SDO HMI 2014-10-01 11:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.69 | 71.02 | 13.74 | 40.69 | 7.34 | 209.10 | 30.41 | 273.07 | 0.5046 | -102.8 | 150.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-01 11:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.97 | 0.00 | 0.57 | 7.47 | 211.53 | 32.83 | 273.41 | 0.5407 | -612.0 | -450.5 | |
| 17.44 | 34.27 | 10.15 | 19.93 | 7.65 | 210.57 | 31.88 | 273.73 | 0.5266 | -1024.8 | -663.3 | |
| 3.70 | -2.00 | 2.15 | -2.00 | 7.30 | 210.51 | 31.81 | 273.05 | 0.5257 | -967.3 | 999999 | |
| 0.00 | 1.23 | 0.00 | 0.71 | 6.69 | 210.11 | 31.41 | 271.87 | 0.5200 | -813.0 | -710.9 | |
| 0.00 | 2.47 | 0.00 | 1.42 | 7.40 | 209.84 | 31.15 | 273.23 | 0.5158 | -760.0 | -745.0 | |
| 0.35 | 4.23 | 0.20 | 2.41 | 6.49 | 208.48 | 29.78 | 271.35 | 0.4956 | 649.5 | 646.1 | |
| 0.00 | 0.97 | 0.00 | 0.55 | 8.29 | 208.58 | 29.88 | 275.00 | 0.4969 | 735.0 | 673.3 | |
| 0.00 | 1.06 | 0.00 | 0.60 | 8.16 | 208.15 | 29.45 | 274.76 | 0.4904 | 595.0 | 473.9 | |
| 0.00 | 0.88 | 0.00 | 0.50 | 7.54 | 207.99 | 29.30 | 273.48 | 0.4880 | 712.0 | 629.0 | |
| 0.00 | 4.23 | 0.00 | 2.39 | 6.74 | 207.73 | 29.03 | 271.82 | 0.4842 | 757.0 | 603.2 | |
| 0.00 | 2.11 | 0.00 | 1.20 | 8.00 | 207.79 | 29.09 | 274.44 | 0.4849 | 657.0 | 503.7 | |
| 0.00 | 1.67 | 0.00 | 0.94 | 7.80 | 207.56 | 28.87 | 274.03 | 0.4814 | 715.0 | 647.1 | |
| 0.97 | 1.85 | 0.55 | 1.04 | 7.66 | 207.52 | 28.82 | 273.72 | 0.4807 | 898.8 | 811.6 | |
| 0.00 | 1.41 | 0.00 | 0.79 | 6.73 | 207.45 | 28.75 | 271.78 | 0.4799 | 770.0 | 622.4 | |
| 1.23 | 4.76 | 0.69 | 2.68 | 7.55 | 207.30 | 28.60 | 273.49 | 0.4775 | 931.0 | 905.0 | |
| 0.00 | 1.59 | 0.00 | 0.89 | 6.54 | 207.06 | 28.36 | 271.36 | 0.4740 | 726.0 | 584.9 | |
| 0.00 | 1.23 | 0.00 | 0.69 | 7.54 | 206.82 | 28.12 | 273.49 | 0.4701 | 834.0 | 708.1 | |
| 0.00 | 0.97 | 0.00 | 0.54 | 7.07 | 206.75 | 28.05 | 272.46 | 0.4691 | 821.0 | 714.5 | |
| 0.00 | 2.03 | 0.00 | 1.13 | 6.33 | 205.85 | 27.15 | 270.82 | 0.4555 | 767.0 | 710.0 | |
| 0.00 | 1.06 | 0.00 | 0.59 | 6.18 | 205.33 | 26.64 | 270.43 | 0.4476 | 713.0 | 578.5 | |
| 0.00 | 2.03 | 0.00 | 1.12 | 6.17 | 204.93 | 26.23 | 270.37 | 0.4413 | 787.0 | 590.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
