SDO HMI 2014-10-01 20:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.58 | 113.35 | 16.42 | 70.54 | -10.11 | 140.46 | -33.27 | 116.56 | 0.6063 | 554.1 | 260.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-01 20:00:32 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.70 | 0.00 | 0.44 | -13.74 | 142.63 | -31.11 | 123.56 | 0.6046 | 626.0 | 496.2 | |
| 0.00 | 1.32 | 0.00 | 0.85 | -15.34 | 140.71 | -33.03 | 124.19 | 0.6377 | 634.0 | 570.1 | |
| 0.00 | 1.14 | 0.00 | 0.71 | -12.00 | 141.02 | -32.71 | 119.78 | 0.6113 | 730.0 | 574.9 | |
| 0.00 | 0.88 | 0.00 | 0.57 | -15.81 | 139.95 | -33.79 | 124.22 | 0.6494 | 164.0 | 233.9 | |
| 26.58 | 99.29 | 16.42 | 61.39 | -9.61 | 140.74 | -32.99 | 116.03 | 0.5998 | 1085.7 | 322.7 | |
| 0.00 | 1.14 | 0.00 | 0.72 | -11.46 | 140.18 | -33.55 | 118.37 | 0.6179 | 650.0 | 526.8 | |
| 0.00 | 0.53 | 0.00 | 0.34 | -15.26 | 139.57 | -34.17 | 123.19 | 0.6498 | 651.0 | 508.3 | |
| 0.00 | 0.70 | 0.00 | 0.45 | -12.43 | 139.82 | -33.92 | 119.50 | 0.6284 | 579.0 | 543.0 | |
| 0.00 | 0.26 | 0.00 | 0.17 | -13.68 | 138.30 | -35.43 | 120.15 | 0.6537 | -637.0 | -595.3 | |
| 0.00 | 1.23 | 0.00 | 0.81 | -14.63 | 137.98 | -35.76 | 121.20 | 0.6633 | -797.0 | -575.5 | |
| 0.00 | 0.88 | 0.00 | 0.58 | -13.44 | 137.58 | -36.15 | 119.33 | 0.6605 | -584.0 | -519.1 | |
| 0.00 | 1.14 | 0.00 | 0.76 | -13.87 | 136.89 | -36.85 | 119.45 | 0.6709 | -141.0 | -303.4 | |
| 0.00 | 0.88 | 0.00 | 0.59 | -13.92 | 136.65 | -37.09 | 119.36 | 0.6739 | -323.0 | -360.4 | |
| 0.00 | 0.44 | 0.00 | 0.29 | -12.88 | 136.61 | -37.13 | 117.93 | 0.6684 | -593.0 | -593.4 | |
| 0.00 | 1.06 | 0.00 | 0.70 | -12.34 | 136.54 | -37.20 | 117.17 | 0.6661 | -680.0 | -564.5 | |
| 0.00 | 1.76 | 0.00 | 1.17 | -12.55 | 136.31 | -37.42 | 117.30 | 0.6699 | -697.0 | -472.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
