SDO HMI 2014-10-01 23:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.82 | 101.32 | 55.97 | 236.23 | -15.60 | 247.28 | 75.19 | 252.35 | 0.9761 | -214.2 | 125.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-10-01 23:00:33 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.43 | 0.00 | 29.32 | -18.20 | 256.13 | 84.05 | 251.20 | 0.9984 | 177.0 | 123.9 | |
| 0.00 | 0.97 | 0.00 | 2.53 | -15.32 | 248.78 | 76.69 | 252.92 | 0.9827 | 501.0 | 468.2 | |
| 0.00 | 1.23 | 0.00 | 3.12 | -15.49 | 248.29 | 76.21 | 252.67 | 0.9813 | 420.0 | 413.9 | |
| 1.06 | 6.60 | 2.73 | 17.13 | -16.08 | 248.45 | 76.36 | 252.11 | 0.9821 | 174.9 | 333.1 | |
| 4.75 | 30.90 | 10.47 | 67.29 | -14.92 | 246.68 | 74.60 | 252.95 | 0.9754 | 476.2 | 374.0 | |
| 0.53 | -5.00 | 1.12 | -5.00 | -14.70 | 246.12 | 74.03 | 253.07 | 0.9731 | 216.8 | 999999 | |
| 6.25 | 47.80 | 12.43 | 93.08 | -14.75 | 245.15 | 73.07 | 252.84 | 0.9694 | -370.7 | -257.9 | |
| 0.00 | 6.69 | 0.00 | 15.91 | -16.96 | 247.29 | 75.21 | 251.01 | 0.9790 | 439.0 | 276.5 | |
| 15.23 | -7.00 | 29.22 | -7.00 | -15.00 | 244.63 | 72.55 | 252.48 | 0.9674 | -535.1 | 999999 | |
| 0.00 | 3.70 | 0.00 | 7.85 | -16.28 | 245.83 | 73.75 | 251.42 | 0.9733 | -57.0 | -38.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
