SDO HMI 2014-10-01 04:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 30.85 | 240.42 | 60.71 | 516.71 | 15.43 | 260.42 | 77.89 | 284.35 | 0.9726 | 68.1 | -95.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-01 04:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.59 | 0.00 | 6.09 | 12.56 | 266.34 | 83.81 | 281.85 | 0.9921 | 70.0 | 83.6 | |
| 0.00 | 1.41 | 0.00 | 4.93 | 13.07 | 265.70 | 83.17 | 282.31 | 0.9906 | -100.0 | -138.4 | |
| 0.00 | 4.23 | 0.00 | 14.34 | 13.50 | 265.49 | 82.97 | 282.72 | 0.9900 | 2.0 | -8.4 | |
| 0.00 | 4.76 | 0.00 | 16.30 | 13.87 | 265.48 | 82.95 | 283.10 | 0.9899 | 81.0 | 125.0 | |
| 0.00 | 2.47 | 0.00 | 7.28 | 13.75 | 264.07 | 81.54 | 282.86 | 0.9863 | -262.0 | -125.2 | |
| 0.00 | 4.67 | 0.00 | 14.21 | 14.16 | 264.57 | 82.05 | 283.32 | 0.9875 | 235.0 | 120.4 | |
| 0.00 | 2.20 | 0.00 | 6.22 | 14.37 | 263.84 | 81.31 | 283.47 | 0.9855 | -223.0 | -165.1 | |
| 6.43 | 115.72 | 15.18 | 268.51 | 15.01 | 261.81 | 79.29 | 283.98 | 0.9789 | -402.1 | -241.0 | |
| 2.73 | -8.00 | 6.73 | -8.00 | 15.38 | 262.38 | 79.85 | 284.39 | 0.9807 | 14.5 | 999999 | |
| 3.97 | -8.00 | 8.34 | -8.00 | 15.16 | 260.25 | 77.72 | 284.03 | 0.9732 | -427.3 | 999999 | |
| 0.00 | 3.17 | 0.00 | 5.63 | 14.60 | 257.48 | 74.95 | 283.30 | 0.9615 | 509.0 | 343.6 | |
| 0.00 | 5.11 | 0.00 | 9.24 | 15.62 | 257.80 | 75.27 | 284.38 | 0.9627 | 421.0 | 240.7 | |
| 1.85 | 69.71 | 3.28 | 120.84 | 15.96 | 257.55 | 75.02 | 284.72 | 0.9615 | 184.4 | 71.7 | |
| 0.00 | 1.15 | 0.00 | 1.83 | 14.85 | 255.53 | 73.00 | 283.47 | 0.9519 | 310.0 | 293.5 | |
| 14.28 | -13.00 | 24.49 | -13.00 | 16.50 | 256.92 | 74.40 | 285.26 | 0.9585 | 455.8 | 999999 | |
| 1.15 | 1.94 | 1.94 | 3.29 | 17.16 | 256.70 | 74.17 | 285.93 | 0.9573 | 344.0 | 258.9 | |
| 0.44 | 15.60 | 0.75 | 27.01 | 17.35 | 256.92 | 74.39 | 286.14 | 0.9583 | 233.4 | -144.1 | |
| 0.00 | 1.23 | 0.00 | 2.01 | 17.11 | 255.96 | 73.43 | 285.86 | 0.9537 | 450.0 | 472.9 | |
| 0.00 | 5.46 | 0.00 | 8.98 | 17.62 | 256.17 | 73.65 | 286.40 | 0.9546 | 417.0 | 396.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
