SDO HMI 2014-10-01 11:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 5.37 | 0.00 | 3.51 | 4.49 | 138.10 | -40.60 | 90.95 | 0.6509 | 51.2 | 141.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-01 11:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.79 | 0.00 | 0.49 | 3.88 | 141.33 | -37.37 | 92.39 | 0.6083 | -688.0 | -524.0 | |
| 0.00 | 0.26 | 0.00 | 0.17 | 4.30 | 140.39 | -38.31 | 91.56 | 0.6206 | -469.0 | -462.0 | |
| 0.00 | 1.23 | 0.00 | 0.80 | 4.47 | 138.27 | -40.43 | 90.98 | 0.6489 | -154.0 | -160.4 | |
| 0.00 | 0.97 | 0.00 | 0.64 | 4.63 | 137.58 | -41.12 | 90.64 | 0.6578 | 567.0 | 498.1 | |
| 0.00 | 1.06 | 0.00 | 0.70 | 4.80 | 137.41 | -41.29 | 90.37 | 0.6599 | 466.0 | 414.5 | |
| 0.00 | 1.06 | 0.00 | 0.71 | 4.53 | 136.29 | -42.40 | 90.63 | 0.6746 | 585.0 | 498.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
