |
| 0.00 | 1.68 | 0.00 | 1.19 | -1.86 | 149.48 | -45.14 | 99.24 | 0.7201 | -349.0 | -313.4 | |
| 0.00 | 1.23 | 0.00 | 0.87 | -0.08 | 149.43 | -45.19 | 96.78 | 0.7168 | -665.0 | -440.5 | |
| 5.03 | 47.27 | 3.57 | 33.62 | -0.69 | 149.34 | -45.29 | 97.60 | 0.7192 | -945.2 | -590.9 | |
| 4.67 | -21.00 | 3.33 | -21.00 | -0.94 | 149.30 | -45.33 | 97.93 | 0.7203 | -906.6 | 999999 | |
| 0.00 | 1.32 | 0.00 | 0.94 | -0.30 | 149.30 | -45.32 | 97.06 | 0.7188 | -752.0 | -635.1 | |
| 11.91 | -21.00 | 8.49 | -21.00 | -1.25 | 149.25 | -45.38 | 98.34 | 0.7216 | -761.3 | 999999 | |
| 0.00 | 0.97 | 0.00 | 0.69 | -1.95 | 149.14 | -45.49 | 99.27 | 0.7245 | -516.0 | -400.0 | |
| 0.00 | 1.23 | 0.00 | 0.88 | -0.67 | 148.96 | -45.67 | 97.47 | 0.7238 | -537.0 | -382.9 | |
| 0.00 | 1.23 | 0.00 | 0.91 | -2.76 | 147.93 | -46.70 | 100.02 | 0.7405 | 619.0 | 443.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
