SDO HMI 2014-10-01 04:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 19.48 | 114.22 | 13.54 | 79.68 | -10.06 | 140.89 | -41.64 | 111.64 | 0.7063 | 587.2 | 285.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-01 04:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 5.29 | 0.00 | 3.67 | -14.28 | 142.96 | -39.57 | 118.31 | 0.7035 | 38.0 | 119.3 | |
| 0.00 | 0.44 | 0.00 | 0.33 | -16.69 | 139.84 | -42.69 | 119.52 | 0.7487 | 512.0 | 492.4 | |
| 19.48 | 103.82 | 13.54 | 72.17 | -9.65 | 140.94 | -41.59 | 111.12 | 0.7039 | 992.0 | 343.6 | |
| 0.00 | 0.88 | 0.00 | 0.66 | -14.60 | 138.24 | -44.29 | 116.13 | 0.7549 | -739.0 | -621.1 | |
| 0.00 | 1.50 | 0.00 | 1.12 | -13.42 | 138.27 | -44.25 | 114.69 | 0.7494 | -568.0 | -458.6 | |
| 0.00 | 1.41 | 0.00 | 1.06 | -13.56 | 138.11 | -44.42 | 114.79 | 0.7517 | -653.0 | -576.2 | |
| 0.00 | 0.88 | 0.00 | 0.67 | -12.50 | 136.43 | -46.10 | 112.70 | 0.7648 | -548.0 | -450.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
