SDO HMI 2014-10-01 14:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.32 | 264.94 | 31.79 | 133.41 | 12.11 | 168.73 | -8.31 | 54.35 | 0.1737 | -213.8 | -69.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-01 14:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.85 | 0.00 | 0.92 | 9.66 | 173.70 | -3.35 | 47.93 | 0.0780 | -1156.0 | -976.5 | |
| 0.00 | 1.14 | 0.00 | 0.57 | 8.46 | 173.28 | -3.77 | 64.42 | 0.0724 | -940.0 | -707.5 | |
| 0.00 | 1.14 | 0.00 | 0.57 | 9.75 | 173.08 | -3.96 | 51.79 | 0.0871 | -948.0 | -718.7 | |
| 0.00 | 2.38 | 0.00 | 1.18 | 10.26 | 172.59 | -4.46 | 50.73 | 0.0993 | -987.0 | -878.5 | |
| 0.00 | 1.41 | 0.00 | 0.71 | 13.99 | 172.35 | -4.70 | 31.97 | 0.1510 | -869.0 | -633.2 | |
| 0.00 | 1.06 | 0.00 | 0.53 | 10.61 | 171.97 | -5.08 | 51.63 | 0.1114 | -1003.0 | -852.9 | |
| 0.00 | 0.97 | 0.00 | 0.48 | 10.19 | 171.95 | -5.10 | 54.89 | 0.1074 | -938.0 | -734.8 | |
| 0.00 | 1.14 | 0.00 | 0.57 | 10.49 | 171.76 | -5.29 | 53.63 | 0.1131 | -930.0 | -783.5 | |
| 0.00 | 2.11 | 0.00 | 1.05 | 10.76 | 171.73 | -5.32 | 51.90 | 0.1164 | -948.0 | -766.2 | |
| 0.00 | 1.23 | 0.00 | 0.62 | 13.65 | 171.45 | -5.60 | 37.89 | 0.1550 | -799.0 | -575.1 | |
| 0.00 | 3.17 | 0.00 | 1.59 | 12.74 | 171.13 | -5.92 | 43.47 | 0.1468 | -890.0 | -788.2 | |
| 3.43 | 22.19 | 1.72 | 11.10 | 12.11 | 171.12 | -5.93 | 46.76 | 0.1394 | -1143.6 | -654.5 | |
| 0.00 | 1.23 | 0.00 | 0.62 | 14.34 | 170.91 | -6.14 | 37.76 | 0.1700 | 979.0 | 702.0 | |
| 0.00 | 2.11 | 0.00 | 1.06 | 13.01 | 170.88 | -6.17 | 43.39 | 0.1531 | -289.0 | -326.0 | |
| 4.58 | 82.95 | 2.29 | 41.59 | 12.20 | 170.77 | -6.27 | 47.87 | 0.1447 | -1053.3 | -472.5 | |
| 36.19 | -15.00 | 18.14 | -15.00 | 12.71 | 170.48 | -6.56 | 46.58 | 0.1542 | -1159.2 | 999999 | |
| 0.00 | 0.79 | 0.00 | 0.40 | 13.82 | 170.21 | -6.84 | 42.81 | 0.1710 | -700.0 | -560.6 | |
| 0.00 | 1.14 | 0.00 | 0.58 | 14.42 | 170.13 | -6.92 | 40.77 | 0.1796 | 787.0 | 612.5 | |
| 0.00 | 0.88 | 0.00 | 0.44 | 13.67 | 170.06 | -6.99 | 44.05 | 0.1709 | -665.0 | -523.8 | |
| 4.49 | 26.06 | 2.25 | 13.08 | 12.24 | 169.51 | -7.54 | 52.71 | 0.1620 | -1140.7 | -626.0 | |
| 2.20 | 5.02 | 1.11 | 2.52 | 12.75 | 169.21 | -7.84 | 51.29 | 0.1712 | -883.4 | -686.0 | |
| 0.00 | 1.14 | 0.00 | 0.57 | 11.63 | 168.97 | -8.08 | 57.65 | 0.1638 | -786.0 | -584.7 | |
| 0.00 | 1.14 | 0.00 | 0.57 | 10.85 | 168.89 | -8.15 | 62.14 | 0.1583 | 1022.0 | 853.8 | |
| 0.00 | 3.96 | 0.00 | 1.99 | 11.66 | 168.69 | -8.36 | 58.36 | 0.1681 | -583.0 | -536.7 | |
| 0.00 | 3.26 | 0.00 | 1.64 | 12.50 | 168.47 | -8.57 | 54.87 | 0.1788 | -694.0 | -530.1 | |
| 0.00 | 1.76 | 0.00 | 0.88 | 10.30 | 168.48 | -8.57 | 66.36 | 0.1608 | 973.0 | 810.6 | |
| 0.00 | 1.50 | 0.00 | 0.75 | 11.08 | 168.12 | -8.93 | 62.95 | 0.1719 | 1048.0 | 811.0 | |
| 0.00 | 9.69 | 0.00 | 4.88 | 12.16 | 167.86 | -9.18 | 58.22 | 0.1844 | 752.0 | 394.2 | |
| 0.00 | 0.97 | 0.00 | 0.49 | 11.28 | 167.71 | -9.34 | 62.89 | 0.1797 | 808.0 | 647.0 | |
| 0.00 | 2.82 | 0.00 | 1.42 | 12.24 | 167.61 | -9.44 | 58.48 | 0.1888 | 928.0 | 679.8 | |
| 0.00 | 1.32 | 0.00 | 0.67 | 12.45 | 167.29 | -9.76 | 58.37 | 0.1952 | 860.0 | 636.6 | |
| 1.06 | 5.11 | 0.53 | 2.58 | 12.08 | 167.24 | -9.80 | 60.13 | 0.1929 | 1080.9 | 803.7 | |
| 0.00 | 5.99 | 0.00 | 3.02 | 11.36 | 167.21 | -9.84 | 63.63 | 0.1879 | 501.0 | 757.6 | |
| 0.00 | 10.57 | 0.00 | 5.33 | 10.94 | 167.13 | -9.92 | 65.88 | 0.1862 | 1148.0 | 939.2 | |
| 0.00 | 2.55 | 0.00 | 1.29 | 11.27 | 166.96 | -10.09 | 64.61 | 0.1910 | 887.0 | 887.3 | |
| 0.00 | 0.79 | 0.00 | 0.40 | 10.33 | 166.93 | -10.12 | 69.31 | 0.1856 | 817.0 | 652.7 | |
| 0.00 | 1.14 | 0.00 | 0.58 | 10.87 | 166.79 | -10.26 | 66.87 | 0.1911 | 999.0 | 831.6 | |
| 0.00 | 1.76 | 0.00 | 0.89 | 11.41 | 166.74 | -10.31 | 64.38 | 0.1955 | 874.0 | 677.5 | |
| 2.20 | 13.74 | 1.11 | 6.94 | 11.02 | 166.60 | -10.45 | 66.52 | 0.1950 | 1043.3 | 824.4 | |
| 0.00 | 2.91 | 0.00 | 1.47 | 13.43 | 166.47 | -10.58 | 56.26 | 0.2157 | 1181.0 | 892.3 | |
| 5.20 | -39.00 | 2.62 | -39.00 | 10.77 | 166.45 | -10.60 | 67.96 | 0.1958 | 975.0 | 999999 | |
| 0.00 | 1.32 | 0.00 | 0.67 | 9.48 | 166.18 | -10.87 | 74.76 | 0.1936 | 868.0 | 592.4 | |
| 0.00 | 2.73 | 0.00 | 1.38 | 11.48 | 165.83 | -11.22 | 65.78 | 0.2100 | 612.0 | 555.3 | |
| 0.00 | 1.06 | 0.00 | 0.54 | 13.79 | 165.16 | -11.88 | 57.78 | 0.2375 | 766.0 | 662.0 | |
| 0.53 | 2.11 | 0.27 | 1.08 | 11.76 | 164.66 | -12.39 | 66.57 | 0.2299 | -904.7 | -799.8 | |
| 2.38 | 3.96 | 1.21 | 2.02 | 11.43 | 164.65 | -12.40 | 67.96 | 0.2281 | -1066.7 | -770.6 | |
| 0.00 | 1.41 | 0.00 | 0.72 | 11.09 | 164.25 | -12.79 | 69.91 | 0.2325 | -769.0 | -577.1 | |
| 0.00 | 2.29 | 0.00 | 1.17 | 11.57 | 164.17 | -12.88 | 68.08 | 0.2364 | -671.0 | -605.2 | |
| 1.06 | 5.02 | 0.54 | 2.58 | 12.65 | 162.73 | -14.32 | 66.04 | 0.2653 | 839.0 | 860.8 | |
| 0.00 | 0.97 | 0.00 | 0.50 | 11.04 | 162.53 | -14.52 | 72.10 | 0.2598 | 895.0 | 669.3 | |
| 0.00 | 0.62 | 0.00 | 0.32 | 12.40 | 162.42 | -14.63 | 67.32 | 0.2685 | 623.0 | 429.3 | |
| 0.00 | 0.97 | 0.00 | 0.50 | 15.59 | 161.99 | -15.06 | 57.63 | 0.2976 | 817.0 | 713.9 | |
| 0.00 | 1.06 | 0.00 | 0.54 | 12.53 | 161.81 | -15.24 | 67.61 | 0.2787 | 792.0 | 623.5 | |
| 0.00 | 1.50 | 0.00 | 0.78 | 13.87 | 161.15 | -15.90 | 64.08 | 0.2971 | 866.0 | 703.8 | |
| 0.00 | 1.32 | 0.00 | 0.68 | 12.47 | 160.76 | -16.29 | 68.98 | 0.2947 | 847.0 | 641.2 | |
| 0.00 | 3.26 | 0.00 | 1.69 | 12.28 | 160.68 | -16.37 | 69.67 | 0.2951 | 855.0 | 628.3 | |
| 0.00 | 1.23 | 0.00 | 0.64 | 12.66 | 159.30 | -17.75 | 69.80 | 0.3183 | 867.0 | 730.2 | |
| 0.00 | 0.70 | 0.00 | 0.37 | 12.54 | 159.18 | -17.87 | 70.28 | 0.3196 | 801.0 | 645.6 | |
| 0.00 | 1.32 | 0.00 | 0.69 | 10.76 | 159.13 | -17.91 | 75.80 | 0.3131 | 771.0 | 557.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
