SDO HMI 2014-09-30 16:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 76.98 | 436.00 | 113.40 | 652.44 | 15.20 | 260.71 | 71.57 | 283.82 | 0.9430 | -24.8 | -93.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-09-30 16:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.67 | 70.20 | 3.35 | 135.13 | 13.12 | 265.92 | 76.78 | 281.87 | 0.9699 | -225.0 | -68.2 | |
| 0.26 | -1.00 | 0.53 | -1.00 | 13.27 | 265.94 | 76.80 | 282.03 | 0.9699 | -153.3 | 999999 | |
| 0.97 | -1.00 | 1.85 | -1.00 | 13.56 | 265.29 | 76.15 | 282.29 | 0.9671 | -208.5 | 999999 | |
| 3.44 | -1.00 | 6.32 | -1.00 | 13.75 | 264.70 | 75.56 | 282.45 | 0.9645 | -379.0 | 999999 | |
| 1.50 | -1.00 | 2.74 | -1.00 | 14.04 | 264.61 | 75.46 | 282.74 | 0.9640 | -233.1 | 999999 | |
| 1.23 | -1.00 | 2.20 | -1.00 | 14.15 | 264.21 | 75.07 | 282.83 | 0.9622 | -517.4 | 999999 | |
| 0.00 | 2.11 | 0.00 | 3.58 | 14.19 | 263.30 | 74.16 | 282.83 | 0.9578 | -422.0 | -351.9 | |
| 19.11 | 164.98 | 30.30 | 256.32 | 15.11 | 262.01 | 72.87 | 283.73 | 0.9511 | -507.6 | -291.6 | |
| 5.37 | -8.00 | 8.37 | -8.00 | 15.80 | 261.68 | 72.54 | 284.45 | 0.9493 | -484.2 | 999999 | |
| 4.32 | -8.00 | 6.55 | -8.00 | 15.23 | 261.18 | 72.04 | 283.83 | 0.9467 | -852.6 | 999999 | |
| 0.00 | 0.79 | 0.00 | 1.12 | 13.73 | 259.62 | 70.48 | 282.18 | 0.9382 | 188.0 | 153.1 | |
| 4.40 | -8.00 | 6.47 | -8.00 | 15.00 | 260.48 | 71.34 | 283.56 | 0.9429 | -33.4 | 999999 | |
| 0.00 | 1.50 | 0.00 | 2.07 | 13.76 | 259.09 | 69.94 | 282.19 | 0.9350 | 430.0 | 396.6 | |
| 0.00 | 3.17 | 0.00 | 4.33 | 14.12 | 258.88 | 69.74 | 282.57 | 0.9337 | 546.0 | 376.5 | |
| 0.00 | 1.59 | 0.00 | 2.16 | 14.42 | 258.73 | 69.58 | 282.88 | 0.9327 | 252.0 | 272.6 | |
| 0.70 | 2.64 | 0.95 | 3.55 | 15.06 | 258.47 | 69.33 | 283.57 | 0.9310 | 280.6 | 249.0 | |
| 2.55 | 12.51 | 3.34 | 16.26 | 14.67 | 257.84 | 68.70 | 283.13 | 0.9271 | 650.4 | 418.1 | |
| 8.02 | 168.94 | 10.54 | 218.46 | 15.52 | 258.00 | 68.86 | 284.05 | 0.9280 | 452.2 | 37.2 | |
| 3.44 | -18.00 | 4.48 | -18.00 | 15.86 | 257.73 | 68.59 | 284.41 | 0.9263 | 396.7 | 999999 | |
| 0.00 | 0.88 | 0.00 | 1.19 | 17.20 | 258.61 | 69.47 | 285.87 | 0.9316 | -420.0 | -399.3 | |
| 20.00 | -18.00 | 25.41 | -18.00 | 16.42 | 257.12 | 67.98 | 285.02 | 0.9223 | 649.9 | 999999 | |
| 0.00 | 0.26 | 0.00 | 0.33 | 17.25 | 256.73 | 67.59 | 285.91 | 0.9198 | 504.0 | 425.7 | |
| 0.00 | 0.79 | 0.00 | 0.97 | 17.14 | 256.24 | 67.10 | 285.80 | 0.9165 | 577.0 | 538.2 | |
| 0.00 | 5.64 | 0.00 | 6.97 | 17.72 | 256.43 | 67.29 | 286.43 | 0.9178 | 445.0 | 392.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
